Thermoelectric Module with PID Control Simulation


Lumped Thermoelectric Module with
PID control





Motivation

Thermoelectric elements are often used to cool or heat electronic components to a
desired temperature.
This model illustrates how to setup a lumped thermal system containing a
thermoelectric element and computes the nonisothermal flow around its heat sink.
A stationary simulation is first performed to evaluate the capabilities of the
thermoelectric module.
A transient simulation is then carried using the PID controller add-in to stabilize the
temperature to a defined value, and study the response of the system.

Model Definition

An electronic device is connected to
a thermoelectric module (TEM) via a
contact element. On the other side,
the TEM is connected to a heat sink.
A nonisothermal fluid flow is
considered around the heat sink
.
The TEM is modeled with the
Lumped Thermal System physics
interface.
The heat sink fins are modeled as
shells.

Model geometry – Only half of the actual geometry is shown

Fluid domain

Heat sink fins

Heat sink base

Thermoelectric
module

Contact element

Electronic device

Model Definition

The a
ir velocity is set to 0.5 m/s at
the inlet.
Side and top boundaries of the fluid
domain are slip walls, while the
bottom one is a no slip wall.
The electronic device generates 4 W
of heat power.
The TEM has a linear behavior:
Maximum current: 4 A
Maximum heat rate: 40 W
Maximum temperature difference: 70°C
Resistance: 2
Ω

Model boundary conditions – Only half of the actual geometry is shown

Outlet

Interior walls

Thermoelectric
module

P = 4 W

Slip wall

Wall

U
0
 = 0.5 m/s

Results

A parametric sweep of the current
through the TEM is performed in a
stationary study.
The behavior of the system deviates
from the linear TEM model because
the heat sink also exchanges heat
with the exterior air.
For a current of 2 A, the device
temperature is about 6.5°C, the heat
rate of the TEM about 8 W and the
temperature difference 28°C.

Results of the stationary study – Heat rate and temperature of the system for different
intensities

Results

In a second (transient) study, a PID
controller is added to the model to
stabilize the temperature of the
electronic device to 6.5°C.
The device is initially at ambient
temperature, and starts generating
heat after 10 min. The response of
the system is evaluated.
The steady state is reached after 1 h.
The temperature of the device is
quickly stabilized.
After 1 h, the temperature difference
is 28°C and the heat rate is 8 W, as
predicted by the stationary study.

Results of the transient study – Heat rate and temperature of the system over time

Results

At steady state, the current through
the TEM is 2 A.
The stationary computation
accurately predicts the steady-state
solution, while the transient
computation allows to study the
response of the system.

Results of the transient study – Heat rate and intensity through the system over time
