Byzantine Fault Tolerance: Protocols, Forensics, and Research
BFT Protocol Forensics
Kartik Nayak
Peiyao Sheng, Gerui Wang, Sreeram Kannan, Pramod Viswanath
State Machine Replication
A group of servers provide
the same interface as a
single non-faulty server even if some of the servers
are Byzantine faulty
(Safety) Any two non-faulty servers do not learn
different sequence of values
(Liveness)
A value proposed by a client will be
eventually executed by every non-faulty server
cmd
i
cmd
j
BFT Protocol Research
•
40 years of research
•
Byzantine Agreement:
•
Byzantine threshold:
t < n
•
Actual number of faults:
f
•
Safety and liveness:
f ≤ t
Tolerate
more
faults
Better
efficiency
Q: What happens when f > t?
BFT Protocol Forensics
•
What happens when
f > t
?
•
Safety and/or liveness can be violated
•
Forensic support:
provide irrefutable evidence of bad
behavior
•
Is it always possible?
•
What does it take to obtain such evidence?
for d > n-2t
BFT Protocol Forensics
Actual number of Byzantine parties (f)
n-t
t
Safe and live
Forensic support
(d = t+1)
No forensic support
d: Number of Byzantine replicas detected
Existing Works on Forensic Support for BFT
•
Multiple previous works
•
PeerReview, Casper, Polygraph, Grandpa BFT, …
•
To design protocols with forensic support (accountability)
•
Our goal: Analyze existing protocols based on
•
Number of Byzantine replicas detected
(d)
•
Number of witnesses
•
Distributedness
(k)
Today’s Talk
Byzantine parties held culpable (
d)
Honest parties involved (k
)
HotStuff
d = t + 1
k = 1
Algorand BA
d = 0
k = n - f (all honest parties)
HotStuff
•
Partially synchronous protocol, tolerates 1/3
rd
Byzantine
faults
[YMRGA’19]
propose(v, hQC)
vote2(v)
vote3(v)
precommitQC(v)
commitQC(v)
Messages in some view e
(2t+1 votes)
HotStuff: Key Invariant
vote3(v)
: “locked on
v
; will not vote differently”
propose(v, hQC)
vote1(v)
vote2(v)
vote3(v)
prepareQC(v)
precommitQC(v)
commitQC(v)
Messages in some view e
HotStuff: Key Invariant
vote3(v):
“locked on
v
; will not vote differently unless it is safe”
propose(v, hQC)
vote1(v)
vote2(v)
vote3(v)
prepareQC(v)
precommitQC(v)
commitQC(v)
Messages in some view e
hQC: highest prepareQC
known to leader
“it is safe”:
hQC
shared by leader is from a higher view
An Attack Across Views
No commits in these views
. . .
Q: Which parties are Byzantine?
No commits in these views
Hint:
D
is not, it did not
vote3(v)
. . .
Observe:
vote2
,
vote3
do not matter
Claim:
B
and
C
are culpable.
Claim: B and C are culpable
A
C
B
D
View e
commitQC(v)
“Party i commits v”
View e’
No commits in these views
Propose(v’, hQC)
commitQC(v’)
“Party j commits v’ ”
A: False,
hQC
can be a
prepareQC
on
v’
in some view
> e
vote3(v)
Holds for all views
> e
except the first one where
prepareQC
was formed
Identifying Culpable Replicas (Across Views)
A
C
B
D
View e
commitQC(v)
“Party i commits v”
View e’
Propose(v’, hQC)
commitQC(v’)
“Party j commits v’ ”
View e*
Propose(v’, hQC)
not vote1
vote1
vote1
vote1
vote3(v)
We’re locked on v
in view e
prepareQC(v’)
We are locked on
v’ or our locks
are older than e
e*
:
first higher view
prepareQC
for a different value was formed
(hQC from a lower view)
Identifying Culpable Replicas (Across Views)
•
Culpable replicas: Intersection of
commitQC(v)
and parties
forming the first
prepareQC(v’)
Q: Who has access to the first
prepareQC(v’)
formed in
e*
?
