Overview of Java Socket Programming and GUI APIs
Java Tutorial
Zhe Li
Topics
●
Socket Programming
●
GUI
●
Maven Project(Tomcat)
Socket
Programming
Overview
Java socket programming provides facility to share data
between different computing devices.
A socket is an endpoint between two way
communication.(Server and Client)
Socket Programming
Socket Class
Socket socket = new Socket(“127.0.0.1”, 5000)
public InputStream getInputStream()
public OutputStream getOutputStream()
public synchronized void close()
ServerSocket Class
public Socket accept()
public synchronized void close()
Client
Server
E
s
t
a
b
l
i
s
h
a
S
o
c
k
e
t
C
o
n
n
e
c
t
i
o
n
Socket socket = new Socket(“127.0.0.1”, 5000)
A socket connection means the two machines have information
about each other’s network location (IP Address) and TCP port.
C
o
m
m
u
n
i
c
a
t
i
o
n
To communicate over a socket connection, streams are used
to both input and output the data.
public InputStream getInputStream()
public OutputStream getOutputStream()
C
l
o
s
i
n
g
t
h
e
c
o
n
n
e
c
t
i
o
n
public synchronized void close()
The socket connection is closed explicitly once the message to
server is sent.
socket demo
Feature1:
Client keeps reading input from user and sends
to the server until “Over” is typed.
Server prints out what the client sends to it.
Feature2:
Client will write first to the server then server
will receive and print the text.
Then server will send the message back to the
client and the client will receive and print the
text.
GUI
Graphical User Interface
Java APIs for graphic programming:
●
AWT(Abstract Windowing Toolkit)
●
Swing
●
JavaFX
HTML/CSS, Jquery, JavaScript
GUI
●
AWT API was introduced in JDK 1.0.
●
Swing API, a much more comprehensive set of graphics libraries that enhances the AWT, was introduced as part of Java
Foundation Classes (JFC) after the release of JDK 1.1. JFC consists of Swing, Java2D, Accessibility, Internationalization,
and Pluggable Look-and-Feel Support APIs. JFC has been integrated into core Java since JDK 1.2.
●
The latest JavaFX, which was integrated into JDK 8, is meant to replace Swing.
AWT
java.awt package contains the core AWT graphics classes:
GUI Component classes, such as Button, TextField, and
Label.
GUI Container classes, such as Frame and Panel
Custom graphic classes, such as Graphic, Color and Font
java.awt.event package supports event handling:
Event classes, such as ActionEvent, MouseEvent,
KeyEvent and WindowEvent
Event Listener Interface, such as ActionListener,
MouseListener, MouseMotionListener
Event Listener Adapter classes, such as MouseAdapter,
KeyAdapter, and WindowAdapter
Awt demo
It has a top-level container Frame, which contains three components - a Label
"Counter", a non-editable TextField to display the current count, and a "Count" Button.
The TextField shall display count of 0 initially.
Each time you click the button, the counter's value increases by 1.
Swing
If you understood the AWT programming (in particular,
container/component and event-handling), switching over
to Swing is straight-forward.
Compared with the AWT component classes (in package
java.awt), Swing component classes (in package
javax.swing) begin with a prefix "J", e.g., JButton,
JTextField, JLabel, JPanel, JFrame, or JApplet.
Writing Swing Applications
In summary, to write a Swing application, you have:
1.
Use the Swing components with prefix "J" in package javax.swing, e.g., JFrame, JButton, JTextField, JLabel, etc.
2.
A top-level container (typically JFrame) is needed. The JComponents should not be added directly onto the
top-level container. They shall be added onto the content-pane of the top-level container. You can retrieve a
reference to the content-pane by invoking method getContentPane() from the top-level container.
3.
Swing applications uses AWT event-handling classes, e.g., ActionEvent/ActionListener,
MouseEvent/MouseListener, etc.
4.
Run the constructor in the Event Dispatcher Thread (instead of Main thread) for thread safety, as shown in the
following program template.
Swing demo
Let's convert the earlier AWT application example into Swing. Compare the two source
files and note the changes (which are highlighted). The display is shown below. Note
the differences in look and feel between the AWT GUI components and Swing's
HTML+iQuery(Web-based)
HTML
HyperText Markup Language
Purpose: How the website will look like(Layout)
jQuery
Manipulation of html elements
jQuery(Library)
jQuery is a library used primarily for Document Object Model (DOM) manipulation. The DOM is a tree-like
structure that represents all elements on a webpage.
jQuery can select DOM elements, create animations, handle events, and more. Its goal is to be extensible,
simple, and clear to use. It takes care of all cross-browser incompatibilities, and it promotes the separation of
HTML and JavaScript.
Bootstrap (framework)
Bootstrap
is an open-source front-end framework to help you with designing websites.
It features a number of CSS styles, icons, components, and JavaScript plugins. These plugins include a lot of
common things you might use when building a website. This includes modals, dropdowns, alerts, and buttons, to
name a few.
AngularJS
HTML is great for declaring static documents, but it falters when we try to use it for declaring dynamic views in
web-applications.
Data-binding eliminates DOM manipulation.
Controllers are the behavior behind the DOM elements.
Maven Project
Maven is a build automation tool used
primarily for Java projects. It addresses
two aspects of building software: First, it
describes how software is built, and
second, it describes its dependencies.
Maven file
Java Application
Building a JavaScript Client
Demo
http://javalin-websocket-example.herokuapp.com/
tips about tomcat
Tomcat version
Mvn clean install
Thank you
