Diffraction of Light: Types and Distinctions
Basanta Pathak
Associate Professor in Physics
Haflong Govt. College
Definition:
According to the wave theory of light , the
propagation of light is approximately rectilinear and
light waves of extremely small wavelengths exhibit
a slight bending in passing by the edge of an
obstacle. This bending of light waves round the
edge of an obstacle causing a rapid diminution in
the intensity of light within its geometrical shadow
is called the diffraction of light.
Distinction between the Interference and
Diffraction phenomena :
1.
Interference fringes are the result of interaction of light waves
arriving from different wavelengths but derived from the same
source.
Diffraction fringes are the result of interaction of light waves
arriving from different points of the same wave front.
2.
All the bright bands have uniform intensity.
All the bright bands have not the same intensity.
3.
Regions of minimum light intensity are perfectly dark.
Regions of minimum light intensity are not perfectly dark.
4.
Interference fringes may or may not have same width.
Diffraction fringes have never same width.
Types of Diffraction :
There are two types of diffraction phenomena.
These are………..
1. Fresnel’s diffraction and
2.
Fraunhofer’s diffraction phenomena.
Fresnel’s type of diffraction:
(i) In this type, the source of light or the screen or both are at finite
distances from the obstacle. No lenses are used to make the light
rays parallel or convergent.
(ii) The incident wave front is either spherical or cylindrical and are
never plane.
(iii) Fresnel’s diffraction is produced when light waves suffer
bending or diffraction at a straight edge, a narrow slit, a thin
wire, a small circular obstacle or a hole. A zone plate is an
example of this type of diffraction.
(iv)
As the incident wave front is not plane the phase of the
secondary wavelets have not same value at all the points of the
aperture or the obstacle producing diffraction.
Fraunhofer Types of diffraction:
(i)
In this type, the source of light and the screen are virtually at
infinite distances from the aperture or the obstacle producing
diffraction. This may be realized by placing a convex lens at a
distance equal to its focal length from the source, so that a
parallel beam may fall on the aperture. Then a second convex
lens is used to focus the emergent parallel beam after diffraction
on the screen. This inter-position of two lenses removes the
source and the screen to infinite distances.
(ii) In this case, the incident wave front is plane and so the phase of
vibration is same at every point of the aperture.
(iii) With this type of diffraction we get plane diffraction grating and
concave reflection grating.
The end.
Thanks
For
Your Co-operation
