Statistical Distributions in Physics
Physics 736: Experimental Methods
in Nuclear, Particle, and Astro Physics
Prof. Vandenbroucke, April 8, 2015
Announcements
•
Problem Set 8 due Thursday 5pm
•
No problem set next week: work on projects
•
No office hours today
•
Read Barlow 5.2-5.3 for Mon (Apr 13)
•
Read Barlow 5.4-6.4 for Wed (Apr 15)
•
Three options for when to give your final project presentation
–
Monday May 4 in class
–
Wednesday May 6 in class
–
Wednesday May 13 in final exam slot (12:25-2:25pm)
–
Everyone is expected to attend all classes and the final exam time
to see the presentations
•
By Monday (Apr 13) 5pm, please send me a ranked list of these dates
to specify your preferences (if working in a group, submit a single list)
•
Binomial
: probability of achieving
r
successes given
n
Bernoulli trials each with
probability of success
p
•
Poisson
: probability of achieving
r
successes given an expected number of successes
λ
(note:
λ
can be any real value, including much less than 1 and much greater than 1)
•
Gaussian
: limiting form of Poisson for
λ >> 1
, setting
λ = µ
= σ
2
•
Important subtlety: binomial and Poisson distributions are discrete; Gaussian
distribution is continuous
•
Although
x
represents the number of events, it is continuous in the Gaussian PDF
•
Example: to find the probability of achieving 13 events, integrate from 12.5 to 13.5
Connections between binomial,
Poisson, Gaussian distributions
PDF of the Gaussian distribution
•
It is often useful to perform a change of variables from an
arbitrary Gaussian to the standard Gaussian (
µ = 0, σ = 1
)
CDF of the Gaussian distribution
•
CDF is often easier to work with than PDF (esp. after transforming to standard Gaussian)
•
To determine probability of random variable lying between
a
and
b
, can either integrate PDF
from
a
to
b
or take difference between CDF evaluated at
b
and CDF evaluated at
a
•
CDF is given by error function: can look up values in tables or use computer to evaluate it
•
By definition,
error function
is integral of Gaussian distribution (for
µ=0, σ=1/sqrt(2)
)
from –x to +x:
So CDF =
Gaussian distribution
•
These numbers come up very often: memorize the 1 sigma, 2 sigma, 3 sigma probabilities!
Example
•
During a meteor shower, meteors fall at a rate of 15.7 per hour. What
is the probability of observing fewer than 5 in a given interval of 30
minutes?
•
P(k < 5)
= P(0) + P(1) + P(2) + P(3) + P(4)
=
10.9%
•
How do we answer the same question using the Gaussian
approximation?
•
λ = µ = 7.85, so σ = sqrt(7.85) = 2.80
•
We need to integrate the Gaussian PDF from -∞ to 4.5
•
(x-µ)/σ = (4.5-7.85)/2.80 = -1.196
•
So we can simply calculate CDF = 0.5 + 0.5*erf(-1.196/sqrt(2))
•
Answer:
11.6%
•
Is the Poisson or Gaussian result more accurate?
Central limit theorem
•
Given
N
independent
random variables
x
i
, each with any arbitrary
distribution function, not necessarily all the same function
•
Each random variable has mean
µ
i
and variance
V
i
•
Let
X
(another random variable) be the sum of
x
i
•
Central Limit Theorem:
1.
Expectation value of
X
is sum of
µ
i
2.
Variance of
X
is sum of
V
i
(Bienaymé Formula)
3.
Random variable
X
is Gaussian distributed in the limit of large
N
(even though
x
i
are arbitrarily distributed)
•
This is why Gaussian distributions are so ubiquitous: arises any time many
independent effects sum together, no matter what the shape of the
independent effects
•
This is why measurement errors are often Gaussian: several independent
effects sum together
The uniform distribution
•
A
uniform
random variable is defined by a PDF that is constant over the
range of the variable
•
Variable can be either continuous or discrete
•
Any particular sample population drawn from a uniform distribution will be
non-uniform due to statistical fluctuations
•
In one dimension, the uniform distribution is defined by two parameters,
a
and
b
•
P(x) = 1/(b-a)
for
x
between
a
and b
;
0 elsewhere
•
The “standard” uniform distribution has
a = 0
and b = 1
•
Mean is
(a+b)/2
•
Variance is
(b-a)
2
/12
•
Uniform distributions can also be defined in higher dimensions, potentially
within a restricted range (e.g. points distributed uniformly within a circle)
•
Example: event times of a Poisson process are distributed uniformly
•
Example: quantization error
–
If a measurement system works by quantizing a continuous value (e.g. analog
to digital converters, wire chamber trackers, silicon trackers) and the resolution
(step size) is much less than the range of values being quantized, then the
measurement error is uniformly distributed
Poisson process
–
Event times follow a uniform distribution
–
Event counts in any particular time interval follow a Poisson
distribution
–
Times between successive events follow an exponential
distribution
–
If the number of counts in a given time interval is large (> ~10),
this can be approximated by a Gaussian distribution
Poisson distribution beyond Poisson
processes
•
Poisson
process
refers specifically to the time dimension
•
Counting discrete events also occurs in a broader range of contexts
•
In any situation in which discrete events are independent of one another and
are counted, the number of measured counts follows a Poisson distribution
•
As in the specific case of a Poisson process, the Poisson distribution in general
can be well approximated by the Gaussian distribution in the limit of large (>
~10) counts
Poisson distribution arising from
binning continuous variables
•
Poisson distribution applies to wide range of applications involving integer
counting
•
Variable can be intrinsically discrete and countable
•
Or, variable can be continuous but then binned (placed in a histogram)
•
Once it is binned, the counts per bin follows a Poisson distribution (if values are
independent of one another)
•
Each bin is a counting experiment following a Poisson distribution
•
As usual, in the limit of large counts per bin the distribution is Gaussian
•
True for 1D, 2D, ND histograms
•
1D Example: heights of trees
•
2D Example: photon counts in a CCD
Two experimental situations involving
Gaussian distribution
•
Situation 1: continuous quantity x is measured one or more times
–
True value is
x
t
–
Measurement error/uncertainty is
σ
x
–
x
t
and σ
x
are independent of one another
–
If unbiased (no systematic error), measurements follow a Gaussian distribution with
parameters
μ = x
t
and
σ
=
σ
x
–
Given a single measurement result
x
1
with uncertainty
σ
x
, we can invert this: the PDF for
the true value
x
t
is described by a Gaussian distribution with parameters
x
1
,
σ
x
•
Situation 2: counting experiment
–
In a given sample of discrete objects (simple counting like light bulb example), time
interval (Poisson process), or histogram bin (binning of continuous quantity), the count
of events follows a Poisson distribution
–
If the number of counts is large (> ~10), this can be approximated by a Gaussian
distribution
–
In this context,
μ
and
σ
are not independent of one another:
μ = σ
2
because the
Poisson distribution has mean = variance = λ and in the Gaussian limit λ =
μ
