Challenges in Reengineering Voting Processes: Equal Treatment of Multiple Channels in Legally Binding Elections
Challenges to Voting Processes Reengineering:
Equal Treatment of Multiple Channels in Legally
Binding Elections
Priit Vinkel
, PhD
Head of
State Electoral Office of Estonia
Priit.Vinkel@valimised.ee
CoDE
Cost of Democratic Elections
Tallinn University of Technology
Ragnar Nurkse Department of Innovation and Governance
Prof. Dr. Robert Krimmer, Dr. David Duenas, Iuliia Krivonosova
Dr. Priit Vinkel, Arne Koitm
ä
e
Outline
•
Theoretical background;
•
Research design and methodology;
•
Case-study;
•
Data;
•
Discussion.
Theoretical background
Decline of voter turnout in established democracies around the
world (
Lopez Pintor and Gratschew, 2002; Lijphart 1998):
governments adding alternative means of voting, including
Internet and postal voting (
Kersting and Baldersheim 2004,
Krimmer, Triessnig, and Volkamer 2007)
;
complex multi-channel elections.
Multi-channel elections
•
more than one voting channel is available to a voter.
Alternative voting channels:
•
Postal voting;
•
Advance voting;
•
Voting at diplomatic missions;
•
Home voting;
•
Proxy voting;
•
Internet-voting.
Multi-channel elections
•
increase the complexity for the election administration;
•
the increase of complexity requires business process
reengineering of electoral processes;
•
and it involves analyzing the cost of introducing new voting
channels
(Xenakis 2004, Krimmer, Triessnig, and Volkamer 2007).
Addition of a new voting channel
Times of
“short-term experiments and permanent reforms”
in the
field of elections
(James 2011, 37)
Voters’ convenience;
Turnout
(Gronke, Galanes-Rosenbaum, and Miller 2007);
Addition of a new voting channel
Times of
“short-term experiments and permanent reforms”
in the
field of elections
(James 2011, 37)
Voters’ convenience;
Turnout
(Gronke, Galanes-Rosenbaum, and Miller 2007);
Increase in complexity;
Impact on quality of election administration;
Increase in costs of elections
(Montjoy 2010; Choi and Kim 2012;
Gibson 2001).
Aim of CoDE project
Empirical research into:
a) how new voting channels are being undertaken;
b) how they influence and change the voting process and
governance;
c) how the adding/removing of Internet voting and other channels
impacts overall costs
Research objective
•
What are the aims for introducing the concept of additional
voting channels to existing election processes?
•
How can business process reengineering be used and extended
from single-channel elections to multi-channel elections and
what cost categories have to be included for activity-based
costing for elections?
•
How do business processes look like for elections administering
multiple voting channels, such as polling station-based (paper)
voting, postal voting and Internet voting? Is it possible to design
a unified business process for multi-channel elections?
•
How can activity-based costing be applied to elections on the
basis of a (unified) business process models?
•
Would election administrators make different choices in regard
to introducing voting channels if they knew about the most cost-
effective combinations of channels (e.g. in terms of work and
cost)?
Research design
•
interdisciplinary theoretical framework incl. (1) election
administration, (2) business process reengineering and (3)
activity-based costing;
•
an exploratory case study (Yin 2003) in order to conduct an in-
depth study using multiple sources of evidence in its real-life
context;
•
a holistic multiple case study approach
: cases will be contrasted
and the goal is to match patterns using triangulation of the
findings and examine whether they point to generalizable and
converging conclusions (Kluge, 2000; Yin, 2003) to use them for
input into a more general reference model.
Case selection
Theoretical sampling approach (Yin, 2003):
•
we took into account the style of government (confederation,
federation, unitary), different kinds of supporting information
systems (de/centralized) and additional voting channels
(Internet voting, postal voting, both);
•
Estonia is selected as the ideal first case (Unitary, Centralized,
Internet voting) and as a critical case due to its electoral system
tradition and conditions.
Estonia
•
the first country in hosting an online binding election in 2005
(Springall et al, 2014);
•
a
“front-runner country in matters of e-governance with its
universal electronic key to all e-services (e-ID), digital
signature, e-Health, e-taxboard, etc”.
(Madise and Vinkel,
2014);
•
multiple international research projects on Estonian e-voting
system: its adoption by citizens (Alvarez et al, 2009), its impact
on the electoral turnout (Vassil and Weber, 2011) or the internal
issues of e-voting processes (Maaten and Hall, 2008; Al-Ameen
and Talab, 2013), amongst others.
Sources of information
•
legal documents (including explanatory notes to draft acts);
•
impact assessments (including internal instructions for the
development of the electoral process, like Election Handbooks
for Electoral Management Bodies);
•
semi-structured interviews conducted with decision makers,
administrative personnel and other stakeholders (election
administrators, legislative committee in parliament, courts,
NGOs, academics, journalists, etc.);
•
election on-site observation and the recordings of the setting of
the e-voting system;
•
electoral budgets provided by local institutions;
•
log files from the e-voting system;
•
academic papers and media discussions on the issue.
Data analysis
•
In the considered time frame of the electoral process, 31
processes including 177 activities are taking place in Estonia;
•
Due to the high number of activities and for the purpose of
comparison, we make a decision to focus only on the processes
which are run differently for voting channels as it will allow us to
make comparisons between voting channels:
1.
Organization of voting place;
2.
Voter identification;
3.
Processing of votes;
4.
Counting of votes.
Data analysis
1. Model for every process (BPMNs);
2. Activity-Based Costing analysis;
3. For final calculation of the cost per ballot, determine: the
attributed time for the different activities; the labor costs; the
practical capacities and the indirect costs;
4. Then, allocate costs to the corresponding voting channels,
calculate cost per ballot and detect the potential cost-raisers for
the electoral system hides;
5. Develop possible solutions for process improvement in terms of
cost-efficiency.
Conclusions
•
First results based on the Estonian case-work to be published in
fall this year
•
The outcome will give a handy tool for EMBs/policy planners
worldwide
by providing incentives for resource optimization and
process improvement
•
The framework allows for
generally
comparable results and the
methodology and model are applicable to different contexts.
•
However, the numerical results are
case and
context-dependent
and should not be generalized
Q&A
Thank You!
Priit.Vinkel@valimised.ee
Contact at the TUT
Prof Robert Krimmer
Robert.Krimmer@ttu.ee
Cost pools
•
Labour Cost
•
Printing Cost
•
Stationery Cost
•
Transportation Cost
•
Rental Cost
•
Equipment Cost
•
Depreciation Cost
TD ABC model for multichannel elections
1.
Process modeling/process mapping for the considered time frame (for instance,
with the help of Business Process Model and Notation – BPMN).
2.
Compliment these findings with interviews and on-site observations. Based on it,
create a list of activities.
3.
Select from the list those activities which are supposed to be organized
differently depending on a voting channel.
4.
Identify resource pools and determine the costs assigned to every resource pool.
5.
Attribute costs to activities in order to receive total cost per activity.
6.
Calculate the practical capacity of resources.
7.
Divide total cost per activity by practical capacity to receive cost per minute per
activity.
8.
Divide time spent on every activity by output to receive cost per output (in our
case, per ballot) per activity. Multiply this number by the unit cost of a resource
pool in order to receive cost per ballot per activity. Sum up cost per ballot per all
considered activities in order to receive cost per ballot per voting channel.
9.
Compare costs per ballot per different voting channels.