A: If
v’
was committed,
2t+1-f
honest parties hold
prepareQC(v’)
-
Many witnesses
Identifying Culpable Replicas (Across Views)
•
Culpable replicas: Intersection of
commitQC(v)
and parties
forming the first
prepareQC(v’)
Q: How do we know
e*
was the first such view?
A: Implementation details matter
-
Depending on information included with
vote1(v’)
, we can have
(a)
Single witness identifying
t+1
Byzantine replicas
(b)
Require multiple witnesses
(c)
Have no forensic support even after obtaining all honest
transcripts
Today’s Talk
Byzantine parties held culpable (
d)
Honest parties involved (k
)
HotStuff
d = t + 1
k = 1
Algorand BA
d = 0
k = n - f (all honest parties)
Algorand BA
•
Synchronous protocol, tolerating 1/3 faults
[CM’16]
•
Byzantine Agreement on a binary value
Algorand BA
•
Propagate local value
b
•
Receive values within a synchronous step:
•
#(0)
> 2t
, update
b
= 0 (terminate if step 1)
•
#(1)
> 2t
, update
b
= 1 (terminate if step 2)
•
Else
•
Step 1: set
b
= 0
•
Step 2: set
b
= 1
•
Step 3: set
b
= common coin
Step 1
Step 2
Step 3
Safety intuition
(f ≤ t)
: Suppose a party commits
b
= 0
-
All
(> 2t)
honest parties have
b
= 0
-
Honest parties never change their value to
b
= 1
Safety Violation when f > t: World 1
•
Propagate local value
b
•
Receive values within a synchronous step:
•
#(0)
> 2t
, update
b
= 0
•
#(1)
> 2t
, update
b
= 1
•
Else
•
Step 1: set
b
= 0
•
Step 2: set
b
= 1
•
Step 3: set
b
= common coin
Step 1
Step 2
Step 3
Safety intuition
(f ≤ t)
: Suppose a party commits
b
= 0
-
All
(> 2t)
honest parties have
b
= 0
-
Honest parties never change their value to
b
= 1
f > t
≤ 2t
can
Byzantine do not send 0
Honest parties switch to b = 1
World 1 Culprits: Parties who did not send b
•
Propagate local value
b
•
Receive values within a synchronous step:
•
#(0)
> 2t
, update
b
= 0
•
#(1)
> 2t
, update
b
= 1
•
Else
•
Step 1: set
b
= 0
•
Step 2: set
b
= 1
•
Step 3: set
b
= common coin
Step 1
Step 2
Step 3
Safety intuition
(f ≤ t)
: Suppose a party commits
b
= 0
-
All
(> 2t)
honest parties have
b
= 0
-
Honest parties never change their value to
b
= 1
f > t
≤ 2t
can
Byzantine do not send 0
Honest parties switch to b = 1
World 2 Culprits: Parties who switched to b = 1
•
Propagate local value
b
•
Receive values within a synchronous step:
•
#(0)
> 2t
, update
b
= 0
•
#(1)
> 2t
, update
b
= 1
•
Else
•
Step 1: set
b
= 0
•
Step 2: set
b
= 1
•
Step 3: set
b
= common coin
Step 1
Step 2
Step 3
Safety intuition
(f ≤ t)
: Suppose a party commits
b
= 0
-
All
(> 2t)
honest parties have
b
= 0
-
Honest parties never change their value to
b
= 1
f > t
≤ 2t
can
Byzantine do not send 0
Honest parties switch to b = 1
All parties send 0
Byzantine parties switch to b = 1
Summary
•
Two protocols: HotStuff and Algorand BA
•
HotStuff has strong forensic support
•
Algorand BA does not have any forensic support
•
Implementation details matter
•
Our paper:
•
PBFT, VABA
•
Implement forensic client on DiemBFT
•
Generic impossibility results
