Efficient Animal Tracking with RFID Technology
RFID Based Animal Tracking System
Animal
Track
The Concern
Locating critical animals is one of the
greatest problem in animal forming
organizations today.
Why RFID for Animal Identification
1.
Enable Automatic Identification & Data
Collection(Contactless)
2.
Identification performed in milliseconds
I.
No line of sight required
II.
Contactless
III.
Works in a harsh environment
IV.
No human error involved
The Saviour
Why RFID for Animal Identifications(Continue
)
3. Avoid Error at data collection & Reduce Handling
mistakes.
4. Avoid Manipulation/ Tamperproof
5. Can read multiple items simultaneously
6. Avoid missing data for important decision
The Saviour
The Saviour
1.
The necessity for proof of ownership and identification
2.
Keepers to maintain records of origin, identity and destination
of animals.
3.
By collecting Secure, authentic & Real-time data one can get
correct statistical analysis and on time information which helps
to take decision making.
4.
Up-to-date record of all Animal’s births, deaths, movements,
treatment, vaccination, castration, Insemination, accident and
others information with dates.
5.
Improving management, sales of breeding animals and genetic
improvement.
6.
To Provide proper and timely treatment to the cattle with
health related case history
.
NEED OF Animal Identification & Management System :
How RFID Works?
Reader broadcasts
signal through antenna
Antenna
Tag
The Charged tag sends identifying
response back to the reader
Tag receives signal
and gets charged
C
o
p
p
e
r
c
o
i
l
a
n
t
e
n
n
a
Reader
C
h
i
p
P
o
l
y
e
t
h
y
l
e
n
e
M
e
d
i
a
RFID based Animal Tracking System
The animal tracking systems contains that each animal is having one
RFID Tag with its unique Identification code. This uses RFID technology
for tracking the animals, each animal has a unique RFID tag attached to
tits body which acts as a radio transmitter and has an unique code that
is different for other animals and RFID readers are located at various
locations to detect the animal movement and its location is updated on
the computer.
The Livestock & Animal Tracking RFID System
1.
Track Cattle, Sheep, Other
animals, Assets Secure and
manage your shelter, yard
monitor location and
availability and numbers of
animals
2.
Improve customer satisfaction
levels RFID makes Animal
Tracking System
3.
Robust
4.
Efficient
5.
Improves Responsiveness
Our Solution
•
AnimalTrack
RFID Solution automates
the tracking process, so we can
find/locate the animals effortlessly.
•
AnimalTrack
is a fully automated local
positioning system, a system for
finding, identifying and managing
animals and their locations in a
tracking area.
•
The
use of
AnimalTrack
is reflected in
time, cost and stress minimization and
more contentment at the animal
farming's organizations.
Our Solution
•
It is not unusual for hours to be wasted
in yard looking for a single animal.
•
With
AnimalTrack
, we can finally
concentrate on our important tasks.
•
Furthermore,
AnimalTrack
optimizes
our inventory/tracking/working
procedures.
•
By careful identification, animals can no
longer become mixed up-with many
more animals, the resulting
embarrassing consequences.
System Components
RFID Tags :
•
Paper thin label.
•
Placed inside the cover of each file/document.
•
Consists of an etched antenna and a tiny chip which
stores vital item information.
•
Including a unique ID number.
•
Provides identification and security in a single tag.
•
Password protected anti-theft security bit.
Specification :
•
Surface material: paper or PET
•
IC: NXP
•
Frequency: 860-960MHz
•
Protocol-ISO 18000 6C EPC Class 1 Gen 2
•
Operation: -40
0
C to 85
0
C
System Components
RFID Handheld Reader :
•
The Handheld RFID reader gives ability to capture a
comprehensive range of data from RFID tags to
images.
•
With this flexible multi-function handheld RFID reader,
which reads data in remote areas where fixed RFID
readers can’t reach.
Specification:
•
Read Range: 0.2ft to 8 ft.
•
Antenna: Integrated, linearly polarized
•
Frequency: 860-960MHz
•
Protocol-ISO 18000 6C EPC Class 1 Gen 2
System Components
Application Software :
•
The
AnimalTrack
application software
forms the backbone of the whole system.
•
It performs end to end functionality from
programming the RFID tags and employee
smart cards to query the system for
locating the position of a particular
animals.
System Components
RFID Server :
•
Central Control Unit for all the RFID
Stations in the local network.
•
Primary database server
•
Acts as a backup server in case of
connection failure
•
Web based Admin Console
•
Monitor and configure RFID
workstations, view customized reports
etc.
•
Define Access Control Levels to the
users.
Benefits
•
Eliminates searches for animals
•
Eliminates broadcast emails looking for animals
•
Performs animal room or area audit quickly
•
Eliminates duplicating/mix-up of animal
•
Fresh staff time for high value work
•
Improves productivity and reduces costs
•
Passively track animals as staff walk around
•
Help find critical animals very quickly
There is a strong ROI you can pull from RFID Animal Tracking, especially when
you consider the amount of valuables professionals looking for things.
The AnimalTrack RFID System :
Daphne Systems Private Limited
THANK YOU
Daphne Systems Private Limited
114, First Floor, Alaknanda Commercial Complex
LSC Plot No. 3 Vikas Kendra, E-Block Vikaspuri
Delhi – 110018. Mobile No. : +91-9910315436
Tel: 011-43021682 Email: info@daphnesystems.com
