1. Modern Performance - SQL Server Joe Chang www.qdpma.com & SolidQ

2. About Joe SQL Server consultant since 1999 Query Optimizer execution plan cost formulas (2002) True cost structure of SQL plan operations (2003?) Database with distribution statistics only, no data 2004 Decoding statblob/stats_stream writing your own statistics Disk IO cost structure Tools for system monitoring, execution plan analysis See ExecStats http://www.qdpma.com/ExecStats/SQLExecStats.html Download: http://www.qdpma.com/ExecStatsZip.html Blog: http://sqlblog.com/blogs/joe_chang/default.aspx

3. Overview Why performance is still important today? Brute force? Yes, but Special Topics Automating data collections SQL Server Engine What developers/DBA need to know?

4. CPU & Memory 2001 and 2012 PCI-E PCI-E PCI-E PCI-E PCI-E PCI-E PCI-E PCI-E PCI-E PCI-E PCI-E PCI-E P L2 P P P QPI PCI-E C4 QPI PCI-E C4 C3 C3 QPI C2 C5 C2 C5 FSB LLC LLC C1 C0 C6 C7 C1 C0 C6 C7 MCH MI MI MI MI QPI QPI 2001 4 sockets, 4 cores Pentium III Xeon, 900MHz 4-8GB memory? QPI PCI-E C4 QPI PCI-E C4 C3 C3 C2 C5 C2 C5 QPI LLC LLC C1 C0 C6 C7 C1 C0 C6 C7 MI MI MI MI Xeon MP 2002-4 DMI 2 PCI-E PCI-E PCI-E PCI-E PCI-E PCI-E PCI-E PCI-E PCI-E PCI-E PCI-E 2012 4 sockets, 8 cores each 4 x 8 = 32 cores total 768GB (48 x 16GB), Westmere-EX 1TB 15 cores in next generation? Each core today is more than 10x over PIII 16GB $191 32GB $794

5. Storage 2001 versus 2012/13 QPI 192 GB 192 GB QPI MCH PCIe x4 PCIe x8 PCIe x8 PCIe x8 PCIe x8 PCIe x8 PCI PCI PCI PCI RAID RAID RAID RAID 10GbE RAID RAID RAID RAID IB HDD HDD HDD HDD SSD SSD SSD SSD HDD HDD HDD HDD HDD HDD HDD HDD 2001 100 x 10K HDD 125 IOPS each = 12.5K IOPS IO Bandwidth limited: 1.3GB/s (1/3 memory bandwidth) 2013 64 SSDs, >10K+ IOPS each, 1M IOPS possible IO Bandwidth 10GB/s easy SAN vendors questionable BW http://www.qdpma.com/Storage/Storage2013.html http://www.qdpma.com/ppt/Storage_2013.pptx

6. SAN Node 1 Node 2 Node 1 Node 768 GB 768 GB 2 768 GB 768 GB 8 Gbps FC or 10Gbps FCOE x8 x8 x8 x8 x8 x8 SSD SSD Switch Switch 8 Gb FC Switch Switch SP A SP B 24 GB 24 GB SP A SP B x4 SAS 2GB/s 24 GB 24 GB x4 SAS 2GB/s Data 1 Data 2 Data 3 Data 4 Data 5 Data 6 Data 7 Data 8 Main Volume Data 9 Data 10 Data 11 Data 12 Data 13 Data 14 Data 15 Data 16 Log volume SSD 1 SSD 2 SSD 3 SSD 4 Hot Spares SSD 10K 7.2K Log 1 Log 2 Log 3 Log 4 http://sqlblog.com/blogs/joe_chang/archive/2013/05/10/enterprise-storage-systems-emc-vmax.aspx http://sqlblog.com/blogs/joe_chang/archive/2013/02/25/emc-vnx2-and-vnx-future.aspx

7. Performance Past, Present, Future When will servers be so powerful that Been saying this for a long time Today 10 to 100X overkill 32-cores, 60-cores later in 2013? Enough memory that IO is only sporadic Unlimited IOPS with SSD What can go wrong? Today s topic

