Integrated course Energy Economics - Energy Balances Chair of Energy Systems Prof. Dr. Boris Heinz | Dr. Elena Timofeeva elena.timofeeva@tu-berlin.de

Outline Energy balances recap Group presentations Seite 2

Energy Balances: Recap Define the components of an energy flowchart and draw a scheme with the given components. Energy imports Domestic extraction Gross Energy Export Total Final Consumption (TFC) Losses Non-energy consumption Industry, Transport, Households, Commercial Useful Energy Seite 3

Energy Balances: Recap Define the components of an energy flowchart and draw a scheme with the given components. Seite 4

Question 2: RES in German energy balance Energy balances of Germany 2017 (AGEB) PJ 2.353.457 769.673 32,7% TWh 653.738 213.798 Cell AD39 AD33 Total electricity output Hydro, wind, PV and other RES share in total output TPES RES in TPES 13.522.990 1.797.459 3.756.386 AI15 499.294 SUM(Z15: AB15) RES share in TPES 13,29% Avr efficiency of RES power pl.: 769.673 PJ / 1.797.459 PJ = 42% But: Hydro, wind and PV cannot be separated from biomass and renewable waste. Seite 5

Question 2: RES in German energy balance (continued) IEA Atlas of Energy: Germany Electricity generation (TWh) RES generation (TWh) RES share in electricity (%) RES share in TPES (%) 647,7 216 33,0 13,0 AGEB uses IEA method to account for RES in TPES. But: these is a slight discrepancy in RES generation (in TWh). Apart from Hydro, wind, PV and other , the German energy balances list Industrial power stations (lines 19 and 13), part of which may be based on RES. Seite 6

Question 10: TFC of road transport Energy balances of Germany 2010 and 2017 (AGEB) PJ Motor gasoline Diesel oil LPG Natural gas Biomass & ren. wastes Electricity Total 2010 791.416 1.168.063 21.823 8.768 119.371 2017 719.580 1.425.424 15.377 5.848 108.349 - 2.109.441 565 2.275.144 See line 69 Road transport Seite 7

Question 10: TFC of road transport Energy balances of Germany 2010 and 2017 (AGEB) 2010 2017 0% 0% 0% 1% 0% 1% 5% 6% 31% 38% 55% 63% Gasoline Natural gas Diesel Biomass LPG Electricity Gasoline Natural gas Diesel Biomass LPG Electricity Increase in diesel share (55% 63%): taxation and engine efficiency as possible reasons. 2017: electricity comes in Seite 8
