HELIPORTS
Engr. Ian Talag
Heliport
A
heliport
is an identifiable area on land or water structures,
including buildings or facilities thereon, used or intended to be used
for the landing and take off of helicopters or other rotary wing
aircraft.
A
helideck
is a heliport located on a floating or an offshore
structure.
A
helistop
is an area developed and used for helicopter landings
and take offs to drop off or pick up passengers or cargo.
A
helipad
is a paved or other surface used for parking helicopters
at a heliport.
Heliport and Helideck
Classification of Heliports
Military Heliport
- facilities are operated by one of the
branches of the armed services. The design criteria are
specified in the branch of the service and usually prohibit
non military uses.
Federal Heliport
– facilities are operated by a non military
agency or department of the federal government. They are
used to carry out the functions appropriate to the agency.
Private Use Heliport
- facilities are restricted in use by
the owner. These may be publicly owned, but their use is
restricted, as in police of fire department use.
Public Use Heliport
- facilities are open to the general
public and do not require the prior permission of the owner
to the land. The extent of the facilities available may limit
operations to helicopters of specified sizes or weights.
Commercial Service Heliport
- these public use and public
owned facilities are designed for the use of helicopters in
commercial passenger or cargo service which enplane 2500
passengers annually and receive scheduled passenger
service with helicopters.
Personal Use Heliport
- facilities are used exclusively by
the owner.
Classification of Heliports
Factors Related to heliport site
selection:
The best locations to serve potential traffic
The provision of minimum obstructions in the approach
and departure areas
The provision of minimum disturbance from noise and
desirable location with respect to adjacent land use
The provision of adequate access to surface
transportation and parking
The minimization of cost to acquire and develop
The provision of two approach paths separated by at least
90 degrees and oriented with respect to prevailing winds
The avoidance of traffic conflicts between helicopters and
other air traffic
The consideration of turbulence and visibility restrictions
presented by nearby buildings
The provision of emergency landing areas along the entire
route for single engine helicopters.
Factors Related to heliport site
selection:
Principal Components of a Heliport
final approach and touchdown area,
the touchdown and liftoff area,
for large heliports, taxiways, helicopter parking
areas, and the terminal building area.
Final Approach and Takeoff Area
The final approach and takeoff area (FATO) is a
surface from which the helicopter can land or take
off.
The FAA allows the FATO to be any shape as long
as it is enclosed by a square of the dimensions
indicated in Table 15-2.
ICAO specifies that the FATO is a circle.
Typical
Heliport
Layout
Its size depends primarily on the overall length of
the largest helicopter to be accommodated by the
heliport.
For precision instrument operations the final
approach and takeoff area is 300 ft wide by 1225
ft long and incorporates a
final approach reference
area (FARA) which is an obstruction free
area 150 ft
by 150 ft located at the far end of the final
approach and takeoff area.
Final Approach and Takeoff Area
Geometric Design Standards for Heliports
Geometric Design Standards for Heliports
Touchdown and Liftoff Area
Within the final approach and takeoff area, an area
is designated for the normal everyday landing of
helicopters.
The TLOF area is usually defined by a solid border
painted on the pavement surface.
The recommended dimensions of the touchdown and
liftoff area are given in Table 15-2.
Peripheral Area
A peripheral or clearance area surrounding the final
approach and takeoff area is recommended as an
obstruction free safety zone.
The area should be kept free of objects hazardous to
the operation of helicopters.
The clearance from the edges of the final approach
and takeoff area required for this area is also given in
Table 15-2.
Terminal Area
At heliports where the volume of traffic is relatively small, the
loading and unloading of passengers can be accomplished within
the final approach and takeoff area.
As traffic increases, it becomes necessary to provide additional
space for the parking of helicopters and passenger processing.
This is usually accomplished on a helipad which is an area
adjacent to the terminal building for processing passengers.
This area provides for one or more parking spaces for helicopters and
is similar in nature and function to the gate or ramp area provided on
the apron adjacent to airport terminal facilities.
Clearances between adjacent helicopter parking positions are
provided so that a separation is provided between the rotor planes
of helicopters as shown in Table 15-2.
The helipad is connected to the final approach and takeoff area by
taxiways and taxilanes.
The width of these taxiway routes and the taxilanes adjacent to the
helipad are given in Table 15-2.
Terminal Area
Marking of Heliports
The primary purpose for marking heliports is to identify the area
clearly as a facility for the use of helicopters.
The requirements for marking heliports are specified by the FAA and
the ICAO.
Essentially these requirements consists of painting an equilateral
square with an “H” in the center of the touchdown and liftoff area.
For hospital heliports a white cross is also inscribed within the square
along with the letter “H” as shown in Fig. 15-6
Marking delineating the edges of the final approach
and takeoff area should be broken white lines whereas
on the touchdown and liftoff area the edges should be
delineated by continuous white lines.
Taxiway centerlines are delineated by solid yellow lines
and taxi route centerline and apron edge markings
should be solid yellow lines.
Taxiway edges should be marked by a double solid
yellow line.
Marking of Heliports
For operation during hours of darkness various
types of lights are suggested.
The amount of lighting depends on the character
and volume of operations.
More lighting is required for scheduled air carrier
operations than for private heliports with occasional
use.
Lighting of Heliports
