Cuckoo Filters Michael T. Goodrich University of California, Irvine Some slides adapted from slides by Fan, Andersen, Kaminsky, and Mitzenmacher
What is Bloom Filter? A Compact Data Structure Storing Set-membership Bloom Filters answer is item x x in set Y Y by: definitely no definitely no , or probably yes probably yes with probability to be wrong false positive rate false positive rate Benefit: not always precise but highly compact Typically a few bits per item Achieving lower (more accurate) requires spending more bits per item
Example Use: Web Crawling www www. .example example. .com com Please verify Please verify www.example.com www.example.com Remote Server It is Good! It is Good! Probably Yes! Probably Yes! Lookup( Lookup( www.example.com www.example.com ) ) No! No! Known Malicious URLs Stored in Bloom Filter Scale to millions URLs
Bloom Filter Review A Bloom Filter consists of m m bits and k k hash functions Example: m m = 10, k k = 3 Insert(x) Lookup(y) = = not found not found hash3(x) hash3(y) hash1(x) hash1(y) hash2(x) hash2(y) 0 1 0 0 0 0 0 0 0 0 0 0 0 1 0 0 0 1 0 0 1 0 0 0 0 0 1 0 1 0
Succinct Data Structures for Approximate Set-membership Tests High Low Space Cost Delete Support Performance Bloom Filter Counting Bloom Filter Can we achieve all three in practice? Can we achieve all three in practice?
Basic Idea: Store Fingerprints in Hash Table Fingerprint Fingerprint(x): A hash value of x Lower false positive rate , longer fingerprint 0: 1: 2: 3: 4: FP(a) FP(c) 5: 6: 7: FP(b)
Basic Idea: Store Fingerprints in Hash Table Fingerprint Fingerprint(x): A hash value of x Lower false positive rate , longer fingerprint Insert Insert(x): add Fingerprint(x) Fingerprint(x) to hash table 0: 1: 2: 3: 4: FP(x) FP(a) FP(c) 5: 6: 7: FP(b)
Basic Idea: Store Fingerprints in Hash Table Fingerprint Fingerprint(x): A hash value of x Lower false positive rate , longer fingerprint Insert Insert(x): add Fingerprint(x) Fingerprint(x) to hash table Lookup Lookup(x): search Fingerprint Fingerprint(x) in hashtable Lookup(x) = = found 0: 1: 2: 3: 4: FP(x) FP(a) FP(c) 5: 6: 7: FP(b)
Basic Idea: Store Fingerprints in Hash Table Fingerprint Fingerprint(x): A hash value of x Lower false positive rate , longer fingerprint Insert Insert(x): add Fingerprint(x) Fingerprint(x) to hash table Lookup Lookup(x): search Fingerprint Fingerprint(x) in hashtable Delete Delete(x): remove Fingerprint Fingerprint(x) from hashtable Delete(x) 0: 1: 2: 3: 4: FP(x) FP(a) FP(c) 5: 6: 7: FP(b) How to Construct Hashtable?
Cuckoo Hashing[Pagh2004] Higher Space Utilization 4-way set-associative table: >95% entries occupied Fast Lookup: O(1) [Pagh2004] Good But .. 0: 1: 2: 3: 4: hash1(x) lookup(x) hash2(x) 5: 6: 7: Standard cuckoo hashing doesn t use fingerprints
Standard Cuckoo Requires Storing Each Item 0: 1: 2: 3: 4: b h1(x) Insert(x) Insert(x) c 5: 6: 7: h2(x) a
Standard Cuckoo Requires Storing Each Item 0: 1: 2: 3: 4: b Insert(x) Insert(x) c 5: 6: 7: Rehash a: alternate(a) = 4 Kick a to bucket 4 h2(x) x
Standard Cuckoo Requires Storing Each Item 0: 1: 2: 3: 4: b Rehash c: alternate(c) = 1 Kick c to bucket 1 Insert(x) Insert(x) a 5: 6: 7: Rehash a: alternate(a) = 4 Kick a to bucket 4 h2(x) x
Standard Cuckoo Requires Storing Each Item Insert complete (or fail if MaxSteps reached) 0: 1: 2: 3: 4: c b Rehash c: alternate(c) = 1 Kick c to bucket 1 Insert(x) Insert(x) a 5: 6: 7: Rehash a: alternate(a) = 4 Kick a to bucket 4 h2(x) x
Challenge: How to Perform Cuckoo? Cuckoo hashing requires rehashing and displacing existing items 0: 1: 2: 3: 4: FP(b) Kick FP(c) to which bucket? FP(c) 5: 6: 7: Kick FP(a) to which bucket? FP(a) With only fingerprint, how to calculate item s alternate bucket?
We Apply Partial-Key Cuckoo Standard Cuckoo Hashing: two independent hash functions for two buckets functions for two buckets two independent hash bucket1 = hash1(x) bucket2 = hash2(x) Partial-key Cuckoo Hashing: use one bucket and fingerprint to derive the other fingerprint to derive the other [Fan2013] use one bucket and [Fan2013] bucket1 = hash(x) bucket2 = bucket1 hash(FP(x)) To displace existing fingerprint: alternate(x) = current(x) hash(FP(x))
Partial Key Cuckoo Hashing Perform cuckoo hashing on fingerprints 0: 1: 2: 3: 4: FP(b) Kick FP(c) to 4 hash(FP(c)) FP(c) 5: 6: 7: Kick FP(a) to 6 hash(FP(a)) FP(a) Can we still achieve high space utilization with partial-key cuckoo hashing?
Set Intersection Problem Preprocess a collection of sets so as to quickly answer set-intersection queries.
Review: Cuckoo Filters A cuckoo table and parallel cuckoo filter. See Fan et al. 14, Eppstein 16. Provides improved functionality over Bloom filters. Each fingerprint is stored in 1 of 2 places. T: cat pig dog cat dog pig M: 111 000 000 000 000 000 111 111 000 F: 2 5 4 1 word 1 word 1 word
New: 2-3 Cuckoo Filters A cuckoo table and parallel cuckoo filter, where each element is stored in 2-out-of-3 possible locations. T: cat dog pig dog cat pig pig dog cat M: 111 000 111 111 000 111 111 111 000 F: 2 4 5 2 5 4 1 word 1 word 1 word
Intersecting Two 2-3 Cuckoo Filters At least one location must overlap: We may have false-positives, though. T1: cat dog pig cat pig dog M1: 111 000 111 111 000 111 111 111 000 F1: 2 4 5 2 5 4 T2: cat cat fox pig pig fox M2: 111 111 000 000 111 111 111 111 000 F2: 2 2 4 5 5 4
Set Intersection Analysis By above analysis, we can construct 2-3 cuckoo filters of size at least 2 with constant-size stashes with probability at least 1-1/wc. Output intersection elements & discard false positives Intersect cuckoo filters w/ bit-parallel operations Examine each colliding position Choosing a fingerprint size of at least log w bits implies false positives occur with probability less than 1/w. Expected number of false positives is O(n/w). Thus, expected time for a set intersection query is O(n(log w)/w + k), where k is the output size.
