  1. Gotta Tell You Switches Only Once Toward Bandwidth-Efficient Flow Setup for SDN FastLane Kai Bu Zhejiang University

  2. Gotta Tell You Switches Only Once Toward Bandwidth-Efficient Flow Setup for SDN

  3. Gotta Tell You Switches Only Once Toward Bandwidth-Efficient Flow Setup for SDN?

  4. Gotta Tell You Switches Only Once Toward Bandwidth-Efficient Flow Setup for SDN Software-Defined Networking

  5. Gotta Tell You Switches Only Once Toward Bandwidth-Efficient Flow Setup for SDN Software-Defined Networking

  6. Gotta Tell You Switches Only Once Toward Bandwidth-Efficient Flow Setup for SDN Software-Defined Networking

  7. Controller Controller Gotta Tell You Switches Only Once Toward Bandwidth-Efficient Flow Setup for SDN App App App Software-Defined Networking

  8. Controller Controller Routing Gotta Tell You Switches Only Once Toward Bandwidth-Efficient Flow Setup for SDN App Flow Setup flow

  9. Controller Controller Routing Gotta Tell You Switches Only Once Toward Bandwidth-Efficient Flow Setup for SDN FlowMod App Flow Setup flow

  10. Switch Rule Controller Priority Matching Action sw1 p1 src_ip=10.20.*.* fwd(sw2) Controller sw2 P2 src_ip=10.20.*.* fwd(sw3) Routing Gotta Tell You Switches Only Once Toward Bandwidth-Efficient Flow Setup for SDN FlowMod sw3 p3 src_ip=10.20.*.* fwd(out) App Flow Setup sw1 sw2 sw3 flow p1, src_ip=10.20.*.*, fwd(sw2) p2, src_ip=10.20.*.*, fwd(sw3) p3, src_ip=10.20.*.*, fwd(out)

  11. Controller Controller Routing Gotta Tell You Switches Only Once Toward Bandwidth-Efficient Flow Setup for SDN FlowMod bandwidth fatigue App control channel Flow Setup flow

  12. Controller Controller Routing Gotta Tell You Switches Only Once Toward Bandwidth-Efficient Flow Setup for SDN FlowMod bandwidth fatigue potential bottleneck [devoflow 11] App control channel Flow Setup flow

  13. Controller Controller Routing Gotta Tell You Switches Only Once Toward Bandwidth-Efficient Flow Setup for SDN FlowMod bandwidth-efficient App Flow Setup flow

  14. Controller Controller Routing Gotta Tell You Switches Only Once Toward Bandwidth-Efficient Flow Setup for SDN FlowMod App FastLane controller instructs only ingress switch; switches cooperate to configure fwding path; flow

  15. Controller Controller Routing Gotta Tell You Switches Only Once Toward Bandwidth-Efficient Flow Setup for SDN FlowMod App FastLane controller instructs only ingress switch; switches cooperate to configure fwding path; flow

  16. Controller Controller Routing Gotta Tell You Switches Only Once Toward Bandwidth-Efficient Flow Setup for SDN FlowMod = PriorityPath, Matching, FwdPath App FastLane FlowMod Construction flow

  17. Switch Rule Controller Priority Matching Action sw1 p1 src_ip=10.20.*.* fwd(sw2) Controller sw2 P2 src_ip=10.20.*.* fwd(sw3) Routing Gotta Tell You Switches Only Once Toward Bandwidth-Efficient Flow Setup for SDN FlowMod = PriorityPath, Matching, FwdPath sw3 p3 src_ip=10.20.*.* fwd(out) App p1-p2-p3, src_ip=10.20.*.*, sw1-sw2-sw3-out FastLane FlowMod Construction sw1 sw2 sw3 flow

  18. Switch Rule Controller Priority Matching Action sw1 p1 src_ip=10.20.*.* fwd(sw2) Controller sw2 P2 src_ip=10.20.*.* fwd(sw3) Routing Gotta Tell You Switches Only Once Toward Bandwidth-Efficient Flow Setup for SDN FlowMod = PriorityPath, Matching, FwdPath sw3 p3 src_ip=10.20.*.* fwd(out) App p1-p2-p3, src_ip=10.20.*.*, sw1-sw2-sw3-out FastLane Rule Extraction ingress switch sw1 sw2 sw3 flow Priority = p1 = the ith priority of PriorityPath Matching = src_ip=10.20.*.* = FlowMod .Matching; same for all sw Action = fwd(sw2) = fwd(swi.next); the ith hop of FwdPath

  19. Switch Rule Controller Priority Matching Action sw1 p1 src_ip=10.20.*.* fwd(sw2) Controller sw2 P2 src_ip=10.20.*.* fwd(sw3) Routing Gotta Tell You Switches Only Once Toward Bandwidth-Efficient Flow Setup for SDN FlowMod = PriorityPath, Matching, FwdPath sw3 p3 src_ip=10.20.*.* fwd(out) App p1-p2-p3, src_ip=10.20.*.*, sw1-sw2-sw3-out FastLane Rule Installation ingress switch sw1 sw2 sw3 flow p1,src_ip=10.20.*.*,fwd(sw2)

