  1. S32K3 ITCM AND DTCM AUTOMOTIVE APPLICATIONS TEAM Created: Last Update: Nov 2021 Nov 2021 EXTERNAL USE

  2. Agenda Place functions into ITCM Place data into DTCM Place ARM EABI GNU related sections 1 EXTERNAL USE

  3. PLACE FUNCTIONS INTO ITCM 2 EXTERNAL USE

  4. Step1: add ITCM section in linker file (after section .shareable_bss) This section s start and end address in ROM/RAM should also be defined __itcm0_code_rom = __shareable_data_rom_end; .itcm0_code : AT(__itcm0_code_rom) { . = ALIGN(4); __itcm0_code_start__ = .; KEEP(*(.itcm0_code)) . = ALIGN(4); __itcm0_code_end__ = .; } > int_itcm __itcm0_code_rom_end = __itcm0_code_rom + (__itcm0_code_end__ - __itcm0_code_start__); 3 EXTERNAL USE

  5. Step2: define ITCM section start and end address for ROM/RAM in linker file This will be used in init_table for data copying __RAM_ITCM0_CODE_START = __itcm0_code_start__; __ROM_ITCM0_CODE_START = __itcm0_code_rom; __ROM_ITCM0_CODE_END = __itcm0_code_rom_end; 4 EXTERNAL USE

  6. Step3: Add the ITCM start and end address into init_table for data copying. This table is defined in startup_cm7.s This file is located at C:\NXP\SW32K3_RTD_4.4_1.0.0\eclipse\plugin s\Platform_TS_T40D34M10I0R0\startup\src\m7\ gcc for MCAL users. This file is located at Project_Settings/Startup_Code/startup_cm7.s for S32DS RTD users. .section ".init_table", "a" .long 6 .long __RAM_CACHEABLE_START .long __ROM_CACHEABLE_START .long __ROM_CACHEABLE_END .long __RAM_NO_CACHEABLE_START .long __ROM_NO_CACHEABLE_START .long __ROM_NO_CACHEABLE_END .long __RAM_SHAREABLE_START .long __ROM_SHAREABLE_START .long __ROM_SHAREABLE_END .long __RAM_INTERRUPT_START .long __ROM_INTERRUPT_START .long __ROM_INTERRUPT_END .long __RAM_ITCM0_CODE_START .long __ROM_ITCM0_CODE_START .long __ROM_ITCM0_CODE_END .long __RAM_DTCM0_DATA_START .long __ROM_DTCM0_DATA_START .long __ROM_DTCM0_DATA_END 5 EXTERNAL USE

  7. Step4: Add __attribute__ ((section(".itcm0_code"))) in the function declaration and definition (namely in both .h and .c files) void __attribute__ ((section(".itcm0_code"))) testFuncItcm(uint32_t nGpioChannel){ return; } 6 EXTERNAL USE

  8. PLACE DATA INTO DTCM 7 EXTERNAL USE

  9. Step1: add DTCM section in linker file (after section .shareable_bss) This section s start and end address in ROM/RAM should also be defined __dtcm0_data_rom = __itcm0_code_rom_end; .dtcm0_data : AT(__dtcm0_data_rom) { . = ALIGN(4); __dtcm0_data_start__ = .; KEEP(*(.dtcm0_data)) . = ALIGN(4); __dtcm0_data_end__ = .; } > int_dtcm __dtcm0_data_rom_end = __dtcm0_data_rom + (__dtcm0_data_end__ - __dtcm0_data_start__); 8 EXTERNAL USE

  10. Step2: define DTCM section start and end address for ROM/RAM in linker file This will be used in init_table for data copying __RAM_DTCM0_DATA_START = __dtcm0_data_start__; __ROM_DTCM0_DATA_START = __dtcm0_data_rom; __ROM_DTCM0_DATA_END = __dtcm0_data_rom_end; 9 EXTERNAL USE

  11. Step3: Add the DTCM start and end address into init_table for data copying. This table is defined in startup_cm7.s .section ".init_table", "a" .long 6 .long __RAM_CACHEABLE_START .long __ROM_CACHEABLE_START .long __ROM_CACHEABLE_END .long __RAM_NO_CACHEABLE_START .long __ROM_NO_CACHEABLE_START .long __ROM_NO_CACHEABLE_END .long __RAM_SHAREABLE_START .long __ROM_SHAREABLE_START .long __ROM_SHAREABLE_END .long __RAM_INTERRUPT_START .long __ROM_INTERRUPT_START .long __ROM_INTERRUPT_END .long __RAM_ITCM0_CODE_START .long __ROM_ITCM0_CODE_START .long __ROM_ITCM0_CODE_END .long __RAM_DTCM0_DATA_START .long __ROM_DTCM0_DATA_START .long __ROM_DTCM0_DATA_END 10 EXTERNAL USE

  12. Step4: Add __attribute__ ((section(".dtcm0_data")))in the variables declaration and definition (namely in both .h and .c file) uint32_t __attribute__ ((section(".dtcm0_data"))) myDtcm0Data[1024] = {10, 9, 8, 7, 6, 5, 4, 3, 2, 1}; 11 EXTERNAL USE

  13. Tips ARM EABI GNU related sections overlay with TCM/data section RTD linker file does not include ARM EABI GNU reserved sections placement, user should add them and place them into Flash to avoid TCM(itcm/dtcm) or data section placement conflicts(overlap) .ARM.exidx : { } > int_flash *(.ARM.exidx*) *(.gnu.linkonce.armexidx.*) *(.glue*) *(.vfp11*) *(.v4*) *(.iplt*) *(.rel*) 12 EXTERNAL USE
