Preferential Voting in Elections
ELECTION NIGHT
CITS1001
Software development
•
Understand the problem
•
Understand the solution
•
Structure the solution
•
Implement the solution
•
Test the solution
•
And then go around again…
2
Preferential voting in the Australian House of Reps
•
An election has
•
M
candidates (we will use five candidates
ABCDE
in examples)
•
N
formal votes
•
One winner, who needs
N/2+1
votes to triumph
•
Each voter returns a list of preferences for all candidates
•
e.g.
CAEDB
•
But not
CAE
or
CAEDA
or
CAXEDB
or …
•
http://www.aec.gov.au/Voting/counting/hor_count.htm
3
The count
•
Discard informal votes
•
Allocate each formal vote to its first preference candidate
•
Then in each round of the count
•
If the leading candidate has enough votes,
•
Declare them the winner
•
Otherwise,
•
Identify the candidate
X
with the fewest votes
•
Redistribute each of
X
’s votes to its highest-ranked surviving candidate
•
Eliminate
X
4
An example
•
100 votes: 12 informal, and 88 formal
•
88/2+1 votes = 45 required to win
•
After the initial distribution
•
A
11,
B
14,
C
29,
D
25,
E
9
•
No winner yet, so
E
is eliminated in Round 1
•
e.g. vote
EABDC
would be transferred to
A
•
A
17,
B
16,
C
29,
D
26
•
No winner yet, so
B
is eliminated in Round 2
•
e.g.
BEDAC
goes to
D
and
EBADC
goes to
A
•
A
22,
C
31,
D
35
•
No winner yet, so
A
is eliminated in Round 3
•
C
47,
D
41
•
C
has enough votes to be declared the winner
5
What types of entities do we have?
•
Votes
•
Each vote is an expression of a voter’s preferences
•
Candidates
•
Each candidate collects votes until they either win or are eliminated
•
Elections
•
Each election represents one constituency
6
The
Vote
class
•
What is the state of a
Vote
?
•
The list of preferences for surviving candidates
•
What inputs does the constructor need?
•
The voter’s original list of preferences
•
What accessor methods does
Vote
provide?
•
Who the
Vote
is currently for:
public char getFirstPreference(String losers)
•
What other methods does
Vote
provide?
•
A test for whether the
Vote
is formal:
public boolean isFormal(String candidates)
7
The
Candidate
class
•
What is the state of a
Candidate
?
•
Their name, and their current pile of
Vote
s
•
What inputs does the constructor need?
•
Their name
•
What accessor methods does
Candidate
provide?
•
getName()
,
getVotes()
,
getCount()
•
What other methods does
Candidate
provide?
•
A way of adding votes to the pile:
public void addVotes(ArrayList<Vote> vs, String losers)
•
A test for whether the candidate has won:
public boolean isWinner(int noOfVotes)
8
The
Election
class
•
What is the state of an
Election
?
•
A pile of
Vote
s for each surviving
Candidate
•
What inputs does the constructor need?
•
Where to get the voting papers and the candidates’ names from
•
What accessor methods does
Election
provide?
•
None – “top-level” class
•
Although there could be a higher class with a collection of
Election
s
•
What other methods does
Election
provide?
•
The constructor could do the initial distribution
•
A method to perform one round of the count
•
Probably several private methods to structure the code
9
Implementation – Class Diagram
10
10
Implementation questions –
Vote
•
What type should the list of preferences be?
•
If the candidates’ names are just one
char
each,
a simple
String
will do
•
Otherwise a
String[]
or an
ArrayList<String>
,
depending on…
•
Should we delete the names of eliminated candidates,
or just ignore them?
•
We could ignore them when looking for the next preference
•
We could delete them as needed
•
We could delete all mentions of
c
at the time they are
eliminated
11
11
Implementation questions –
Candidate
•
What type should the pile of
Vote
s be?
•
For most candidates, the pile will grow during the count
•
So an
ArrayList<Vote>
is best
12
12
Implementation questions –
Election
•
What type should the pile of
Candidate
s be?
•
Again, an
ArrayList<Candidate>
is best
•
Should we delete eliminated
Candidate
s,
or just ignore them?
•
We can use multiple constructors for testing:
public Election(String candidates, String votes)
{…}public Election(String votes)
{this(“candidates.txt”, votes);}public Election()
{this(“votes.txt”);}13
13
Take a look at one solution
•
Available on the lectures page
•
Along with four sample elections
•
[small, no contest, medium, large] [candidates, votes, results]
•
SC.txt, SV.txt, SR.txt
•
NC.txt, NV.txt, NR.txt
•
MC.txt, MV.txt, MR.txt
•
LC.txt, LV.txt, LR.txt
14
14
