  1. Imaging of Wrist DR AMITA HARSULE

  2. Basic Radiograph ROUTINE PA Lateral Scaphoid series when there is tenderness in the anatomical snuff box.

  3. PA ulnar deviation

  4. note the disruption of arc I at the lunotriquetral joint.

  5. A disruption of the second carpal arc at the scapholunate joint and the lunotriquetral joint is seen on the left.

  6. There is an abnormal step off at the capitohamate joint.

  7. Volar aspect of the wrist

  8. USG

  9. CT

  10. CT

  11. Ligamentous Anatomy Classified as either extrinsic or intrinsic. The extrinsic ligaments link the carpal bones to the radius and ulna. The intrinsic or intercarpal ligaments connect the individual carpal bones.

  12. Normal TFCC. Triangular fibrocartilage proper (*). Foveal (arrow) and styloid (dashed arrow) insertions. Meniscus homologue (arrow head). Normal lunotriquetral (LTL) and scapholunate (SLL) ligaments are also seen.

  13. MENISCUS HOMOLOGUE

  14. Tendon pathology Tendon pathology is often encountered in the wrist and hand, which may be the result of overuse, trauma or inflammation.Patients typically present with focal pain and swelling. The term "tendinitis" is an inaccurate term A better term is tendinosis, which describesa degenerative process with "microtears", healing and vascularin-growth. The term "tendinopathy" encompasses both degenerativeand inflammatory conditions. Tenosynovitis refers to inflammatorychange within the tendon sheath, with or without tendon morphologicalchanges.

  15. flexor tenosynovitis

  16. Carpal Tunnel $ Causes include flexor tenosynovitis, trauma, systemic inflammatory disease, pregnancy, acromegaby, hypothyroidism

  17. Space-occupying lesions within the carpal tunnel such as ganglia, tenosynovitis, and anatomic variants are well seen with MR imaging MR imaging is therefore indicated only in patients with equivocal clinical findings, a suspected mass

  18. Compressive ulnar neuropathy. (A) At the level of the canal of Guyon s. The Guyon canal is a triangular space lateral to the pisiform bone and medial to the hamate that contains the ulnar nerve and ulnar artery. (B) The ulnar nerve (arrow) has high signal intensity and it is thickened. There is a ganglion cyst (*) compressing the ulnar nerve against the pisiform. (C)

  19. GANGUON CYSTS Seventy percent of all wrist ganglia occur dorsally adjacent to the SLL

  20. 1. ganglion cyst that arises from the dorsal aspect of the SLL 2. volar ganglion cyst adjacent to the radioscaphoid joint

  21. schwannoma of radial nerve
