ALGOA RECONCILIATION STRATEGY STEERING COMMITTEE 18 April 2018

INTRODUCTION Agenda Items for feedback: 8.1 NMBM water requirements 11.1 NMBM Drought measures and progress with implementation 11.2 WC/WDM at NMBM 11.3 Nooitgedagt Low-level Scheme Implementation and Financing 11.4 Desalination of Sundays River irrigation return flows. 11.5 Re-use of water treated to industrial standards: Fish Water Flats WWTW Coega WWTW 11.6 Groundwater - Coega Kop implementation 11.7 Other groundwater schemes & drought initiatives 11.8 NMBM 60 Ml/d Desalination Scheme 11.9 Marina Sea Salt Desalination Scheme

8.1 NMBM WATER REQUIREMENTS: The water requirements for the NMBM remains in terms of the current licence abstraction from the various resources. 2005 WMP anticipated a water requirement of 390 Ml/d. Projects to support increased demand: NCLLS Phase 3: 70 Ml/d Ground Water Coega: 15-20 Ml/d NRW reduction: 20 Ml/d

NMBM: Potable Water Bulk Supply System Orange / Fish System Orange / Fish System Nooitgedagt Nooitgedagt Groendal Groendal Sand & Bulk Sand & Bulk Groundwater Groundwater Loerie Loerie Churchill & Churchill & Elandsjagt Elandsjagt

11.1 NMBM DROUGHT MEASURES AND PROGRESS WITH IMPLEMENTATION National drought declaration 13 February 2018. R97mil funding received on 28 March 2018. Approval received for the following projects: Coega Kop Wellfields, drilled - 10%, equip 10% Moregrove fault line boreholes, drilled - 50%, equip - 0% Uitenhage boreholes, drilled - 10%, equip - 0% Churchill boreholes, drilled 10%, equip - 0% Health facilities, drilled 20%, equip - 5% Maximising of Nooitgedagt 210Ml water

FINANCIAL IMPLICATIONS OF INTERVENTIONS No 1 2 3 4 5 6 DESCRIPTION COST ESTIMATE Increased Efficiency in Operations and Maintenance Day Zero (6months) and Drought Awareness Campaigns Water Conservation / Water demand Management Nooitgedagt optimisation & temporary treatment Implementation of ground water schemes. Accessing Dead Storage in Dams R22,000,000 R10,000,000 R107,000,000 R21,000,000 R255,000,000 R7,000,000 7 Improvements of the Older Dams System R18,000,000 8 9 Ward Boreholes (30 Wards @ 3 each = 90) Desalination Plants R21,060,000 R1,760,500,000 R2,221,560,000 Totals

HISTORICAL DAM LEVELS Kouga (%) 65.38 66.13 65.8 61.52 55.76 47.37 40.88 34.18 28.38 24.33 20.74 18.36 15.18 14.82 14.18 12.23 12.59 9.77 10.13 40.88 30.75 Impofu (%) 83.93 83.51 82.93 80.76 79.18 76.54 73.98 71.39 69.32 66.98 64.63 61.07 58.30 55.97 53.75 50.90 48.58 45.49 43.30 73.98 30.68 Loerie (%) 33.58 21.05 23.83 20.85 20.26 20.46 32.55 45.51 41.54 34.93 55.98 30.27 29.44 74.12 92.86 88.73 99.14 84.43 84.27 32.55 -51.72 Total (%) 72.58 71.88 71.70 68.14 64.17 58.25 53.53 48.74 44.23 40.24 37.85 34.85 31.99 31.75 31.29 29.47 29.79 27.13 26.19 53.53 27.34 Month Churchill (%) Groendal (%) July 2016 August 2016 September 2016 October 2016 November 2016 December 2016 January 2017 February 2017 March 2017 April 2017 May 2017 June 2017 July 2017 August 2017 September 2017 October 2017 November 2017 December 2017 January 2018 January 2017 % change 63.45 59.83 60.71 55.13 49.57 41.94 35.13 28.40 20.88 15.76 12.35 9.70 7.67 10.01 12.90 13.92 20.79 20.33 18.91 35.13 16.22 80.15 78.09 79.12 76.72 73.71 68.90 65.81 62.80 59.02 56.44 54.81 52.32 49.14 49.66 52.06 52.84 54.21 53.95 51.29 65.81 14.52

OVERALL MONTHLY STORAGE CAPACITIES AVE MONTHLY CONSUMPTION (M /d) 307.91 314.77 305.60 301.73 303.73 303.01 293.53 293.02 288.00 284.02 258.99 267.60 275.56 273.19 281.00 271.16 280.99 287.68 288.33 MONTH AVE. DAM LEVELS %CHANGE July 2016 August 2016 September 2016 October 2016 November 2016 December 2016 January 2017 February 2017 March 2017 April 2017 May 2017 June 2017 July 2017 August 2017 September 2017 October 2017 November 2017 December 2017 January 2018 72.58 71.88 71.70 68.14 64.17 58.25 53.53 48.74 44.23 40.24 37.85 34.85 31.99 31.75 31.29 29.47 29.79 27.13 26.19 - 1.43 - 0.70 - 0.18 - 3.56 - 3.97 - 5.92 - 4.72 - 4.79 - 4.51 - 3.99 - 2.39 - 3.00 - 2.86 - 0.24 - 0.46 - 1.82 - 0.32 - 2.66 - 0.94

