1. Mechanical Measurement & Metrology ME211 Nishith Parikh

2. Teaching Scheme 50 30 M1 M2 Tu, W, Thu Lectures Mo/ Thu - Lab M, Tu, F Lectures Mo/ Tu- Lab

3. Teaching Scheme Tentatively Plan Continuous Examination 30 Marks 10 Marks Attendance 10 Marks Minor Quiz I MCQ (Unit 1) 10 marks Minor Quiz II MCQ (Unit 4 and Unit 5) Mid Term Examination 40 Marks ( Convert to 20 Marks) Unit 1, 2 and 3 End Term Examination 50 Marks Unit 1, 2, 3, 4 and 5 Internal Evaluation 20 Marks Lab Submission Lab Attendance ExternalEvaluation 30 Marks Practical Performance Viva

4. Syllabus Sr No Unit Course Content Weightage (%) 1 Concept of Measurement Definition, Need of Measurement, Methods of Measurement, Unit and Standards, Characteristics of Measuring Instruments, Accuracy and Precision, Static and Dynamic Characteristics of Measuring Instrument, Error in Measurements, Limit, Fit and Tolerances, Snap Gauges 10 2 Linear and Angular Measurement Introduction, Surface Plate, V Blocks, Scaled Measurements, Vernier Measurements, Micrometer Measurements, Slip Gauges, Protractor, Sine bar, Angle Gauges, Spirit Level, Autocollimator, Comparators: Mechanical, Optical, Pneumatic, Electrical and electronics. 25 3 Form Measurement Gear Terminology, Measurement of Gear Elements, Screw Thread Terminology, Measurement of Screw Thread Elements, Metrology of Surface Finish, Surface Metrology Concepts, Methods of Measuring Surface Finish. 25

5. Syllabus Sr No Unit Course Content Weightage (%) 4 Measurement of Mechanical Parameters Measurement of Force, Measurement of Torque, Measurement of Strain, Methods of Measuring Temperature, Thermocouples, Pressure Measurement 25 5 Miscellaneous Metrology Precision Instrumentation based on Laser Principles, Coordinate measuring machines: Structure, Modes of Operation of CMM, Optical Measuring Techniques: Tool Maker s Microscope, Profile Projector, Machine Tool Metrology, Machine Vision. 15

6. Textbook Engineering Metrology and Measurement, N V Raghavendra and Krishnamurthy, Oxford University Press, Reference Books: Engineering Metrology and Measurements, Bentley, Pearson Education Theory and Design for Mechanical Measurements, 3rd Edition, Richard S Figliola, Donald E Beasley, Wiley India Metrology and Measurement, Anand Bewoor & Vinay Kulkarni McGraw-Hill

7. List of Experiments 1. Performance on Linear Measurements 2. Performance on Angular Measurements 3. Measurements of Gear Elements By Using Gear Tooth Vernier. 4. Study of Surface Roughness 5. Measurement of Circularity / Roundness using Mechanical Comparator. 6. Force Measurement 7. Torque Measurement 8. Study of Temperature Measurement by thermocouple 9. Study and applications of Profile Projector 10.Study and applications of Tool Maker Microscope.

8. Unit 1: Concept of Measurement

9. Measurement Procedure in which an unknown quantity is compared to a known standard, using an accepted and consistent system of units The measurement may involve a simple linear rule to scale the length of a part Or it may require a sophisticated measurement of force versus deflection during a tension test Measurement provides a numerical value of the quantity of interest, within certain limits of accuracy and precision

10. Metrology Metrology is the name given to the science of pure measurement. Engineering Metrologyis restricted to measurements of length & angle

11. Need of Measurement Establish standard Interchange ability Customer Satisfaction Validate the design Physical parameter into meaningful number True dimension Evaluate the Performance

12. Methods of Measurement Direct method Indirect method Comparative method Coincidence method Contact method Deflection method Complementary method

13. Direct method Measurements are directly obtained Ex: Vernier Caliper, Scales 01-electroniccaliper-VERNIER CALIPER-DIGITAL VERNIER CALIPER-DIRECT MEASUREMENTS-ACCURATE-PRECISION MEASUREMENTS-CALIBRATED INSTRUMENTS

14. Indirect method Obtained by measuring other quantities Ex : Weight = Length x Breadth x Height x Density

15. Comparative Method It s compared with other known value Ex: Comparators

16. Coincidence method Measurements coincide with certain lines and signals Fundamental method Measuring a quantity directly in related with the definition of that quantity Contact method Sensor/Measuring tip touch the surface area

17. Complementary method The value of quantity to be measured is combined with known value of the same quantity Ex:Volume determination by liquid displacement

18. Deflection method The value to be measured is directly indicated by a deflection of pointer Ex: Pressure Measurement