8. Factors to Consider SQL Tables Indexes Compile Parameters Statistics Query Optimizer Storage Engine Hardware

9. Special Topics Data type mistmatch Multiple Optional Search Arguments (SARG) Function on SARG Parameter Sniffing versus Variables Statistics related (big topic) first OR, then AND/OR combinations Complex Query with sub-expressions Parallel Execution Not in order of priority http://blogs.msdn.com/b/sqlcat/archive/2013/09/09/when-to-break-down-complex-queries.aspx

10. 1a. Data type mismatch DECLARE @name nvarchar(25) = N'Customer#000002760' SELECT * FROM CUSTOMER WHERE C_NAME = @name SELECT * FROM CUSTOMER WHERE C_NAME = CONVERT(varchar, @name) .NET auto-parameter discovery? Unable to use index seek

11. 1b. Type Mismatch Row Estimate SELECT * FROM CUSTOMER WHERE C_NAME LIKE N'Customer#00000276%' SELECT * FROM CUSTOMER WHERE C_NAME LIKE 'Customer#00000276%' Row estimate error could have severe consequences in a complex query

12. SELECT TOP plus Row Estimate Error SELECT TOP 1000 [Document].[ArtifactID] FROM [Document] (NOLOCK) WHERE [Document].[AccessControlListID_D] IN (1,1000064,1000269) AND EXISTS ( SELECT [DocumentBatch].[BatchArtifactID] FROM [DocumentBatch] (NOLOCK) INNER JOIN [Batch] (NOLOCK) ON [Batch].ArtifactID = [DocumentBatch].[BatchArtifactID] WHERE [DocumentBatch].[DocumentArtifactID] = [Document].[ArtifactID] AND [Batch].[Name] LIKE N'%Value%' ) ORDER BY [Document].[ArtifactID] Data type mismatch results in estimate rows high Top clause easy to find first 1000 rows In fact, there are few rows that match SARG Wrong plan for evaluating large number of rows http://www.qdpma.com/CBO/Relativity.html

13. 2. Multiple Optional SARG DECLARE @Orderkey int, @Partkey int = 1 SELECT * FROM LINEITEM WHERE (@Orderkey IS NULL OR L_ORDERKEY = @Orderkey) AND (@Partkey IS NULL OR L_PARTKEY = @Partkey) AND (@Partkey IS NOT NULL OR @Orderkey IS NOT NULL)

14. Dynamically Built Parameterized SQL DECLARE @Orderkey int, @Partkey int = 1 , @SQL nvarchar(500), @Param nvarchar(100) SELECT @SQL = N /* Comment */ SELECT * FROM LINEITEM WHERE 1=1 , @Param = N'@Orderkey int, @Partkey int' IF (@Orderkey IS NOT NULL) SELECT @SQL = @SQL + N' AND L_ORDERKEY = @Orderkey' IF (@Partkey IS NOT NULL) SELECT @SQL = @SQL + N' AND L_PARTKEY = @Partkey' PRINT @SQL exec sp_executesql @SQL, @Param, @Orderkey, @Partkey IF block is easier for few options Dynamically built parameterized SQL better for many options Considering /*comment*/ to help identify this

15. IF block DECLARE @Orderkey int, @Partkey int = 1 This is actually the stored procedure parameters IF (@Orderkey IS NOT NULL) SELECT * FROM LINEITEM WHERE (L_ORDERKEY = @Orderkey) AND (@Partkey IS NULL OR L_PARTKEY = @Partkey) ELSE IF (@Partkey IS NOT NULL) SELECT * FROM LINEITEM WHERE (L_PARTKEY = @Partkey) Need to consider impact of Parameter Sniffing, Consider the OPTIMIZER FOR hint

16. 2b. Function on column SARG SELECT COUNT(*), SUM(L_EXTENDEDPRICE) FROM LINEITEM WHERE YEAR(L_SHIPDATE) = 1995 AND MONTH(L_SHIPDATE) = 1 SELECT COUNT(*), SUM(L_EXTENDEDPRICE) FROM LINEITEM WHERE L_SHIPDATE BETWEEN '1995-01-01' AND '1995-01-31' DECLARE @Startdate date, @Days int = 1 SELECT COUNT(*), SUM(L_EXTENDEDPRICE) FROM LINEITEM WHERE L_SHIPDATE BETWEEN @Startdate AND DATEADD(dd,1,@Startdate)