20 YEAR RAINFALL DATA AT CHURCHILL DAM

Langkloof catchment Monthly Daily Rain (mm) Data for station [0032507 4] - KAREEDOUW - POL Measured at 08:00 Year JAN FEB MAR APR MAY JUN JUL AUG SEP OCT NOV DEC AVE DIF 2000 2001 2002 2003 2004 2005 2006 2007 2008 2009 2010 2011 2012 2013 2014 2015 2016 2017 2018 AVE MAX MIN 68.5 93.0 22.5 40.0 8.0 10.5 148.7 28.5 43.7 11.0 19.2 49.5 40.0 0.4 10.0 40.5 10.2 8.6 50.0 37.0 148.7 0.4 76.7 40.0 48.7 9.5 41.5 59.1 25.0 34.5 47.5 29.6 63.5 49.1 20.4 19.8 40.0 57.3 30.0 12.0 39.1 76.7 9.5 87.7 44.6 12.5 12.5 34.0 42.5 62.3 205.1 61.5 50.0 39.0 35.8 100.5 29.8 47.0 43.6 50.4 14.2 54.1 205.1 12.5 33.5 55.6 25.3 77.0 31.6 58.1 82.2 28.3 15.4 63.0 65.5 17.7 45.0 32.1 73.5 130.0 75.0 49.8 53.3 130.0 15.4 8.0 5.5 35.5 48.2 45.0 17.2 173.2 110.4 10.0 11.6 8.0 123.5 20.0 64.0 46.5 13.0 6.4 17.8 42.4 173.2 5.5 0.0 23.0 0.0 55.6 21.0 18.6 64.6 80.1 37.4 89.1 59.0 72.0 108.0 110.0 10.0 111.7 17.4 6.6 49.1 111.7 0.0 13.5 78.0 74.6 7.0 24.5 17.5 57.6 21.5 12.3 68.0 21.0 21.2 215.0 13.7 58.9 80.2 99.0 29.0 50.7 215.0 7.0 2.5 62.8 141.3 13.0 10.0 5.2 372.6 58.9 38.7 8.9 38.8 78.0 54.5 79.6 59.8 79.5 37.0 109.6 69.5 372.6 2.5 63.0 89.8 61.8 25.0 104.1 20.5 29.5 4.0 21.0 52.8 13.5 23.0 36.0 2.8 76.3 245.8 53.3 68.0 55.0 245.8 2.8 92.6 17.3 83.5 65.0 115.2 9.0 37.6 47.1 78.5 60.6 85.1 68.9 242.2 128.5 26.0 8.0 31.0 49.5 69.2 242.2 8.0 124.0 68.8 31.0 20.0 13.0 94.0 29.2 107.5 68.1 27.7 27.8 76.0 30.5 84.1 63.0 116.0 84.5 84.0 63.8 124.0 13.0 82.5 35.1 82.7 20.0 146.5 33.0 28.3 163.9 40.3 35.5 96.7 19.3 49.2 10.0 38.8 18.0 30.5 27.8 53.2 163.9 10.0 652.5 613.5 619.4 392.8 594.4 385.2 1110.8 889.8 474.4 507.8 537.1 634.0 961.3 574.8 549.8 943.6 524.7 476.9 16.5 -22.5 -16.6 -243.2 -41.6 -250.8 474.8 253.8 -161.6 -128.2 -98.9 -2.0 325.3 -61.2 -86.2 307.6 -111.3 -159.1 635.7 1110.8 385.2 Doc Ref no: \\fape-document\ec-comm-307-Sales & other marketing

DROUGHT MITIGATIONS Nooitgedagt optimisation & temporary treatment Optimisation: Stanford Rd booster transferring 60 Ml/d. Increase Chelsea Res. zone into Lorraine / Fairview / Charlo. Increase Motherwell Res. Zone into New Brighton / Deal Party. Increase the supply into Uitenhage / KwaNobuhle. Pump station to Despatch Tower. Pump station Chelsea Res to KwaNobuhle

DROUGHT MITIGATIONS Nooitgedagt optimisation & temporary treatment (cont.): Temporary Treatment: Nooitgedagt: 140 Ml/d Treatment & 210 Ml/d Pumping Capacity. 70Ml/d spare pumping capacity. Temporary Treatment Plant at Grassridge Reservoir: Treating of 70 Ml/d spare capacity that can be pumped. Reintroduced 1992 Drought Plan. Pipe interconnections currently being carried out. Sedimentation & disinfection. Water then gravitates to Motherwell pumpstation where it is blended with the remaining 140 from the low level scheme before distribution to customers.