  20. Switch Rule Controller Priority Matching Action sw1 p1 src_ip=10.20.*.* fwd(sw2) Controller sw2 P2 src_ip=10.20.*.* fwd(sw3) Routing Gotta Tell You Switches Only Once Toward Bandwidth-Efficient Flow Setup for SDN FlowMod = PriorityPath, Matching, FwdPath sw3 p3 src_ip=10.20.*.* fwd(out) App p1-p2-p3, src_ip=10.20.*.*, sw1-sw2-sw3-out FastLane FlowMod Forwarding ingress switch sw1 fwds it to sw2 Hdr=flow.header sw1 sw2 sw3 flow p1,src_ip=10.20.*.*,fwd(sw2)

  21. Switch Rule Controller Priority Matching Action sw1 p1 src_ip=10.20.*.* fwd(sw2) Controller sw2 P2 src_ip=10.20.*.* fwd(sw3) Routing Gotta Tell You Switches Only Once Toward Bandwidth-Efficient Flow Setup for SDN FlowMod = PriorityPath, Matching, FwdPath sw3 p3 src_ip=10.20.*.* fwd(out) App p1-p2-p3, src_ip=10.20.*.*, sw1-sw2-sw3-out FastLane FlowMod Forwarding ingress switch sw1 fwds it to sw2: Hdr=flow.header sw2 directs it to cpu: Hdr.SwIndex=sw2 sw1 sw2 sw3 flow phighest,SwIndex=sw2, to cpu p1,src_ip=10.20.*.*,fwd(sw2)

  22. Switch Rule Controller Priority Matching Action sw1 p1 src_ip=10.20.*.* fwd(sw2) Controller sw2 P2 src_ip=10.20.*.* fwd(sw3) Routing Gotta Tell You Switches Only Once Toward Bandwidth-Efficient Flow Setup for SDN FlowMod = PriorityPath, Matching, FwdPath sw3 p3 src_ip=10.20.*.* fwd(out) App p1-p2-p3, src_ip=10.20.*.*, sw1-sw2-sw3-out FastLane FlowMod Forwarding ingress switch sw1 fwds it to sw2: Hdr=flow.header sw2 directs it to cpu: Hdr.SwIndex=sw2 sw2 extracts rules: Payload=FlowMod sw1 sw2 sw3 flow phighest,SwIndex=sw2, to cpu p1,src_ip=10.20.*.*,fwd(sw2)

  23. Switch Rule Controller Priority Matching Action sw1 p1 src_ip=10.20.*.* fwd(sw2) Controller sw2 P2 src_ip=10.20.*.* fwd(sw3) Routing Gotta Tell You Switches Only Once Toward Bandwidth-Efficient Flow Setup for SDN FlowMod = PriorityPath, Matching, FwdPath sw3 p3 src_ip=10.20.*.* fwd(out) App p1-p2-p3, src_ip=10.20.*.*, sw1-sw2-sw3-out FastLane intermediate/egress sw iterates extract rule; install rule; forward FlowMod sw1 sw2 sw3 flow phighest,SwIndex=sw2, to cpu *egress switch untags SwIndex !forward FlowMod p1,src_ip=10.20.*.*,fwd(sw2)

  24. Controller Gotta Tell You Switches Only Once Toward Bandwidth-Efficient Flow Setup for SDN ?Benefits of FastLane

  25. Controller already 50%+ bandwidth saving Gotta Tell You Switches Only Once Toward Bandwidth-Efficient Flow Setup for SDN for 3-switch path by FastLane

  26. Controller saved bw supports more flows; lower average flow latency Gotta Tell You Switches Only Once Toward Bandwidth-Efficient Flow Setup for SDN can be promised by FastLane

  27. Controller Controller Routing Gotta Tell You Switches Only Once Toward Bandwidth-Efficient Flow Setup for SDN FlowMod App FastLane flow

  28. Controller Controller Routing Gotta Tell You Switches Only Once Toward Bandwidth-Efficient Flow Setup for SDN FlowMod App bandwidth-efficient flow setup for FastLane flow

  29. Controller Controller Routing Gotta Tell You Switches Only Once Toward Bandwidth-Efficient Flow Setup for SDN FlowMod App bandwidth-efficient flow setup for FastLane controller instructs only ingress switch; switches cooperate to configure fwding path; flow

  30. Controller Controller Routing Gotta Tell You Switches Only Once Toward Bandwidth-Efficient Flow Setup for SDN FlowMod App bandwidth-efficient & fast flow setup for FastLane controller instructs only ingress switch; switches cooperate to configure fwding path; flow saved bandwidth favors more flows and thus reduces average flow latency;

  31. Controller Controller Controller Routing Gotta Tell You Switches Only Once Toward Bandwidth-Efficient Flow Setup for SDN Thank You App App FlowMod FastLane @SDDCS 2015 Kai Bu Zhejiang University kaibu@zju.edu.cn flow
