Extensible Monitoring with Nagios and Messaging Middleware LISA 2012 Jonathan Reams <jreams@columbia.edu>
Symon Says Nagios Project Replace 12-year-old home grown monitoring system Very customized Very engineered Very unsupported ~17,000 checks Mandate to move to Nagios
False Start 1. Installed Nagios 2. Ported checks from old system to new 3. Went out for coffee 4. Problems a. High check latency b. High load
Stock Nagios Nagios Host Nagios Process Nagios Reapers Check Results Status Data File Check Processes CGIs Sysadmin
Nagios Problems Trapped on one host: Check results Status data Configuration data Nagios isn t a great executor Forks 2 processes per check Everything is basically synchronous async achieved with multiple processes Data format is simple but non-standard
Nagios Problems Implementation is all in C hard to customize Can be I/O bound by reading/writing check result files Cannot query data from status file/configuration without reading/parsing all of it Input via FIFO gives no feedback and has a limited buffer size
Nagios Problems Communication is hard!
My Solution NagMQ A ZeroMQ-based API for Nagios
Background on ZeroMQ Broker-less messaging kernel in a single library Emulates Berkeley socket API Supports IPC/TCP/Multicast transports Fanout, pub/sub, pipe-line, and request/reply messaging patterns All I/O is asynchronous after connections are established with dedicated I/O threads Bindings available for large number of operating systems and languages Agnostic of data being sent no defined data format
Event Publisher & Commands Host check result from publisher host_check_processed localhost { "host_name": "localhost", "check_type": 0, "check_options": 0, "scheduled_check": 1, "reschedule_check": 1, "current_attempt": 1, "max_attempts": 1, "state": 0, "last_state": 0, "last_hard_state": 0, "last_check": 1354996955, "last_state_change": 1337098090, "latency": 1.63600, "timeout": 60, "type": "host_check_processed", "start_time": { "tv_sec": 1354996955, "tv_usec": 636453 }, "end_time": { "tv_sec": 1354996964, "tv_usec": 161965 }, "early_timeout": 0, "execution_time": 0.07324, "return_code": 0, "output": "Host up", "long_output": null, "perf_data": null, "timestamp": { "tv_sec": 1354996964, "tv_usec": 161966 } } Command to add an acknowledgement to service problem {'comment_data': 'Stop alerting me!!', 'notify_contacts': False, 'author_name': jreams', 'persistent_comment': False, 'host_name': 'localhost', 'service_description': 'rotate-unix', 'time_stamp': {'tv_sec': 1355074576}, 'type': 'acknowledgement'}
State Data Request {'keys': ['host_name', 'services', 'hosts', 'service_description', 'current_state', 'members', 'type', 'name', 'problem_has_been_acknowledged', 'plugin_output', 'checks_enabled', 'notifications_enabled', 'event_handler_enabled'], 'include_services': True, 'host_name': 'localhost'} Response [{'checks_enabled': True, 'notifications_enabled': True, 'current_state': 0, 'plugin_output': 'Host up', 'problem_has_been_acknowledged': 0, 'event_handler_enabled': True, 'host_name': 'localhost', 'services': ['rotate-unix'], 'type': 'host'}, {'checks_enabled': False, 'notifications_enabled': True, 'current_state': 1, 'plugin_output': 'You are now on call', 'problem_has_been_acknowledged': False, 'event_handler_enabled': True, 'host_name': 'localhost', 'service_description': 'rotate-unix', 'type': 'service'}]
Some examples Distributed check execution (mqexec) Custom user interfaces (nag.py, etc) High availability (haagent.py, halib.py)
mqexec Asynchronous command executor Subscribes to host_check_initiate, service_check_initiate, and event_handler_start messages, and executes command line specified Can filter which commands to execute based on any attribute in message Receives messages as Fair-queued worker pool (pull from MQ broker) Individual worker (subscribe directly to NagMQ) Sends results back to command interface of NagMQ
Performance: Stock Nagios 18 16 Latency in Seconds 14 12 10 Max Host Avg Host Max Svc Avg Svc 8 6 4 2 0 1 2 3 4 5 6 7 8 9 1011121314151617181920 Time in Minutes
Performance: NagMQ/mqexec 18 16 14 Latency in Seconds 12 10 Max Host Avg Host Max Svc Avg Svc 8 6 4 2 0 1 2 3 4 5 6 7 8 9 1011121314151617181920 Time in Minutes
User Interfaces Command-line $ nag.py -c 'Stop alerting me!!' add ack localhost [localhost]: No problem found [uptime@localhost]: Acknowledgement added Python/Javascript/Twitter Bootstrap web interface using NagMQ (see demo) Interface to Twitter
High Availability - NagMQ Use regular program_status to provide heartbeat Retrieve active state from state interface to bring passive node into sync with active node on startup Subscribe to and send check result messages, acknowledgements, downtimes, and adaptive changes to command interface Passive host s mqexec(s) run checks for whatever host is active Use VIFs owned by the message broker to direct traffic to active host
Why not use one of these? LiveStatus live state query module with check execution workers Mod_gearman distributed check execution based on gearman job queue Merlin database/distributed backend for Nagios Ndoutils database backend for Nagios NSCA allows check/command submission over network NRPE remote check executor
API not a product NagMQ is just an interface into Nagios, not a product Better communication with clients comes from larger ZeroMQ project leaving NagMQ to focus on Nagios Implement ad-hoc tools for Nagios without having to write any compiled code Doing expensive data processing of monitoring data doesn t have to create latency in monitoring system Re-use one interface for many tools
Future Work Pluggable authentication/encryption for NagMQ Pluggable parser/emitter for custom data formats (XML, Yaml, etc) NDOutils database replacement More user interfaces (Jabber, SMS, email gateway, REST API) Nagios 4
NagMQ https://github.com/jbreams/nagmq Jonathan Reams jbreams@gmail.com