Drought Awareness Campaigns

Drought Awareness Campaigns

11.2 WC/WDM at NMBM 8.1 11.1 11.2 11.3 11.4 11.5 NMBM water requirements NMBM Drought measures and progress with implementation WC/WDM at NMBM Nooitgedagt Low-level Scheme Implementation and Financing Desalination of Sundays River irrigation return flows.

11.2 WC/WDM at NMBM Financial Year Volume Treated (k ) 8,354,000 Revenue Volume (k ) 4,399,666 Revenue Water (%) NRW volume (k ) NRW (%) Real Losses (M ) Real Losses (%) Water Losses (M ) Water Losses (%) Jul-17 Aug-17 8,468,752 4,563,015 53.9% 3,905,737 46.1% 3,101,180 36.6% 3,736,362 44.1% Sep-17 8,429,870 4,929,445 58.5% 3,500,425 41.5% 2,765,417 32.8% 3,331,828 39.5% Oct-17 Nov-17 8,425,978 4,678,833 55.5% 3,747,145 44.5% 2,955,344 35.1% 3,560,656 42.3% Dec-17 8,918,145 4,463,912 50.1% 4,454,233 49.9% 3,548,972 39.8% 4,275,870 47.9% Jan-18 Feb-18 7,836,300 5,559,472 70.9% 2,276,828 29.1% 1,749,517 22.3% 2,107,852 26.9% Annual 67,777,346 38,975,446 8,405,953 4,551,707 54.1% 3,854,246 45.9% 3,021,272 35.9% 3,640,087 43.3% 8,938,348 5,829,396 65.2% 3,108,952 34.8% 2,413,992 27.0% 2,908,424 32.5% 52.7% 57.5% 3,954,334 47.3% 3,143,421 37.6% 3,787,254 45.3% 28,801,900 42.5% 22,699,115 33.5% 27,348,332 40.4%

11.2 WC/WDM at NMBM WC/WDM Focus Areas: Zoning Pressure reduction. Meter replacement. Pipe replacement. Leak repairs: Contractor support. Recruitment of additional plumbers (13 recruited in the last 12 months).

11.3 NOOITGEDAGT LOW-LEVEL SCHEME IMPLEMENTATION AND FINANCING Phase2: 99% complete 140Ml/day available since July 2017. Phase3: 30% complete. 2 Major delays: Health & Safety Non Payment Funded from NT and DWS through Amatola Water as per DORA Anticipated completion date February 2020.

11.4 DESALINATION OF SUNDAYS RIVER IRRIGATION RETURN FLOWS. NMBM: Limited Feasibility study conducted. Volumes of water not enough for long term solution. Water to be transferred to western side of Metro where problem/shortage during droughts exists. Huge financial costs associated ( R500M) Awaiting outcomes of the feasibility study by DWS as agreed in meeting before NMBM can proceed.

11.5 RE-USE OF WATER TREATED TO INDUSTRIAL STANDARDS: Fishwater Flats WWTW: Currently limited industrial re-use being utilised especially in the Deal Party industrial area. 110Ml/day Re-use scheme for Coega IDZ planned. 60Ml/day from FWF WWTW 50Ml/day from Coega WWTW. Coega IDZ EIA approval stipulates Re-use of treated water for Coega industrial use. Estimated cost of R600mil. NMBM does not have these funds available.

11.5 RE-USE OF WATER TREATED TO INDUSTRIAL STANDARDS: Coega WWTW: Feasibility studies completed. Potential plant size of 110Ml/day. Plant required for the ultimate full development of the Coega IDZ. Plant broken into industrial and domestic lines due to effluent variances in quality. Motherwell North development and sewer line to support commissioning of plant. Estimated cost of WWTW is R3bil. NMBM does not have these funds available

11.6 GROUNDWATER - COEGA KOP IMPLEMENTATION Coega Kop aquafer is the best possible groundwater potential. EIA approval for 25Ml/day of groundwater abstraction. Implementation: Phase1 - feasibility study complete. Phase2 - Exploration boreholes drilled. Phase3 - Production borehole contract and relevant pipelines commenced. (R55M). Phase4 - Construction of 20M/day water treatment plant to commence within 2019. (R160M).

11.7 SCHEMES & DROUGHT INITIATIVES OTHER GROUNDWATER Water Augmentation: Churchill Dam Kamesh Reservoir Moregrove Fault Drought Augmentation: Borehole drilling to support swimming pools Provision of non potable water points throughout the NMBM 30 Wards @ 3 boreholes each when required.

11.8 DESALINATION SCHEME NMBM 60 ML/D Feasibility study nearly complete and finalised. Site determined through a Multi disciplinary Criteria Method Planned for construction in phases up to 60Ml/day. Estimated cost of R3bil. NMBM does not have the funding available. Funding and procurement model need assistance.

11.9 DESALINATION SCHEME MARINA SEA SALT Marina Salt approached NMBM with possible potable water provision through their construction of a sea water desalination plant. 26Ml/day potentially available for usage. NMBM currently investigating the contractual and legal implications of an agreement between the two parties, Marina Salt & NMBM. Appears that National Treasury / Minister determination is required.