17. Estimated versus Actual Plan - rows Estimated Plan 1 row??? Actual Plan actual rows 77,356

18. 3 Parameter Sniffing -- first call, procedure compiles with these parameters exec p_Report @startdate = '2011-01-01', @enddate = '2011-12-31' -- subsequent calls, procedure executes with original plan exec p_Report @startdate = '2012-01-01', @enddate = '2012-01-07' Assuming date data type Need different execution plans for narrow and wide range Options: 1) WITH RECOMPILE 2) main procedure calls 1 of 2 identical sub-procedures One sub-procedure is only called for narrow range Other called for wide range Skewed data distributions also important Example: Large & small customers

19. 4 Statistics Auto-recompute points Sampling strategy Percentage Random pages versus random rows Histogram Equal and Range Rows Out of bounds, value does not exist etc Statistics Used by the Query Optimizer in SQL Server 2008 Writer: Eric N. Hanson and Yavor Angelov Contributor: Lubor Kollar http://msdn.microsoft.com/en-us/library/dd535534.aspx

20. Statistics Structure Stored (mostly) in binary field Scalar values Density Vector limit 30, half in NC, half Cluster key Histogram Up to 200 steps Consider not blindly using IDENTITY on critical tables Example: Large customers get low ID values Small customers get high ID values http://sqlblog.com/blogs/joe_chang/archive/2012/05/05/decoding-stats-stream.aspx

21. Statistics Auto/Re-Compute Automatically generated on query compile Recompute at 6 rows, 500, every 20%? Has this changed?

22. Statistics Sampling Sampling theory True random sample Sample error - square root N Relative error 1/ N SQL Server sampling All rows in random pages

23. Row Estimate Problems Skewed data distribution Out of bounds Value does not exist

24. Loop Join - Table Scan on Inner Source Estimated out from first 2 tabes (at right) is zero or 1 rows. Most efficient join to third table (without index on join column) is a loop join with scan. If row count is 2 or more, then a fullscan is performed for each row from outer source Default statistics rules may lead to serious ETL issues Consider custom strategy

26. Compile Parameter Not Exists Main procedure has cursor around view_Servers First server in view_Servers is CAESIUM Cursor executes sub-procedure for each Server sql: SELECT MAX(ID) FROM TReplWS WHERE Hostname = @ServerName But CAESIUM does not exist in TReplWS!

27. Good and Bad Plan?

28. SqlPlan Compile Parameters

29. SqlPlan Compile Parameters <?xml version="1.0" encoding="utf-8"?> <ShowPlanXML xmlns="http://schemas.microsoft.com/sqlserver/2004/07/showplan" Version="1.1" Build="10.50.2500.0"> <BatchSequence> <Batch> <Statements> <StmtSimple StatementText="@ServerName varchar(50) SELECT @maxid = ISNULL(MAX(id),0) FROM TReplWS WHERE Hostname = @ServerName" StatementId="1" StatementCompId="43" StatementType="SELECT" StatementSubTreeCost="0.0032843" StatementEstRows="1" StatementOptmLevel="FULL" QueryHash="0x671D2B3E17E538F1" QueryPlanHash="0xEB64FB22C47E1CF2" StatementOptmEarlyAbortReason="GoodEnoughPlanFound"> <StatementSetOptions QUOTED_IDENTIFIER="true" ARITHABORT="false" CONCAT_NULL_YIELDS_NULL="true" ANSI_NULLS="true" ANSI_PADDING="true" ANSI_WARNINGS="true" NUMERIC_ROUNDABORT="false" /> <QueryPlan CachedPlanSize="16" CompileTime="1" CompileCPU="1" CompileMemory="168"> <RelOp NodeId="0" PhysicalOp="Compute Scalar" LogicalOp="Compute Scalar" EstimateRows="1" EstimateIO="0" EstimateCPU="1e-007 AvgRowSize="15" EstimatedTotalSubtreeCost="0.0032843" Parallel="0" EstimateRebinds="0" EstimateRewinds="0"> </RelOp> <ParameterList> <ColumnReference Column="@ServerName" ParameterCompiledValue="'CAESIUM'" /> </ParameterList> </QueryPlan> </StmtSimple> </Statements> </Batch> </BatchSequence> </ShowPlanXML> Compile parameter values at bottom of sqlplan file

