Assisted Reproductive Technologies: Gamete Intra-fallopian Transfer (GIFT)


ASSISSTED REPRODUCTIVE
TECHNOLOGIES

Kamal Kumar Gupta

Gamete Intra-fallopian transfer

GIFT is an assisted reproductive procedure
which involves removing a woman’s eggs,
mixing them with sperm, and immediately
placing them into a fallopian tube
In GIFT fertilization takes place inside the
fallopian tube rather than in a laboratory
unlike in vitro fertilization (IVF) and zygote
intrafallopian transfer (ZIFT)

How is GIFT performed?

Healthy tubes are necessary for GIFT to work
Patients must first have an x-ray to determine
the presence of at least one healthy fallopian
tube. The doctor use a laparoscope to ensure
that there is not any scar tissue on the outside
of the fallopian tube
Using a laparoscope, eggs are then retrieved
from the ovaries
The male provides a sperm sample on the
same day that the eggs are retrieved

How is GIFT performed?

The eggs are then mixed with the sperm in a
catheter
The egg and sperm mixture is inserted into
the fallopian tubes with a catheter
The woman is then provided with medication
to build up the uterine lining to support
implantation of a fertilized egg

Who can be treated with GIFT?

Couples with unexplainable infertility
Women who have at least one healthy
fallopian tube
Couples in which the husband has a low
sperm count or other problems with his sperm
Couples who have not had success with IVF
Couples who have a religious or moral
reluctance to use IVF

Differences between GIFT and in vitro
fertilization (IVF)?

With IVF, the eggs are fertilized in a laboratory
rather than in the fallopian tubes as with GIFT
IVF can be used with couples in which the female
does not have fallopian tubes or has blocked
fallopian tubes
IVF allows for fertilization confirmation and
assessment of embryo quality
GIFT does not involve fertilization outside of the
body, so couples do not have to deal with the
ethical
 concerns with choosing which embryos to
transfer

Advantages and Disadvantages

The GIFT does not require the patient to be
hospitalized. After the procedure, patients
typically stay in recovery for about eight hours
Doctors cannot visibly confirm fertilization or
determine embryo quality with GIFT
GIFT cannot be used in patients who have
damaged or blocked fallopian tubes

Vaginal GIFT

A major disadvantage with conventional GIFT is that a
surgical procedure - laparoscopy - is needed to transfer
the eggs and sperm into the fallopian tube
Dr.
Jansen and Anderson
from Sydney, described vaginal
GIFT, in which the gametes can be transferred into the
fallopian tubes through the vagina and cervix under
ultrasound guidance

Vaginal GIFT

This requires a special set of catheters which allow the
doctor to enter the uterine ends of the fallopian tubes
through the cervix
 Once the catheters have been accurately positioned -
and ultrasound can help in this - the gametes are
injected into the tubes.
Since this does not involve surgery, it is less expense, no
hospitalization, no scar and no anesthesia is required
 However, the technique does require much more
technical expertise and is still being investigated more
thoroughly.
Also, the pregnancy rates with the method are less than
with conventional laparoscopic GIFT.

Zygote Intrafallopian transfer

Transfer of zygote in the fallopian tube
Difference between IVF-ET and ZIFT
Difference between GIFT and ZIFT

Similarities and Differences between
ZIFT and In Vitro Fertilization (IVF)

ZIFT and IVF both tend to be favorable treatments for
women who have more severe infertility issues such as
damaged fallopian tubes
ZIFT and IVF both involve embryo culture
ZIFT transfers the fertilized embryo into the fallopian
tube whereas the IVF and embryo transfer procedures
result in the fertilized embryo being placed into the
uterus.
The ZIFT procedure differs from IVF in that the transfer
of embryos into the tube requires an extra surgical
procedure called laparoscopy

PROST: Pronuclear stage Tubal Transfer

Transfer of fertilized egg at pronuclear stage in
the fallopian tube
Few hour before ZIFT
After 14 hr of penetration of the sperm

TEST: Tubal Embryo Stage Transfer
TET: Tubal Embryo Transfer

A multi cell (2, 4 or 8) stage embryo is
transferred in fallopian tube after IVF

ICSI: Intracytoplasmic Sperm Injection

If infertility is due to  impaired sperm motility
or failure of spermatids to differentiate into
sperms
The oocyte can be fertilized by injecting the
sperm or spermatid directly in the its
cytoplasm
The Zygote is developed to 8 or 16 cell stage
and introduced in to uterus

ICSI

Patients with very low sperm numbers
Patients with very low sperm motility
Patients with very high numbers of abnormal sperm
When the sperm have been surgically collected i.e.
taken directly from the epididymis (MESA) or testicles
(TESA)
When there is a high level of antibodies in the semen
When very few eggs have fertilised following
conventional IVF or very few eggs have been collected
at egg pick-up


PESA


PESA or Percutaneous Epididymal Sperm
Aspiration (PESA), does not require a surgical
incision. A small needle is passed directly into
the head of the epididymis through the scrotal
skin and fluid is aspirated. The embryologist
retrieves the sperm cells from the fluid and
prepares them for ICSI.

PESA

MESA


Microsurgical Epididymal Sperm Aspiration
(MESA) is used in conditions like obstructive
azoospermia, involves dissection of the
epididymis under the operating microscope and
incision of a single tubule. Fluid spills from the
Epididymal tubule and pools. This pooled fluid is
then aspirated. Because the epididymis is richly
vascularized, this technique invariably leads to
contamination by blood cells that may affect
sperm fertilizing capacity in vitro

TESE and TESA

TESE or testicular sperm extraction is a
surgical biopsy of the testis whereas TESA or
testicular sperm aspiration is performed by
inserting a needle in the testis and aspirating
fluid and tissue with negative pressure. The
aspirated tissue is then processed in the
embryology laboratory and the sperm cells
extracted are used for ICSI.


How is it done?

All patients receive hormonal stimulation as for
conventional IVF treatment, the differences between IVF
and ICSI occur in the laboratory alone.
After its collection the egg is examined to ensure it is
suitable for ICSI, and a single sperm is injected into the
egg. The eggs are then placed in culture and examined the
following day to see whether they have fertilised normally
A semen sample will need to be provided on the morning
of the egg collection by the partner. However, if the sperm
is to be collected surgically, this will have been performed
earlier and frozen, or collected on the days prior to, or on
the day, of oocyte collection.


Potential risks

One genetic abnormality that is known to be
associated with male infertility is where there are Y-
chromosome defects. If these genes are defective or
parts of them are missing (deletions), sperm
production will be reduced or non-existent.
 If ICSI is used to overcome the very low sperm counts
and a male child is born he will inherit this problem.
Increased miscarriage rates are also seen in
pregnancies resulting from ISCI using surgically
collected sperm when it is used to overcome low
sperm numbers.

APPLICATIONS

Intracytoplasmic sperm injection (ICSI) has enabled many
men with AIDS, paralysis, very low sperm counts, or
abnormal sperm to become fathers, without increasing the
birth defect rate
But potential problems are emerging, based on the fact
that ICSI bypasses “natural sperm selection barriers.”
ICSI is now commonly used on men who make very few or
no sperm by using a needle to extract precursor cells, called
spermatids, from the testes. That is, the infertility does not
arise until the sperm mature.
About 10 percent of infertile men have microdeletions in
the Y chromosome and when they use ICSI, they pass on
the infertility to their sons.

MIF: Microinjection Fallopian Transfer

The embryo so obtained by microinjection
method is transferred into fallopian tube
