MeasurementTools The AMMQC program is an Equal Opportunity program. Adaptive equipment is available upon request for individuals with disabilities. This workforce product was funded by a grant awarded by the U.S. Department of Labor s Employment and Training Administration. The product was created by the grantee and does not necessarily reflect the official position of the U.S. Department of Labor. The U.S. Department of Labor makes no guarantees, warranties, or assurances of any kind, express or implied, with respect to such information, including any information on linked sites and including, but not limited to, accuracy of the information or its completeness, timeliness, usefulness, adequacy, continued availability, or ownership. This work is licensed under a Creative Commons Attribution 3.0 Unported License [http://creativecommons.org/licenses/by/3.0]
RULER Scale (divisions in an inch)
PARTS OF VERNIER CALIPER 1. Outside large jaws: Used to measure external diameter or width of an object 2. Insidesmall jaws: Used to measure internal diameter of an object 3. 4. 5. 6. 7. 8. Retainer: Used to block movable part to allow the easy transferring of a measurement Depth probe: Main scale: Main scale: Vernierscale: Vernierscale: Used to measure depths of an object or a hole Scale marked everymm Scale marked in inches and fractions Gives interpolated measurements to 0.1 mm or better Gives interpolated measurements in fractions of an inch
MEASURING WITH VERNIER CALIPERS 1.The Main Scale is similar to a ruler. Each unit on this scale is divide into ten subdivisions, measuring 1/10 (.1) of a unit. 2. Vernier Scale or Secondary Scale is also divided into ten subdivisions, with each measuring 9/100 (.09) of a unit on the main scale.