30. 5a Single Table OR -- Single table SELECT * FROM LINEITEM WHERE L_ORDERKEY = 1 OR L_PARTKEY = 184826

31. 5a Join 2 Tables, OR in SARG -- subsequent calls, procedure executes with original plan SELECT O_ORDERDATE, O_ORDERKEY, L_SHIPDATE, L_QUANTITY FROM LINEITEM INNER JOIN ORDERS ON O_ORDERKEY = L_ORDERKEY WHERE L_PARTKEY = 184826 OR O_CUSTKEY = 137099

32. 5a UNION instead of OR SELECT O_ORDERDATE, O_ORDERKEY, L_SHIPDATE, L_QUANTITY, O_CUSTKEY, L_PARTKEY FROM LINEITEM INNER JOIN ORDERS ON O_ORDERKEY = L_ORDERKEY WHERE L_PARTKEY = 184826 UNION (ALL) SELECT O_ORDERDATE, O_ORDERKEY, L_SHIPDATE, L_QUANTITY, O_CUSTKEY, L_PARTKEY FROM LINEITEM INNER JOIN ORDERS ON O_ORDERKEY = L_ORDERKEY WHERE O_CUSTKEY = 137099 -- AND (L_PARTKEY <> 184826 OR L_PARTKEY IS NULL) -- Caution: select list should have keys to ensure correct rows UNION removes duplicates UNION ALL does not -- Hugo Kornelis trick --

33. 5b AND/OR Combinations Hash Join is good method to process many rows Requirement is equality join condition SELECT xx FROM A WHERE col1 IN (expr1) AND col2 NOT IN (expr2) SELECT xx FROM A WHERE (expr1) AND (expr2 OR expr3) In complex SQL with AND/OR or IN NOT IN combinations Query optimizer may not be to determine that equality join condition exists Execution plan will use loop join, and attempt to force hash join will be rejected Re-write using UNION in place of OR And LEFT JOIN in place of NOT IN More on AND/OR combinations: http://www.qdpma.com/CBO/Relativity3.html

34. Complex Query with Sub-expression Query complexity really high compile cost Repeating sub-expressions (including CTE) Must be evaluated multiple times Main Problem - Row estimate error propagation Solution/Strategy Get a good execution plan Temp table when estimate is high, actual is low. When Estimate is low, and actual rows is high, need to balance temp table insert overhead versus plan benefit. Would a join hint work? More on AND/OR combinations: http://www.qdpma.com/CBO/Relativity4.html http://blogs.msdn.com/b/sqlcat/archive/2013/09/09/when-to-break-down-complex-queries.aspx

35. Temp Table and Table Variable Forget what other people have said Most is Cr@p Temp Tables subject to statistics auto/re-compile Table variable no statistics, assumes 1 row Question: In each specific case: does the statistics and recompile help or not? Yes: temp table No: table variable

36. Parallelism Designed for 1998 era Cost Threshold for Parallelism: default 5 Max Degree of Parallelism instance level OPTION (MAXDOP n) query level Today complex system 32 cores Plan cost 5 query might run in 10ms? Some queries at DOP 4 Others at DOP 16? Really need to rethink parallelism / NUMA strategies More on Parallelism: http://www.qdpma.com/CBO/ParallelismComments.html http://www.qdpma.com/CBO/ParallelismOnset.html

37. Full-Text Search Loop Join with FT as inner Source Full Text search Potentially executed many times

38. varchar(max) stored in lob pages Disk IO to lob pages is synchronous? Must access row to get 16 byte link? Feature request: index pointer to lob

39. Summary Hardware today is really powerful Storage may not be SAN vendor disconnect Standard performance practice Top resource consumers, index usage But also Look for serious blunders http://www.qdpma.com/CBO/SQLServerCostBasedOptimizer.html http://www.qdpma.com/CBO/Relativity.html http://blogs.msdn.com/b/sqlcat/archive/2013/09/09/when-to-break-down-complex-queries.aspx

40. Special Topics Data type mismatch Multiple Optional Search Arguments (SARG) Function on SARG Parameter Sniffing versus Variables Statistics related (big topic) AND/OR Complex Query with sub-expressions Parallel Execution
