  1. Introduction to ROTATIONAL BLEND Creo 2.0- Part Mode

  2. Go to Model>>Shapes>>Rotational Blend Following interface will appear. Select to define 1st Sketch

  3. Entire sketch must be on one side of Axis of Rotation Axis of Rotation

  4. Select . Following interface will appear. Angle of Rotation* Select to define 2nd Sketch * Angle must be between -120 to 120

  5. Define Second sketch on the same side of Axis of Rotation as 1st Sketch. Choose the Flow as required, i.e. Straight or Smooth., under Options Tab. Here, Tangency can be defined within both end sections
