FTP and Samba for Network Administration
C
h
a
p
t
e
r
6
F
T
P
,
F
i
l
e
a
n
d
P
r
i
n
t
S
e
r
v
e
r
A System Administration
Perspective
Network and System Administration
1
What is FTP
•
FTP is short for File Transfer Protocol.
•
It is used to transfer files between an FTP server
and another computer.
•
FTP also tends to be faster than other contemporary
methods of transferring files because it was
designed to do so.
•
Two roles during file transfer:
FTP Server: Hosts the service
FTP Client: uploads/downloads files to/from FTP Server
•
FTP support Automatic Resume.
Network and System Administration
2
How to connect to FTP Server
•
Two approaches exist to connect to FTP Server:
The first is to make it so anyone can log in anonymously,
otherwise known as anonymous FTP, or
Example:
ftp://movies.ambou.edu.et
Assign user names and passwords to people that they
must use to log in to the server.
Example:
ftp://username:password@movies.ambou.edu.et
It is also possible to use FTP client that is designed
specifically to connect to FTP servers.
These types of software are generally the best as they have been
streamlined for speed and support a lot of the advanced features
like automatic resume.
Example: FileZilla, Fire FTP, WinSCP
Network and System
Administration
3
Samba: An Introduction
•
The main essence of computer network is to share
information and resource.
•
File is among the resource users can share on the
network.
File sharing should be transparent to heterogeneity in
platforms in the network
Windows, Unix, Mac, …..
•
Domain based windows network doesn’t
communicate with Linux/Mac machines.
•
Network and System
Administration
4
Samba…
•
Samba is an Open Source/Free Software suite that
provides seamless file and print services to
SMB/CIFS clients.
Samba is freely available, unlike other SMB/CIFS
implementations, and allows for interoperability
between Linux/Unix servers and Windows-based clients
Samba uses the TCP/IP protocol that is installed on the
host server.
When correctly configured, it allows that host to interact
with a Microsoft Windows client or server as if it is a
Windows file and print server.
It uses SMB/CIFS (Server Message Block/Common
Internet File System) protocol.
Network and System
Administration
5
What Samba Does
•
Samba implement the four basic modern-day CIFS
services.
File & print services
Authentication and Authorization
Name resolution
Service announcement (browsing)
Network and System
Administration
6
What Samba….
•
File and print services are the cornerstone of the
CIFS suite.
File sharing, Print Sharing
•
It also handles share mode and user mode
authentication and authorization.
One can protect shared file and print services by
requiring passwords.
In share mode, password can be assigned to a shared directory or
printer.
With user mode authentication, each user has their own
username and password.
Network and System
Administration
7
What Samba….
•
Name resolution takes two forms: broadcast and
point-to-point.
In broadcast, a client looking for a service will call out
with the service name and wait for the machine with that
name to answer with an IP address.
In point-to-point which uses NBNS (NetBios Name
Service), services will keep their name and associated IP
Address.
The clients send their NetBIOS names & IP addresses to the
NBNS server
•
Browsing maintains browsable list of services (file
and print shares) offered by the computers on a
network.
Network and System
Administration
8
What Samba….
•
Service announcement (browsing) is handled by
Local Master Browser (LMB).
The LMBs job is to keep a list of available services
LMB is voted by the participating PCs in the LAN.
In addition to LMBs, there are
Domain
Master Browsers
(DMBs).
DMBs coordinate browse lists across NT Domains, even on
routed networks
Network and System
Administration
9
Samba Utilities
•
Samba comes with a variety of utilities. The most
commonly used are:
smbclient
A simple SMB client, with an interface similar to that of the FTP
utility.
It can be used from a Unix system to connect to a remote SMB share,
transfer files, and send files to remote print shares (printers).
nmblookup
It can be used to find NetBIOS names on a network, lookup their IP
addresses, and query a remote machine for the list of names the
machine believes it ownes.
swat
The
S
amba
W
eb
A
dministration
T
ool
. Swat allows you to configure
Samba remotely, using a web browser.
Network and System
Administration
10
