1. AQMS utilities (python, sql, etc scripts) NetOps IX Workshop, University of Washington, March 20-21, 2018 Glenn Biasi, USGS, Facilitator

2. What AQMS utility do you use most often? dbselect (9 mentions) perl scripts (2) python scripts (3) sql (3) shell scripts (3) pretty even mix of all of them named others: stp, jiggle We use our own utilities mostly, but use Ellen's dbcleanup scripts monthly.

3. What utility functions do you wish could be added? Station UI Event-based ways to assess station performance / contribution Import metadata through SIS Centralized configuration GUI for alarms Efficient import of hypocenters/magnitudes from neighbor networks Analysis of channel mags for mag residuals I have a long wishlist of features. 1) ability in Jiggle to see past versions of events and revert to them if desired; 2) ability in Jiggle and/or dbselect to search for events that have comments and for keywords within comments; 3) ability in Jiggle to easily add pick times for stations not in the database and test how they effect the solutions; 4) ability in Jiggle to see event submissions from other networks so you can compare solutions side-by-side; 5) ability in Jiggle's map to plot lines from the epicenter to the stations used in that solution (as a means to quickly gauge azimuthal coverage and prioritize picking); 6) ability in Jiggle to easily toggle between servers (a button to change all affected fields in the jiggle props)

4. Locally developed utility or feature that might be helpful or of interest to other networks? managing configuration files with subversion station metadata loader "swarm alarm" script, a dbselect query that looks for events concentrated in area and time. Over a pre-set threshold, it emails us. CEUS contributions (next two slides)

5. Scripting Landscape, CEUS - Memphis db2cat, output a catalog line for evid (in Finalize) db2evdir, output an event directory for evid (in Finalize) dbselect, get parametric information for evid epidist2, find closest city from summary line findcatmatch, find a match in NewMad2k.cat for event makemessage2, make a text file (e.g. report) for evid rmtrace, remove specified trace from event stp, get seismograms from archdb Next page for off-line analysis

6. Tools Supporting Off-line Analysis, Memphis rsa keys and the oracle instantclient allow the analyst to run these scripts on an offline analysis machine (vilos) and remotely connect to the production postproc system. Offline analysis tools: chmag, set magnitude for evid chvelmod, use a fixed velocity model db2qml, send quakeml to PDL for evid (done automatically with Finalize) eqtweet, create and send a tweet for evid; and notweet, disable eqtweet. etype, set etype in archdb for evid ev2db, load event directory into archdb newtrig, create a new trigger in archdb from sac dir newtrig2, create a new trigger in archdb from sac dir using station name for lat/lon. nuke_dups, remove duplicate entries in the waveform table. nuke_dups_archive, remove duplicate entries in the waveform table for years prior to current. sac2db, load sac files into archdb for evid sac2db_archive, load sac files into archdb for evid from a year prior to present startdeep, set starting depth to 25 km

7. Tools Supporting Off-line Analysis, Memphis Patterns: Scripting evolves to address small needs, solve problems Low thresholds for using the database promote its use. rsa keys and the oracle instantclient allow the analyst to run these scripts on an offline analysis machine (vilos) and remotely connect to the production postproc system. Offline analysis tools: chmag, set magnitude for evid chvelmod, use a fixed velocity model db2qml, send quakeml to PDL for evid (done automatically with Finalize) eqtweet, create and send a tweet for evid; and notweet, disable eqtweet. etype, set etype in archdb for evid ev2db, load event directory into archdb newtrig, create a new trigger in archdb from sac dir newtrig2, create a new trigger in archdb from sac dir using station name for lat/lon. nuke_dups, remove duplicate entries in the waveform table. nuke_dups_archive, remove duplicate entries in the waveform table for years prior to current. sac2db, load sac files into archdb for evid sac2db_archive, load sac files into archdb for evid from a year prior to present startdeep, set starting depth to 25 km

8. SCSN Utilities and Scripts Main tool set: tpp scripts http://vault.gps.caltech.edu/trac/cisn/browser#PP/trunk/perl_utils Wiki document about them here: http://vault.gps.caltech.edu/trac/cisn/wiki/PerlUtils -- Role switch scripts: http://scsnwiki.gps.caltech.edu/doku.php?id=rtem:fail_over&s[]=takeover Bourne shell script changing roles of primary and secondary real-time systems Includes checklist of things to check: event generation, duty review, alarm, TMTS2 Another useful utility we have is the "qml" script: http://vault.gps.caltech.edu/trac/cisn/browser/RT/branches/linux-dev-CI- branch/alarming/contrib/bin/qml Generate quakeML from AQMS database Used to submit to ComCat. Perl (2800 lines!)

