Railway Wagon/Coach Tracking Solution Overview
This solution involves RFID technology to track railway wagons and coaches in real-time, ensuring operational efficiency and security. RFID tags are placed on each wagon or coach, which are read by RFID readers installed along the railway tracks. Any mismatch in data triggers alerts such as hooter alarms and email notifications. The system provides features like live tracking, automated identification, and detailed reporting to enhance logistical planning and network utilization.
Download Presentation
Please find below an Image/Link to download the presentation.
The content on the website is provided AS IS for your information and personal use only. It may not be sold, licensed, or shared on other websites without obtaining consent from the author. Download presentation by click this link. If you encounter any issues during the download, it is possible that the publisher has removed the file from their server.
E N D
Presentation Transcript
Railway Wagon / Coach Tracking Solution 1
2 Overall Solution RFID Reader & Antenna will be fixed at railway Track left and right side of the track. RFID tags will be pasted in each wagons and each coach When train will passes in differents station our Raeder will read RFID Tags and same tag id will send to the centralize server . Data will send to the server for the matching tags otherwise system will display error message and send a mail to the particular railway station master. Hooter and tower Light will automatically started for Mismatch data.
3 Solution Architecture RFID Reader Antenna 3 Antenna 1 Antenna 0 Antenna 4 RFID Server
Site Layout Top View. Ant 0 Ant 2 Ant 1 Ant 3 RFID Reader box 4
Purpose Government wanted to increase operational efficiency by tracking the movements of its freight trains from the border and station throughout the entire rail network. For this purpose, the company opted for a Stallion RFID solution which was installed by the system integrator Trinity System with the help of Alien RFID Reader. Train carried out a test phase to lay the foundation for real-time tracking of some 4,000 railway carriages.
7 Railway Tracking System Features Wagon or Coach tracking Application will replace the manual security checking. Auto Identification of Wagon/ Coach using RFID Tag Live Tracking of runing coach at different stations. Will able to send mail / Hooter alarm in case of mismatch Wagon / Coach. Will provide the Monthly and Daily basis report .
8 Report Features EPC detail of tag for different wagons / Coach Individual Tag count of each RFID tagged wagon Date and time of tag reading
Result The Stallion solution fully met the requirements of the customer. Real-time data can be generated, analysed,filtered and also cached in the event of a network failure. Using intelligent Stallion RFID software, planning an process security decisions can now be made more quickly and reliably. The rail company can now look forward to optimised logistical planning and, as a result of this, an enhanced overview of the network utilisation and improved calculation of the service life for the leased carriages.
For your wathcing Thank You THANK Y
