1. LABORATORY OF PROCESS SYSTEMS ENGINEERING First steps to the integration of carbon- and hydrogen supply chains Edwin Zondervan* *ezon@uni-bremen.de Narayen K.R. Tuan Nguyen Anton Ochoa Bique Sven Charmeteau Kevin Schmidtke Sebastian Schulze Grazia Leonzio

2. Forecast Problem attacked: Population, wealth and energy-demand are growing, leading to (amongst others) increased GHG emissions. How can we prevent that more-and-more CO2 is released into our atmosphere? Insight found: In dealing with this complex problem a systems perspective is very valuable! (everything is connected to everything), that is what PSE lab in Bremen tries to do! 2

3. Outline Some numbers and interpretations on carbon dioxide/Greenhouse Gases; The (engineering) challenges that we face; How PSE lab in Bremen is working on carbon dioxide? (our first insights) 3

4. Climate change 4

5. 5

6. 6

7. 7

8. ...towards implementation From a concept, an innovation ... 8

9. 9

10. 10

11. 11

12. 112

13. PSE Lab on: Carbon capture with absorption via IL s? Tuan Nguyen Capture technology: absorption with [bmim][Ac] can remove up to 90% CO2 from flue gas streams (at different compositions and flow rates) MEA_0.1 kmol/s IL_0.1 kmol/s MEA_1 kmol/s IL_1 kmol/s MEA_5 kmol/s IL_5 kmol/s MEA_10 kmol/s IL_10 kmol/s 240 220 Total cost/ton CO2 captured ($/ton) (cost includes feed dehydration, CO2 capture & compression) 200 180 160 140 120 100 80 60 40 20 0 13 0.0 0.1 0.2 0.3 0.4 0.5 0.6 Molar fraction of CO2 in feed

14. PSE Lab on : Carbon storage as CO2 mitigation option Narayen K.R. Data analysis: aggregation of sources/sinks: From 242 sources to 35 sources Model development: Mixed Integer Linear Program with approx. 7000 Decision variables Storage capacity: 85% of storage capacity is still available even after 25 years of CO2 storage Preferred technology: In this problem, PSA using MVY is preferred (13 alternatives) Cost effectiveness: Further optimization of capture technologies is necessary to reduce the cost ( 47,83 billion ( 35,43/tCO2/yr) 14

15. PSE Lab on : Carbon utilization via methanol production Sebastian Schulze Sven Charmeteau Kevin Schmidtke Data analysis: location of primary emission sources, hydrogen production- and methanol reforming sites Model development: Mixed Integer Linear Program with approx. 7000 Decision variables Anton Ochoa Bique Main driver: Flue gas composition Preferred transport: Best is to transport raw materials and product via pipeline Cost effectiveness: A Methanol supply chain based on CO2 emissions and renewable hydrogen is at this stage not feasibile: energy should cost nothing and capture costs should be dramatically reduced 15

16. PSE Lab on : Carbon capture, storage and utilization integrative design Grazia Leonzio Model development: Mixed Integer Quadratic Program for Germany including storage and utilization options ~1700 variables and constraints Data analysis: Potential for CO2 utilization in Europe Main driver: Utilization is preferred over storage Preferred technology: PSA as preferred techn. (highest efficiency, highest costs) Cost effectiveness: Capture costs take up to 90% of the total supply chain costs; production costs are 20x higher than current MeOH sales prices economic and environmental incentives required 16

17. Observations Scale: Looking only at one aspect will lead to conflicting conclusions; Time: A carbon dioxide economy might not be sustainable; hopefully CO2 emissions will not occur in the (far) future: that means that there is no need for capture, storage and utilization; 18

18. Next ... Management of (combinatorial) complexity Decision-making under uncertainty Multi-criterion decision making 17