9. tpp scripts, Event Info Command Function cattail dump events since <hours-back>, or in a starttime::endtime window; 45 command line args trigtail dump triggers since <hours-back> eventhist show the event's history catone output summary line for one event eventAge output event age in seconds eventMag output event mag showalarms Print a list of alarms generated by one or more an events. Data are parsed from rows of the ALARM_ACTION table. Event Info scripts reflect a lot of work Arguments are not intuitive and require the user to remember a lot. Outputs are brittle; have to edit the code or write a postprocessor to do things as simple as change column order of output. Code behavior is inconsistent in things like headers.

10. tpp scripts, Event Parameter Info Command Function hypophases dump phases in Hypo2000 format ampdump dump amps contributing to mag (AssocAmM) ampdumpo dump amps associated with origin (AssocAmO) ampdumpsm dump strong motion station amps associated with event checkwavefiles show dir and list archived waveform files for event (requires ssh) wavedump dump list of this event's waveforms Specialized queries for phase, amplitude, and waveform archive information

11. tpp scripts, Station/Channel Info Command Function hypostalist dump station list in Hypo200 format; flags to adjust output for time and type subsets makeadhoc dump station list in 'adhoc' format stainfo dump station info - string like ""NC.SJE.HHZ.--"", ""CE.%.hn_.0%"" types: ""hypo"", ""kml"", ""gmt"", ""adhoc"" or default" Specialized station info fetch and format stadist sort current stations from point - also: <lat.dec> <lon.dec>. waveform archiving support call Crafted SQL calls, outputs to specific formats.

12. tpp scripts, Duty Review Page Support Command Function acceptEvent mark event as reviewed acceptTrigger mark trigger as reviewed deleteEvent delete event or trigger undeleteEvent undelete event or trigger alarmSend send alarms alarmCancel cancel alarms finalizeEvent finalize the event

13. tpp scripts, Process Control System Command Function puttrans create transition definition deltrans delete a transition definition gettrans show transition definitions from PCS_TRANSITION database table getstates List all postings in PCS_STATE table whose state description matches input arguments post post event <id> to <group> <table> <state> <rank> in the PCS system example: post -d mydb EventStream archdb MakeGif 100 postFromList post events listed in a file to a state unpost remove an event from all states delstates Delete all events with the given signature next Get the next event in this state result set event's result value specialized scripting for process tracking and control

14. tpp scripts, Post Processing Tasks Command Function ampgenpp create amps and write to database Calculate ground motions for one event. Does: PGD, PGV, PGA and spectral amps Runs the AmpGenPp application found in jiggle jar rcgone Generate request cards for one event

15. tpp scripts, Miscellaneous Utilities Command Function masterrt output current master RT system name masterdb output current master database name showlocks show events locked by Jiggle unlockevent unlock an event locked by Jiggle unlockall unlock all events locked by Jiggle epoch show system time in epoch seconds hypolocate locate this event with a [remote] SolServer

16. What is Next For AQMS Utility Development? Balance between turn-key scripts in AQMS distro vs. tools to craft your own? Need/usefulness of greater standardization? Priorities for AQMS utility development?

18. tpp: cattail.pl usage: cattail.pl [option-list] [[#interval] or [startDate [endDate]]] options: [-h] [-c] [-d dbase] [-a or [ [-D] [-B0|1]]] [-i|I] [-f file] [-e types] [-g|G gtypes] [-p rflags] [-m mag -M mag] [ -mt magtypes] [-ma magalgo] [-mad rval -MAD rval] [-rms rval -RMS rval] [-mz] [-z depth -Z depth] [ -fz] [-es esrc -os osrc -ms msrc ] -[2rwL] [-u d|w|m ] Writes a summary list for events in the past 'N' hours (default = 24), or specified date range. 45 command-line args.

19. tpp: trigtail.pl usage: trigtail.pl [-d dbase] [-h] [-aqr] <#hrs-back> (default = $hrsback) Print a listing summarizing the subnet trigger events (etype=st) that occurred in the past '#hrs-back' hours. -d dbase : alias to use for db connection (defaults to $masterdb) -a : include all events including deleted and duplicates -q : do not print column header title -r : reverse sort order (newest at top) example: $0 -d mydb 24

20. tpp: eventhist.pl usage: eventhist.pl [-q] [-d dbase] <evid> Show origin,magnitude change history info for an event. List is sorted in magnitude lddate descending order. (The most recent update first, oldest last). example difficulty: Event prefmag is flagged by "<+++" after its lddate, otherwise if its the preferred of a magtype its flagged by "+" after. Example problem: When the orid is event prefor and the magid is the event prefmag the both the waveform count and event version numbers are printed. So to use eventhist.pl, we have to remember the special output cases, the odd flagging convention, and then write another parser to get the extra stuff out.

