1. Unit 1: Introduction Comparing Transit Modes Materials developed by K. Watkins, J. LaMondia and C. Brakewood

2. Outline Transit mode definition. Families of transit modes. Comparison of modes and mode selection in the US. Materials developed by K. Watkins, J. LaMondia and C. Brakewood

3. First, lets define the transit were working with TRANSIT MODE DEFINITION Materials developed by K. Watkins, J. LaMondia and C. Brakewood

4. Transit Mode Definition 4 Basic Characteristics: Right-of-Way (ROW) System Technology Types of Service Organizational Oversight Materials developed by K. Watkins, J. LaMondia and C. Brakewood

5. Characteristic 1: Right-of-way Street Transit Semi-rapid Transit Rapid Transit ROW C Mixed Traffic ROW B Physically Separated ROW A Fully controlled Speed of Vehicles Operating & Capital Costs Materials developed by K. Watkins, J. LaMondia and C. Brakewood

6. Examples of ROW Classes Class A: Boston Red Line Class B: Dublin Light Rail Class C: MARTA Bus Materials developed by K. Watkins, J. LaMondia and C. Brakewood

7. Pros and Cons of Rights of Way + + + + Highest performance Electric guided technology High safety Short dwell time ROW A - - - Highest investment cost Rigid alignment Grade-separated stations require land and longer access + Higher performance speed, reliability, capacity, comfort, safety Use of longer vehicles Stronger identity / image Lower per passenger operating cost Can be electrified ROW B + + + + - - - Require space for ROW Higher investment Special signals or control / priority measures ROW C Materials developed by K. Watkins, J. LaMondia and C. Brakewood

8. Characteristic 2: System Technology Support: Vertical contact Guidance: Lateral control Propulsion: Power system Control: Spacing Rubber tire on pavement Steel wheel on rail Vehicle on water, mag lev, etc. Steered by driver Guided by track Diesel engine Electric motor Hybrid Magnetic forces, etc Manual/visual Manual/signals Automatic Materials developed by K. Watkins, J. LaMondia and C. Brakewood

9. Characteristic 3: Types of Service Trip Served Short-haul City transit Regional transit Time of Day Regular Peak Special Stopping Schedule See next slide Materials developed by K. Watkins, J. LaMondia and C. Brakewood

10. Characteristic 3: Types of Service Express Rapid Local Materials developed by K. Watkins, J. LaMondia and C. Brakewood

11. Characteristic 4: Organization Oversight On-Demand Individuals On-Demand Group Image:IMGP1004.JPG Materials developed by K. Watkins, J. LaMondia and C. Brakewood

12. Characteristic 4: Organization Oversight Public Group Materials developed by K. Watkins, J. LaMondia and C. Brakewood

13. Characteristics of Organizational Oversight Characteristic Private On-Demand Public Designation Private Paratransit Transit Availability Owner Public Public Supplier User Carrier Carrier Route determination User (flexible) User User (carrier) Carrier (fixed) Time-schedule determination User (flexible) User User (carrier) Carrier (fixed) Cost-price User absorbs Fixed RATE Fixed FARE Carrier type Individual Group Individual Group Group Modes SOV Carpool Taxi Dial-a-ride Street transit Motorcycle Vanpool Rent Car Jitney Semirapid transit Bicycle Car Share Charter Rapid Transit Walking Bike Share Specialized Materials developed by K. Watkins, J. LaMondia and C. Brakewood

14. This classification of usage leads us to our FAMILIES OF TRANSIT MODES Materials developed by K. Watkins, J. LaMondia and C. Brakewood

15. 4 Major Transit Families Street Transit Right-of-Way (ROW) System Technology Types of Service Rapid Transit Right-of-Way (ROW) System Technology Types of Service Semi-rapid Transit Right-of-Way (ROW) System Technology Types of Service Specialized Transit Right-of-Way (ROW) System Technology Types of Service Materials developed by K. Watkins, J. LaMondia and C. Brakewood

16. Regular Bus Articulated Bus in London (Bendy Bus) Materials developed by K. Watkins, J. LaMondia and C. Brakewood

17. Express Bus GRT Xpress Bus Materials developed by K. Watkins, J. LaMondia and C. Brakewood

18. Trolleybus Trolleybus in Zurich, Switzerland Materials developed by K. Watkins, J. LaMondia and C. Brakewood

19. Streetcars Double Decker Streetcars in Hong Kong Materials developed by K. Watkins, J. LaMondia and C. Brakewood

20. Semi-rapid Transit Modes Bus Rapid Transit Light Rail Transit Automated Guideway Transit Materials developed by K. Watkins, J. LaMondia and C. Brakewood

21. Bus Rapid Transit TransJakarta, Jakarta, Indonesia Materials developed by K. Watkins, J. LaMondia and C. Brakewood

22. Light Rail Transit Dallas Area Regional Transit Materials developed by K. Watkins, J. LaMondia and C. Brakewood

23. Automated Guideway Transit Hartsfield-Jackson Atlanta Airport Materials developed by K. Watkins, J. LaMondia and C. Brakewood

