Anaerobic Infections: A Case Study in Clinical Microbiology
Erin Graf, Ph.D. & Margaret Powers-Fletcher, Ph.D.
University of Utah and ARUP Laboratories in Salt Lake City,Utah
A Pain in the Neck
Case 1
•
A 16-year old male presents to the
Emergency Department with a fever of
104°F, neck pain and right sided chest
pain.
•
3 days prior he was seen at an urgent
care clinic for sore throat and fever.
–
A rapid Group A Streptococcus
(GAS) test was performed and was
negative.
–
He was sent home with a diagnosis
of viral pharyngitis.
Case 2
•
A 23-year old female presents to the
Emergency Department with a fever of
102.4°F, sore throat, neck pain and
right hip pain.
•
3 and 5 days prior she was seen in the
Emergency Department.
–
No microbiology testing was
ordered.
–
Both times she was sent home with
a diagnosis of viral pharyngitis.
Case 1
•
An X-ray of his chest is performed.
–
Shows multiple nodules in both lungs:
concern for infection
•
Blood cultures are ordered.
Case 2
•
A Computed Tomography (CT) scan of
her pelvis is performed.
–
Shows gas around the hip joint and
thickening of thigh muscle:
concern for
infection.
•
Blood cultures are ordered.
–
Culture of tissue from her right hip is also
ordered.
Laboratory Testing
•
The anaerobic blood culture bottle from both patients
becomes positive.
–
See case study “Of Mice and Men” for description of blood cultures.
•
A Gram stain of the bottle for each patient performed (see
next slide).
•
The blood culture bottle is sub-cultured onto anaerobic agar
media and placed in the anerobic chamber for incubation.
Blood Culture Bottle Gram Stain
Reported as “Pleomorphic Gram negative rods”
Photo Credit: Erin Graf, Ph.D. & Margaret Powers-Fletcher, Ph.D.
Anaerobic Culture Conditions
•
Obligate anaerobes require special incubation conditions as
even small amounts of oxygen can be toxic to growth.
–
An anaerobic glove box incubator can be used for these types of
cultures. The incubator pumps in an anaerobic gas mixture (mostly
nitrogen with a small amount of CO
2
and H
2
) and contains a catalyst
within the incubator space that absorbs O
2
.
–
Smaller laboratories may use air tight boxes or “anaerobic” jars with
catalyst pouches that absorb O
2
.
Anaerobic Glove Box Incubator
Photo Credit: Erin Graf, Ph.D. & Margaret Powers-Fletcher, Ph.D.
Anaerobic Culture Media
•
Four different types of agar and a broth to enhance recovery of anaerobes
were inoculated. The media is described as follows:
–
Brucella Blood Agar - Non-selective media, most anaerobes will grow.
–
PEA (Phenylethyl Alcohol) – Selective media for Gram positive anaerobes.
–
LKV (Laked blood+ Kanamycin+Vancomycin) - Facilitates growth of
Prevotella
and
Bacteroides
sp.
–
BBE (Bacteroides Bile Esculin) - Selective for
Bacteroides fragilis
group.
•
Only strict aerobes are identified further.
–
Aerotolerance of isolates must be tested by subculture and incubation in aerobic
conditions.
Blood Bottle Subculture From Patients 1&2
(After 48 Hours In Anaerobe Chamber)
Brucella Blood Agar
Split plate of LKV on left and BBE on right
•
No growth on PEA.
•
No growth on aerobic subculture
(failed aerotolerance test).
Photo Credit: Erin Graf, Ph.D. & Margaret Powers-Fletcher, Ph.D.
Microbiology Laboratory Results
•
Patient 1&2’s blood cultures (and the hip tissue from patient 2)
grew a single anaerobic bacteria identified as:
Fusobacterium necrophorum
Fusobacterium necrophorum
•
Common flora of the mouth.
•
Opportunistic pathogen.
–
Associated with dental infections, sore throat and peri-tonsillar
abscesses.
–
The most severe association is internal jugular vein thrombosis
leading to bacteremia and dissemination of septic emboli, otherwise
known as “
Lemierre’s syndrome
”.
Lemierre’s Syndrome
•
Case series published by Andrew Lemierre in 1936.
–
Described throat infections followed by sepsis with high mortality rate (before
antibiotics).
•
It is a rare disease, but recent studies suggest incidence may be rising
1, 2
.
•
Patients usually present with sore throat that progresses to neck pain and
often visit the ED multiple times without a diagnosis because there is so
much overlap with more common infections such as viral pharyngitis or
Strep throat.
•
The clinical microbiology laboratory is instrumental as a blood culture
identification of
F. necrophorum
guides diagnosis and follow up.
1
Brazier JS et al.
J Med Micro
2002
2
Ramirez S. et al.
Pediatrics
2003
Patient Outcomes
•
Both patients were diagnosed with Lemierre’s Syndrome after
blood culture identification of
F. necrophorum
.
•
Patient 1 received the intravenous antibiotic
Piperacillin/tazobactam (Zosyn) and recovered quickly.
•
Patient 2 received IV Ampicillin/Sulbactam (Unasyn) and had a
more complicated course requiring multiple debridements of her
infected right hip.
Erin Graf, Ph.D.
Dr. Graf is a second year CPEP fellow at the University of
Utah and ARUP Laboratories in Salt Lake City, Utah. Upon
completion of her fellowship, Dr. Graf will become Assistant
Director of Clinical Microbiology and Virology at the
Children’s Hospital of Philadelphia. Her research interests
include adaptation of next generation sequencing
technologies and metagenomics for diagnosis in the clinical
microbiology laboratory.
Margaret Powers-Fletcher, Ph.D.
Dr. Powers-Fletcher is a first year CPEP fellow at the University of Utah
and ARUP Laboratories in Salt Lake City, UT. She obtained her Ph.D. in
Pathobiology and Molecular Medicine from the University of Cincinnati
College of Medicine. Her thesis work focused on stress response
pathways of the opportunistic fungal pathogen,
Aspergillus fumigatus
.
She has expanded on her interest in medical mycology during her
fellowship, working on advanced fungal diagnostics and susceptibility
testing
.
Photo Credit: Erin Graf, Ph.D. & Margaret Powers-Fletcher, Ph.D.