21. tpp: catone.pl usage: catone.pl -[ht] [-d dbase] <event-id> Write a summary line for one event. -h : print usage info -t : write column header -d dbase : alias to use for db connection (defaults to "$masterdb") example: catone.pl -d k2db -t 7395710

22. tpp: eventAge.pl usage: eventAge.pl [-d dbase] <evid> Prints total integer seconds elapsed since event origin time, or "0" if the input event evid does not match an event row in db. -h : print usage info -d dbase : alias to use for db connection (defaults to "$masterdb ) example: $0 -d k2db 8735346 Implicit read of Event hash (database hardcode)

23. tpp: eventMag.pl # options to prepend/append magtype,evid,auth, and version. # Handles rounding to nearest 0.1 unit. usage: eventMag.pl [-d dbase] [-i] [-t] <evid> Print the magnitude value of an event. -h : print this usage info -d dbase : alias to use for db connection (defaults to "$masterdb") Return string value for the preferred magnitude of the event in db associated with input evid -a : append the event auth after evid for the event info string; -v : append the event auth and its version after evid for the event info string -i : prepend an event info string before the magnitude value; -I : append an event info string after the magnitude value -l : format origin as local time and date; -L : format origin as date and local time -o : origin date time appended, default is UTC with date first; -O : origin date time prepended, default is UTC with date first -p : magnitude in parentheses -t : prepend the magnitude type before the magnitude value; -T : append the magnitude type after the magnitude value -u : format origin time as UTC time and date -U : format origin time as UTC date and time

24. tpp: showalarms.pl usage: showalarms.pl [-d dbase] [evid] Print a list of alarms generated by one or more an events. Data are parsed from rows of the ALARM_ACTION table. -h : print this usage info -d dbase : alias to use for db connection (otherwise does both "$masterrt" and "$masterdb") -e : only list alarms whose action state is ERROR -t days : when no evid argument, the #days back MOD_TIME for all evids in table (default: $daysAgo = 7)

25. tpp: dbinfo masterdblookup.pl: Returns name of DB database that is PRIMARY by querying the RT dbases. Info also available from MasterDbs.pm masterrtlookup.pl: Returns name of RT database that is PRIMARY by querying the RT dbases. Info also available from MasterDbs.pm refreshDBInfo.pl Keep the file (cfg/masterinfo.cfg) containing info about master db's current with master/backup info. This file is used by ALL other scripts that need to know about master dbases. setupTransitions.pl setupTransitions.pl [ -d dbname, default: "$masterdb"] [ -f cfgFile evaluated with rules] Set up the standard PCS_TRANSITION table rules. Reads rules from file and inserts into table of connected database.

26. tpp: hypophases.pl Dump phase info for one event in Hypoinverse2000 .ARC format Prints a hypoinverse ARC listing of the phase arrival data associated with the prefor of the event, unless using -o option, in which case the input id is origin orid. 242 L

27. ampdump, ampdumpo, ampdumpsm Print amp data associated with preferred magnitude of event (AssocAmM), or with input magid if -m option is used. formats sql call, organizes return Print amp data associated with the preferred origin of event in (AssocAmO). Or input origin id with -o option. formats sql call, organizes return Print strong motion amp data, or total amp count, associated with event (AssocEvAmpset). formats sql call, organizes return

28. tpp: checkwavefiles.pl usage: checkwavefiles.pl [-d dbase] [-1 or -wW wavefilehost] <evid> Print the waveform file path found in database for an event evid. Optionally lists path files found on a specified wavefile host using ssh.

29. tpp: wavedump.pl usage: wavedump.pl [-h] [-c|k] [-C] [-d dbase] [-q] [-f] [-r] [-R] <evid> Prints summary info about waveforms and/or waveform requests associated with event. Waveform summary info: SNCL, ontime, start-time, end-time, duration-secs, total-bytes, sps

30. tpp: hypostalist usage: hypostalist [-abd:qX:x:I:i:h] [<start-date>] [<end-date>] Dump station list from CHANNEL_DATA table in Hypoinverse format 10 command line options to adjust output choices Crafted SQL with some hardcoding

31. tpp: makeadhoc Lists info for SCEDC seismic stations in AdHoc list format. Includes only those seedchan matching the wildcards: E% or H%, for nets: 'CI', 'AZ', 'FA', 'TA', 'EN', 'SB', 'ZY', 'BC', 'NN', excluding sta: 'MIK' and 'CBC'. usage: makeadhoc [-d dbase] crafted SQL call, formatted output.

32. tpp: stainfo usage: stainfo -[ahqt] [-d dbase] [-f type] <station string> Prints summary station info ordered by sta, net, location, seedchan. All formats include lat,lon, and elevation. Default includes channel ondate, offdate, and site name. Optional formats for output

33. tpp: stadist usage: stadist -[h] [-d dbase] <lat.dec> <lon.dec> stadist -[h] [-d dbase] <latdeg> <latmin> <londeg> <lonmin> Dump a station list in distance order from this lat/lon. Only those stations eligible for waveform archiving (rcg) are listed. Based on dbase connection and rule for archiving. -> specialized sql select, purpose-formatted output.