24. Rapid Transit Modes Rail Rapid Transit (Metro) Light Rail Rapid Transit Rubber-tired Rapid Transit Monorail Regional (Commuter) Rail Materials developed by K. Watkins, J. LaMondia and C. Brakewood

25. Rail Rapid Transit (Metro) Atlanta, Georgia Materials developed by K. Watkins, J. LaMondia and C. Brakewood

26. Light Rail Rapid Transit Docklands Light Railway (DLR) in London Materials developed by K. Watkins, J. LaMondia and C. Brakewood

27. Rubber-tired Metro Montreal, Canada Materials developed by K. Watkins, J. LaMondia and C. Brakewood

28. Monorail Kuala Lumpur, Malaysia Materials developed by K. Watkins, J. LaMondia and C. Brakewood

29. Commuter Rail Boston, Massachusetts Materials developed by K. Watkins, J. LaMondia and C. Brakewood

30. Specialized Modes Terrain-Specialized Cable cars Funicular / inclined plane Aerial tram Water-based Ferry Materials developed by K. Watkins, J. LaMondia and C. Brakewood

31. Cable Car San Francisco, CA Materials developed by K. Watkins, J. LaMondia and C. Brakewood

32. Funicular / Inclined Plane Pittsburgh, PA Materials developed by K. Watkins, J. LaMondia and C. Brakewood

33. Aerial Tram Image:Roosevelt Island Tramway.jpg Roosevelt Island, NY Materials developed by K. Watkins, J. LaMondia and C. Brakewood

34. Ferrys Seattle, Washington Seattle, WA Materials developed by K. Watkins, J. LaMondia and C. Brakewood

35. COMPARISON OF MODES & MODE SELECTION IN THE USA Materials developed by K. Watkins, J. LaMondia and C. Brakewood

36. 2010 APTA Modal Facts # Systems 1,206 Passenger Trips 5,256 mil Passenger Miles 21,013 mil 10,874 mil 1,494 mil 16,407 mil 2,173 mil Bus Commuter Rail Paratransit Heavy Rail Light Rail Trolleybus Monorail Inclined Plane Publico Aerial Tramway Automated Guideway Transit Cable Car Ferryboat 28 464 mil 190 mil 3,550 mil 457 mil 99 mil 6,741 15 35 5 2 4 1 2 6 1 51 159 mil 203 mil 1,893 mil Materials developed by K. Watkins, J. LaMondia and C. Brakewood

37. Largest US Agencies by Mode Largest Heavy Rail Agencies (Unlinked Pax Trips): Largest Bus Agencies (Unlinked Pax Trips): 1. NYCT 2. LA County MTA 3. CTA (4 for pax miles) 4. SEPTA (5 for pax miles) 5. NJ Transit (3 for pax miles) 1. NYCT 2. WMATA 3. CTA (4 for pax miles) 4. MBTA (6 for pax miles) 5. BART (3 for pax miles) Materials developed by K. Watkins, J. LaMondia and C. Brakewood

38. Largest US Agencies by Mode Largest Commuter Rail (Unlinked Pax Trips): Largest Light Rail (Unlinked Pax Trips): 1. MBTA 2. MUNI (San Fran) 3. LA County MTA 4. TriMet (Portland) 5. San Diego 1. Long Island Railroad 2. NJ Transit 3. MetroNorth 4. Metra (Chicago) 5. MBTA Materials developed by K. Watkins, J. LaMondia and C. Brakewood

39. New Diversity of Transit Modes More rail being constructed; since 1970: 7 new heavy rail systems constructed (BART, WMATA, MARTA, Baltimore, Miami, LA, San Juan) Nearly 20 cities opened or are constructing new LRT systems Resurgence in streetcars and tramways after decades of elimination Buses traditionally non-priority Buses carry 60% of transit passenger trips Mostly transit captive BRT is changing this Materials developed by K. Watkins, J. LaMondia and C. Brakewood

40. Mode Selection Systems Approach: Cities require multiple modes integrated and working together for the highest ridership Choice of modes depends on many factors, including life cycle costs, LOS, economy, impact on surrounding, passenger attraction and livability Materials developed by K. Watkins, J. LaMondia and C. Brakewood

41. DISCUSSION TOPIC Google Bus in San Fransisco (e.g. Private Bus Services) Function Family Characteristics Pros & Cons Materials developed by K. Watkins, J. LaMondia and C. Brakewood

42. Conclusions Understanding the differences in transit modes is critical Cities often require multiple modes integrated and working together for high ridership Make the mode fit the service instead of the service fit the mode rest of course focuses on service Materials developed by K. Watkins, J. LaMondia and C. Brakewood

43. Reference Materials in this lecture were taken from: Vukan Vuchic, Urban Transit Operations, Planning and Economics (2005). Dickens, Matthew, John Neff, and Darnell Grisby. "APTA 2012 Public Transportation Fact Book." (2012). Materials developed by K. Watkins, J. LaMondia and C. Brakewood
