Enhancing SDN Networks with GRAMI Software: A Study by Shlomi Nissim and Anat Bremler-Bar
GRAMI Software Enhancement on
SDN Networks
Shlomi Nissim, Anat Bremler-Bar
Interdisciplinary Center Herzliya
January 2017
Outline
•
Background - GRAMI Overview
•
OpenVSwitch Integration
•
RTP Implementation
•
GRAMI Evaluation – creating SDN networks setups
•
Summary
Background
•
RTT – Round Trip Time
–
Time to
send
a packet
and receive
a response
–
The RTT is not constant
•
Applications: Bottlenecks and anomalies detection,
traffic engineering
•
Existing Tools, such as Ping and Traceroute,
are
limited
in traditional networks
–
Only between
L3 entities
–
Cannot measure
any selected route
–
Routing changes
2
RTT Monitoring in OpenFlow
2
1
2
1
2
3
2
4
3
GRAMI - Overview
GRA
nular RTT
M
onitoring
I
nfrastructure
•
GRAMI works in two phases:
•
Offline:
Controller application
finds a
location set for k
monitoring points
(MPs) and builds an
overlay network
•
Online
: Active probing
from
the
MPs
–
The RTT of a single link\RTP is calculated
in the MPs by
subtracting
the RTT of
different paths
5
Original Paper Limitations
6
Virtual Machine – Ubuntu 14.04
Mininet
ꓫ
GRAMI did not implemented on
OpenVSwitch
ꓫ
Tested on a *MININET* with one
CPU
ꓫ
RTP was not implemented
2
Main Goal: Implement GRAMI on a Real Network
7
Implement GRAMI on OpenVSwitch
with lower overhead
Verifying GRAMI software by real
SDN Network setups
RTP algorithm implementation
CPqD => OpenVSwitch
Mininet => Separate VMs / Servers
Goals: Make GRAMI Support OpenVSwitch
8
The main goal is to integrate GRAMI with OpenVSwitch.
•
Implement GRAMI on existing SDN will be more simple.
•
GRAMI code would be updated in GitHub.
•
SDN users could use this work for study and research.
Goals: Run GRAMI on Various SDN Networks
9
•
Test GRAMI on various network setups
•
Identify real network load
•
Compare GRAMI against another network diagnostic tools
•
Validate GRAMI Reliability
Goals: Adding RTP implementation
10
10
•
RTP measurement –
R
ound
T
rip
P
ath measurement
•
GRAMI RTP calculation algorithm was describe in the previous work
•
Implementing preconfigured RTP between any two virtual switches
Probe Packet Structure
[00:00:00] Measurement Round Started
[00:00:02] Packet (1,NULL) Received
[00:00:05] Packet (1,2) Received
M
e
a
s
u
r
e
m
e
n
t
P
o
i
n
t
OpenVSwitch Integration - Challenges
•
OpenVSwitch did not support QinQ.
•
We need to find other packet field to tag GRAMI data.
•
OpenVSwitch does not OpenFlow 1.5 implement partial field setting.
•
Work with P4 switch require changing the switches software and uneasy to use.
OpenVSwitch Integration
•
We started to work on QinQ support in OpenVSwitch.
•
In February 2017 the OVS patch released.
•
Adjust GRAMI source code for OpenVSwitch support.
•
Using in
sourceMac
instead of
ethType
to indicate the GRAMI packet type.
RTP implementation
14
14
1
2
3
Creating test setup considerations
•
What is a real SDN setup?
•
How can we create this setup with our hardware?
•
How to compare GRAMI against other network diagnostic tool?
Upgrade the test setup software
Upgraded to 16.04 for more driver support
Now supports OVS and RYU latest versions
Upgraded to 2.7.9
Added QINQ support
Added more support for OpenFlow features
Using Traceroute
•
Traceroute is popular tool for RTT calculation in IP network.
•
Traceroute computes the RTT from the MP to the IP endpoints.
•
For testing, we manually reconfigure the virtual switches to work as IP endpoints.
Evaluation: OpenVSwitch within Mininet
First, to check if GRAMI works with OpenVSwitch, we use Mininet.
•
GRAMI ran on the same network topology from the article.
•
GRAMI ran on the upgraded setup.
•
RTT & RTP calculation results were reliable.
Evaluation: Separate VMs Setup
•
Our goal was to create real SDN setup.
•
We set SDN on personal computer –
by running 6 VMs on it.
•
The controller, virtual switches and
the MP were installed on some
separate VMs.
•
The RTT and RTP was calculated
successfully.
Evaluation: GRAMI vs Traceroute without load
GRAMI ran in the last SDN setup to monitor links RTT
•
Each virtual switch was installed on VM and was connected to other VM.
•
For the result validating, traceroute ran on the same setup.
•
GRAMI overhead was less than traceroute overhead.
Evaluation: Simulating the Network Load
To check if GRAMI identify network load, we tried to simulate it by:
N
o
t
r
a
f
f
i
c
V
M
1
1
0
.
0
.
0
.
1
V
M
2
1
0
.
0
.
0
.
2
Link RTT = 10ms
Link RTT = 500ms
eth0
1Mbps Limit
eth0
1Mbps Limit
F
i
l
e
t
r
a
n
s
f
e
r
2. Configure a interface bandwidth limit ->
RTT Increased Significantly
1. Add a network traffic by file transfer ->
RTT unchanged
Evaluation: GRAMI vs Traceroute with Load
There was two tests to check how GRAMI handle network load:
1.
One link with load against the other links
2.
One link with load changes over time
GRAMI successfully identify the changes.
Evaluation: Deepness Lab Servers Setup
Finally, To check GRAMI on physical links, we used Deepness lab
servers:
•
Except from physically connecting the servers,
we managed the tests remotely.
•
The main difficult was that the servers number
were not enough.
Evaluation: Deepness Lab Servers - Results
•
GRAMI ran on the physical links successfully
•
The results were more consistent than the previous, with less overhead
•
GRAMI was compatible with traceroute measurement results.
S
1
-
S
2
-
S
3
-
S
1
R
T
P
t
i
m
e
:
3
0
.
4
1
m
i
l
l
i
s
e
c
o
n
d
s
Possible Future Work
•
Apply GRAMI on SDN Organization Data Centers
•
Additional virtual switches and controllers support
•
Implement an automation of local SDN creation for tests
•
Implement an automation of local network creation for traceroute
tests
Summary
•
The integration with OpenVSwitch succeed.
•
RTP calculation algorithm implemented.
•
GRAMI was tested on various setups:
–
Simulated links on a single VM using Mininet.
–
Simulated links on separate VMs.
–
Physical links on separate servers.
•
The evaluation results return reliable results by deviation of 0.1
milliseconds.
GRAMI software enhancement on SDN networks was explored in a study conducted by Shlomi Nissim and Anat Bremler-Bar at the Interdisciplinary Center Herzliya in January 2017. The research focused on GRAMI overview, OpenVSwitch integration, RTP implementation, SDN network setups, and evaluation, highlighting the importance of RTT monitoring in OpenFlow and the phases of GRAnularRTT Monitoring Infrastructure. The main goal was to implement GRAMI on a real network environment for improved performance and efficiency.
