Making queues a first class citizen :
Abstracting queues in the UApi

Magnus Karlsson & Björn Töpel, Intel

Problem Statement

2
bind(af_xdp_fd, netdev, queue_id)
Ethtool using queue_id
UAPI

Drivers decide what queue ids to use for what. No standard
Only possible to use pre-configured queues in the driver. No dynamic
creation
XDP and AF_XDP Tx queues invisible to user space
How to get rid of HW queue ids in user space and still be able to create an
AF_XDP socket and direct traffic to it?
Netdev
queues
XDP Tx
queues
AF_XDP Tx &
Rx queues
NIC specific
queues

Basic Requirements

Rx:
 Create a dedicated Rx queue and steer traffic to it
Bridge the gap with a getsockopt to get queue ids for use in ethtool
Tx:
 Multiple users (XDP Tx and AF_XDP Tx) but no traffic steering
Traffic shaping and QoS can be present though
Requirements:
1.
UAPI: create an AF_XDP socket without specifying a HW queue id
2.
Kernel: common module/functionality for allocating, freeing and
naming/enumeration of queues
3.
Drivers: No change to drivers that do not use this feature
4.
UAPI: configuring traffic-steering and QoS to and from this socket
By NIC HW steering or XDP programs
Will focus on 1 – 3 only in this presentation

3
Register, alloc & free

High-Level Proposal: Option 1 – Hide Queues

Driver registers queues with QM (non-netdev vs all?)
Components that need queues can alloc, free and lookup in QM
QM uses new ndo to perform allocs and frees in the driver

4
fd = bind(af_xdp_fd, netdev)
Ethtool using fd (or
opaque queue_id)
UAPI
Queue
module (QM)
XDP Tx
queues
AF_XDP Tx &
Rx queues
Xsk
Ethtool
Driver
Alloc, free & lookup fd -> HW qid
XDP
Register, alloc & free

High-Level Proposal: Option 2 – Expose Queues

Expose queues and required info to user space to make a decision
New queues can be created through ethtool or devlink, if needed
Feed the desired queue id into bind
Flow objects could be added to control steering

5
fd = bind(af_xdp_fd, netdev, queue_id)
Devlink to expose and
manipulate queues
UAPI
Queue
module (QM)
XDP Tx
queues
AF_XDP Tx &
Rx queues
Xsk
Devlink
Driver
Alloc, free & lookup fd -> HW qid
XDP

Reflections / Questions

Is the queue manager uneccesary and a subdev should be used?
Switchdev / tc offload to steer traffic
Extend __rx and __tx structs to implement a queue manager?
Socket, abstracted queue id or extended queue id in user space?
Should netdev use the queue manager too?
XDP Tx and AF_XDP Tx two separate paths. Unify?

AF_XDP ToDo list on xdp-project repo
Need infra in user space to list queues

6

Feedback from the Meeting

Option 2 preferred
Provides advanced configuration and control
Simplified user interface can be provided with libbpf
Start with the queue object, then the flow object
Use devlink to expose and manipulate queues and flows
Keep the current interface to bind()
Queue id can be treated as an opaque

7
