Formal languages and Compiler Design Simona Motogna S. Motogna - LFTC

Why Why? ? Compiler Design Formal Languages FLCD S. Motogna - LFTC

Organization Issues Course 2 h/ week Seminar 1h/week Laboratory - 1h/week 5 presences seminar 6 presences - lab PRESENCE IS MANDATORY S. Motogna - LFTC

Organization Issues Final grade = 70% written exam + 20% lab + 10% seminar Lab: Seminar: - all laboratory assignments are mandatory - delays NO more than 2 weeks - solved problems, answers (blackboard), homeworks S. Motogna - LFTC

References See fi a disciplinei S. Motogna - LFTC

What is a compiler? Interpreter? Object code / program Source code / program Compiler Assembler? S. Motogna - LFTC

A little bit of history Java 1995 C 1969 - 1973 J. Gosling Pascal 1968 - 1970 D. Ritchie Lisp 1962 N. Wirth McCarthy Fortran 1954-1957 Backus S. Motogna - LFTC

Structure of a compiler analysis Error handling Source code/ program Scanning (lexical analysis) Parsing (syntactical analysis) tokens Semantic analysis Syntax tree Intermediary code generation synthesis Adnotated syntax tree Intermediary code optimization Symbol Table management Intermediary code Object code / program Object code generation Optimized intermediary code S. Motogna - LFTC

Chapter 1. Scanning Definition = treats the source program as a sequence of characters, detect lexical tokens, classify and codify them INPUT: source program OUTPUT: PIF + ST Algorithm Scanning v1 While (not(eof)) do detect(token); classify(token); codify(token); End_while S. Motogna - LFTC

Detect I am a student. - Separators => Remark 1) + 2) if (x==y) {x=y+2} - Look-ahead => Remark 3) S. Motogna - LFTC

Classify Classes of tokens: Identifiers Constants Reserved words (keywords) Separators Operators If a token can NOT be classified => LEXICAL ERROR S. Motogna - LFTC

Codify Codification table Identifier, constant => Symbol Table (ST) PIF = Program Internal Form = array of pairs Token replaced by pair (code, position in ST) identifier, constant S. Motogna - LFTC

Algorithm Scanning v2 While (not(eof)) do detect(token); iftoken is reserved word OR operator OR separator then genFIP(code, 0) else if token is identifier OR constant then index = pos(token, ST); genFIP(code, index) elsemessage Lexical error endif endif endwhile S. Motogna - LFTC

Remarks: genFIP = adds a pair (code, position) to PIF Pos(token,ST) searches token in symbol table ST; if found then return position; if not found insert in SR and return position Order of classification (reserved word, then identifier) If-then-else imbricate => detect error if a token cannot be classified S. Motogna - LFTC

Symbol Table Definition = contains all information collected during compiling regarding the symbolic names from the source program identifiers, constants, etc. Variants: table) - Unique symbol table contains all symbolic names - distinct symbol tables: IT (identifiers table) + CT (constants S. Motogna - LFTC

ST organization Remark: search and insert 1. Unsorted table in order of detection in source code 2. Sorted table: alphabetic (numeric) 3. Binary search tree (balanced) 4. Hash table O(n) O(lg n) O(lg n) O(1) S. Motogna - LFTC

Hash table K = set of keys (symbolic names) A = set of positions (|A| = m; m prime number) h: K A h(k) = (val(k) mod m) + 1 Conflicts: k1 k2 , h(k1) = h(k2) S. Motogna - LFTC
