Situated in Palm Coast, the oldest fire station, built in 1977, is undergoing significant improvements for health, safety, and energy efficiency. The project includes upgrades to the kitchen, truck bay exhaust system, electrical outlets, fire separation, and floor plan reconfiguration. These enhancements aim to modernize the facility and ensure the well-being of firefighters. Visual representations of existing and proposed floor plans provide insight into the transformation of the approximately 3,900 SF space.


Uploaded on Sep 09, 2024 | 0 Views


Download Presentation

Please find below an Image/Link to download the presentation.

The content on the website is provided AS IS for your information and personal use only. It may not be sold, licensed, or shared on other websites without obtaining consent from the author. Download presentation by click this link. If you encounter any issues during the download, it is possible that the publisher has removed the file from their server.

E N D

Presentation Transcript


  1. FIRE STATION No. 22 Improvement Project Project Budget Expenses

  2. BACKGROUND Palm Coast s Oldest Fire Station (Built in 1977). Approximately 3,900 SF. Original Design included a fire hose drying chase that doubled as a clock tower as well as a future 2nd floor.

  3. FLOOR PLANS EXISTING & PROPOSED

  4. PROPOSED IMPROVEMENTS Health & Safety ADA Improvements Energy Improvements

  5. PROPOSED IMPROVEMENTS Health & Safety Kitchen Replacement Truck Bay Exhaust Electrical Fire Separation Floor Plan Reconfiguration Interior Finishes

  6. Health & Safety Kitchen Replace cabinets and countertops New sink, faucet and garbage disposal New dishwasher and under cabinet microwave

  7. Health & Safety Truck Bay Exhaust Add Exhaust System w/Push Button & CO Detector/sensor

  8. Health & Safety Electrical Additional Power Outlets Replace Smoke Detectors Add Safety Sensors to Truck Bay doors Replace Doorbell & Wiring

  9. Health & Safety Fire Separation Install 1-hour firewall between truck bay and living space

  10. Health & Safety Floor Plan Reconfiguration Relocate/Connect laundry tub/washer (in truck bay) to building sewer drain New shelving in truck bay for consumables New shelving/open cabinets in storage room for fire fighter s PPE gear Relocate ice machine to opposite wall of truck bay to connect to building drainage system

  11. Health & Safety Interior Finishes New Vinyl Flooring in Living Areas Paint all Walls Paint Truck Bay Floor & Ceiling

  12. PROPOSED IMPROVEMENTS - ADA ADA Parking Space Improvements Building Access Improvements Building Entrance Modification Restroom Modifications

  13. ADA Improvements Parking & Building Access Adjust Wheel Stop Reconstruct Walkway from Parking spot to Entrance

  14. ADA Improvements Building Entrance Replace Entry Doors with Wider door and reconfigure furniture layout in Day Room

  15. ADA Improvements Restroom Renovate Existing Restroom/Shower Room to meet ADA requirements

  16. PROPOSED IMPROVEMENTS - Energy Insulation Lighting Hot Water Heater

  17. Energy Insulation Remove old floating batt insulation above drop ceiling and install spray foam insulation & fire barrier above living space Spray foam insulate exterior block walls (if needed)

  18. Energy lighting Replace fluorescent lighting throughout with new LED lighting

  19. Energy Hot Water Heater Replace leaking water heater with new energy savings water heater

  20. PROPOSED IMPROVEMENTS - BUDGET Mechanical Electrical Plumbing G.C. Cabinet/Counter Flooring Insulation Truck Door Sensors PW Fire Dept Permits & Misc. Contingency 18,742.00 $ 11,510.00 $ 8,202.64 $ 9,800.00 $ 3,600.00 $ 2,859.50 $ 8,995.00 $ 1,050.00 $ 5,000.00 $ 10,000.00 $ 5,000.00 $ 15,240.86 $ 100,000.00 $

  21. COUNCIL ACTION Approve Expenses in the Amount of $100,000.00 associated with Fire Station No. 22 Improvements

  22. Questions?
