Explore a series of detailed histological slides showcasing the stomach anatomy of different animal species including cats, rabbits, dogs, pigs, sheep, and goats. The images highlight key features such as gastric pits, mucosal layers, chief and parietal cells, proper gastric glands, cardiac and pyloric glands, mucus neck cells, and different regions of the stomach with distinct cellular compositions.


Uploaded on Sep 23, 2024 | 0 Views


Download Presentation

Please find below an Image/Link to download the presentation.

The content on the website is provided AS IS for your information and personal use only. It may not be sold, licensed, or shared on other websites without obtaining consent from the author. Download presentation by click this link. If you encounter any issues during the download, it is possible that the publisher has removed the file from their server.

E N D

Presentation Transcript


  1. Stomach DEMO SLIDE BOX 178 (F-H-143)- Stomach, cat. gastric pits muscularis mucosae stratum compactum lamina propria parietal cells chief (zymogenic) cells tunica muscularis lamina subglandularis submucosa

  2. DEMO SLIDE BOX 178 (F-H-143)- Stomach, cat. CIRCULAR, LONGITUDINAL, CIRCULAR muscularis mucosae (three layers) stratum compactum Muscularis mucosae muscularis mucosae

  3. DEMO SLIDE BOX 178 (F-H-143)- Stomach, cat. Not well defined stratum compactum muscularis mucosae (three layers) chief (zymogenic) cells CIRCULAR, LONGITUDINAL, CIRCULAR parietal cells

  4. Mucus neck cells Fundic stomach, rabbit (toluidine blue) 244 Enteroendocrine cells Chief cells Parietal cell

  5. DEMO SLIDE BOX 51 - Stomach, dog. pyloric gland region. pyloric glands =MUCOUS Gastric pits thickened tunica muscularis = PYLORIC SPHINCTER solitary lymph nodules

  6. DEMO SLIDE BOX 51 - Stomach, dog. PROPER GASTRIC GLANDS HAVE PARIETAL AND CHIEF CELLS PRESENT PROPER GASTRIC GLANDS with PARIETAL AND CHIEF CELLS PRESENT

  7. DEMO SLIDE BOX 163 (P001-H-141,142,144) - Stomach, pig. PROPER PROPER: PARIETAL AND CHIEF CELLS

  8. DEMO SLIDE BOX 163 (P001-H-141,142,144) - Stomach, pig. CARDIAC: GLANDS HAVE CELLS WITH ROUND NUCLEI CARDIAC PYLORIC PROPER PYLORIC: GLANDS HAVE CELLS WITH FLAT NUCLEI the serous-type cells lining in pits and high density of lymphocytes

  9. DEMO SLIDE BOX 164 (O-001-H-142AB) - Abomasum, sheep. spiral folds. PROPER

  10. Slide #179 (GT-1 174)- Abomasum, goat. abomasum not taken from the proper gastric gland region as no chief or partial cells serosa Smooth muscle Of externa

  11. Slide #179 (GT-1 174)- Abomasum, goat. Three layers of tunica muscularis Nerve cell body In submucosa nerve Nerve cell body in tunica muscularis capillary lymphatic venule arteriole muscularis mucosae

  12. Slide # 29. Esophagus, proventriculus, and gizzard, chicken thick tunica muscularis SMOOTH MUSCLE gizzard = ventriculus stratified squamous epithelium simple columnar epithelium The proventricular glands in the lamina propria are the outstanding features of this organ. KOILIN

  13. DEMO SLIDE 177 (831) - Esophagus, proventriculus, and gizzard, chicken gizzard Esophagus proventriculus

  14. DEMO SLIDE BOX 53 - Demo slide # 53a Proventriculus, chicken. lymphatic nodules Side of the gizzard / ventriculus submucosa layer is very thin

  15. DEMO SLIDE BOX 54 - Demo slide # 54a. Gizzard, chicken. gizzard = ventriculus tunica muscularis is very thick and has a diamond appearance simple tubular glands lined with simple cuboidal epithelium Submucosa diamond appearance of tunica muscularis CCT thick koilin, secreted by the glands of the lamina propria. muscularis mucosae is absent

  16. DEMO SLIDE BOX 55 Demo slide #55. Gizzard, chick. muscularis mucosae is absent CCT is stained green (blue) tunica muscularis diamond appearance created by the CCT interlacing the tunica muscularis not seen in developing gizzard better seen in Demo slide 54a below

  17. Slide #40 (CK1 75/98/115B) Proventriculus, chicken. Gizzard Esophagus Proventriculus thick koilin, secreted by the glands

  18. Demo slide # 53b- Gizzard???, chicken Proventriculus

  19. Demo slide 54a thick koilin tunica muscularis diamond appearance created by the CCT interlacing the tunica muscularis not seen in developing gizzard

  20. Slide #92 (Sp 804-102F). Rumen, sheep. Ruminant Forestomach ruminal papilla tunica muscular is arranged in two distinct layers keratinized stratified squamous epithelium mesothelium No muscularis mucosae is present serosa submucosa

  21. DEMO SLIDE BOX 52 - Demo slide # 52. Rumen, cow. papillae The stratified squamous epithelium varies in thickness and the keratin is not readily seen serosa tunica muscularis is composed of two layers of smooth muscle numerous papillae

  22. DEMO Slide #228 (O-001-H-142RU). Rumen, sheep. keratinized stratified squamous epithelium numerous papillae

  23. Slide #90 (1124). Reticulum, steer. large projections are termed reticular crests, while the smaller ones are papillae. muscularis mucosae of the reticulum is incomplete no muscularis mucosae is present in the papillae.

  24. Slide #32 (O-001-H-142-RE). Reticulum, sheep. no muscularis mucosae is present in the shorter papillae. muscularis mucosae muscularis mucosae of the reticulum is incomplete in the reticular crests

  25. Slide #195 (BV 5 101b). Reticulum, cow. muscularis mucosae of the reticulum is incomplete in the reticular crests mesothelium serosa

  26. Slide #191 (GT-1-93). Omasum, goat. mucosal projections of this compartment are quite long ( spider leggy ) and are termed omasal laminae muscularis mucosae is complete and strands of smooth muscle derived from the tunica muscularis are also present in the laminae.

  27. Slide #196 (BV 5 88a). Omasum, cow. serosa tunica muscularis large muscular artery muscularis mucosae is complete nerve omasal laminae CCT unilocular adipose cells

  28. Slide #91 (98-B-OM-8A)- Omasum, cow. muscularis mucosae is complete and strands of smooth muscle derived from the tunica muscularis are also present in the laminae.

  29. Slide #33 (O-001-H-142-RE) - Omasum, sheep. muscularis mucosae is complete omasal laminae
