Training Requirements for Walking & Working Surfaces in Construction Industry

Identifying key points within the 29 CFR 1926 Standards related to walking/working surfaces, addressing common issues, providing mitigation strategies, and informing employees about employer obligations. The training agenda covers requirements for ladders, stairways, fall protection systems, and retraining highlights the importance of updating skills and maintaining knowledge for long-term productivity and mistake reduction.

• Construction safety
• Workplace training
• Fall protection
• Regulatory compliance
• Employee education

eamon Follow

Uploaded on Jul 19, 2024 | 0 Views

Download Presentation

Please find below an Image/Link to download the presentation.

The content on the website is provided AS IS for your information and personal use only. It may not be sold, licensed, or shared on other websites without obtaining consent from the author. Download presentation by click this link. If you encounter any issues during the download, it is possible that the publisher has removed the file from their server.

Presentation Transcript

1. Walking Working Surfaces Bassam Albukhaytan, Dominic Guevara, Benjamin Klebs, Maggie Krawczyk, Jonte Lane

2. Objectives To identify key points within the 29 CFR 1926 Standards involving walking/working surfaces To address common issues within each standard along with mitigation strategies To inform employees on employer obligations within the standards

3. Agenda of Training 1926.1060 - Training Requirements 1926.1051 - General 1926.1052 - Stairways 1926.1053 - Ladders 1926 - Appendix A

4. 1926.1060 - Training Requirements Employer shall provide a training program for employees using ladders and stairways Program should enable employees to recognize hazards with stairways/ladders Train employees on procedures to be followed to minimize hazards

5. 1926.1060 - Training Requirements 1926.1060(a)(1) Nature of fall hazards in the work area Procedures for building, maintaining, and disassembling the fall protection system used Proper construction, use, placement, and care in handling stairways/ladders

6. 1926.1060 - Training Requirements 1926.1060(a)(1)- Continued Maximum intended load-carrying capacities of ladders Standards contained in this subpart

7. 1926.1060 - Training Requirements 1926.1060(b) Retraining shall be provided for each employee as necessary so that the employee maintains the understanding and knowledge acquired through compliance with this section

8. 1926.1060 - Training Requirements Why retrain? Helps update skills Increase long term productivity Helps reduce mistakes

9. 1926.1051- General Requirements This standard requires: A ladder to be provided if there is a change in elevation more than 48 inches The passage for movement to be kept clear at all times Employers to provide and install stairway and ladder fall protection systems within compliance

10. 1926.1051- General Requirements Common issues Fall protection systems are not deployed by every employee Stairways missing handrails Personal Fall Arrest Systems are not used properly by employee

11. 1926.1051- General Requirements Mitigation Strategies Provide Personal Fall Arrest Systems to employees working at height Proper training Provide guardrails and handrails to any platform or staircase

12. 1926.1052 - Stairways This standard requires Stairs must be installed at 30 - 50 Uniform riser height and tread depth, free of projection hazards Extended platform where door/gate swings into, effective width at least 20

13. Figure 1: Stairway angle limits for OSHA (2016)

14. 1926.1052 - Stairways Requirements Cont. Over 4 steps or 30 vertical rise, at least 1 handrail Stair rails along sides, at least 36 above tread, no greater than 37 if used as handrail

15. 1926.1052 - Stairways Requirements Cont. Mid rail, screen/mesh, or vertical member required Mid rails must be midway, screen/mesh must entirely cover opening, vertical members 19 apart

16. 1926.1052 - Stairways Requirements Cont. Handrails/stair rails must withstand 200 lb force Handrail height range 30 - 37 Stair rails/handrails must be surfaced and installed to allow thorough grasping, be hazard free, Unprotected sides of landings must be guarded

17. 1926.1052 - Stairways Common Issues Effective width of platforms not reaching 20 when door/gate open Mid rails not midway Hand railing not providing adequate handhold

18. 1926.1052 - Stairways Mitigation Strategies Competent installation crew, inspected by safety professional Test rails prior to purchase, have safety professional inspect selection

19. 1926.1053 - Ladders This standard requires: Each portable ladder should hold at least four times the maximum intended load.(a)(1)(i) Ladder rungs, cleats, and steps shall be parallel, level, and uniformly spaced when the ladder is in position for use.(a)(2)

20. 1926.1053 - Ladders Common Issues: Worn out rungs Using ladders on uneven surfaces Climbing ladders with loads in hands Absence of ladder safety devices

21. 1926.1053 - Ladders Mitigation Strategies: Cover rungs with slip-resistant material Use ladders only on flat service Climb ladders with at least one hand Do not carry load while climbing Install cages for ladders about 24 ft.

22. 1926.1053 - Ladders Figure 2: Portable Ladder Safety for State of California Department of Industrial Relations (2019)

23. 1926 - Ladders - Subpart X App A Appendix A brings more stringent standards with ladder loading and strength requirements of 1926.1053(a)(1). Manufactured portable wood ladders: ANSI A14.1-1982 Manufactured portable metal ladders: ANSI A14.2-1982 Manufactured fixed ladders: ANSI A14.3-1984 Job-made ladders: ANSI A14.4-1979 Plastic ladders: ANSI A14.5-1982

24. References OSHA. (1990). Training Requirements (Standard No. 1926.1060). Retrieved from https://www.osha.gov/laws- regs/regulations/standardnumber/1926/1926.1060 OSHA. (1990) General Requirements (Standard No.1926.1051). Retrieved from https://www.osha.gov/laws- regs/regulations/standardnumber/1926/1926.1051 OSHA. (1991). Stairways and Ladders (Standard No. 1926.1052). Retrieved from https://www.osha.gov/laws- regs/regulations/standardnumber/1926/1926.1052 OSHA. (2014). Ladders (Standard No. 1926.1053). Retrieved from https://www.osha.gov/laws- regs/regulations/standardnumber/1926/1926.1053 OSHA. (1990). Ladders (Standard No. 1926 Subpart X App A) Retrieved from https://www.osha.gov/laws- regs/regulations/standardnumber/1926/1926SubpartXAppA

25. References Cont. Figure 1 - OSHA. (2016). Stairway angle limit. Occupational Safety and Health Administration. [Graphic]. Reprinted from https://www.osha.gov/laws-regs/regulations/standardnumber/1910/1910.25 Figure 2 - State of California Department of Industrial Relations. (2019). Portable Ladder Safety. State of California Department of Industrial Relations. [Graphic] Redistributed from https://www.dir.ca.gov/dosh/etools/08-001/regs.htm
