Basic Terminology in Library Information Systems
LRM Terminology
LRM Module 2
Standing Committee on Training
Program for Cooperative Cataloging (PCC)
March 2020
Basic Terminology—Overview
•
All definitions* taken from LRM Chapter 7, Glossary of Modelling
Terminology
•
Vocabulary mostly originates from the entity-relationship model
•
Some vocabulary familiar from FRBR, but be cautious—it may be
somewhat differently defined
* Except Inheritance
2
Terminology Covered in this Module
•
Class
•
Entity
•
Superclass
•
Subclass
•
Disjointedness
•
Property
•
Attribute
•
Relationship
•
Inheritance
•
Domain
•
Range
•
Reification
3
Class
•
LRM gives no formal definition for class, although the term is used
often
•
Here are some definitions from common usage and from the RDF
schema:
•
“A group, set, or kind, sharing common attributes” (
Merriam-Webster
)
•
“Resources may be divided into groups called classes. The members of a
class are known as
members
of the class” (
RDF Schema 1.1
)
•
The class concept is inherent to the enhanced entity-relationship
model, but not part of a basic entity-relationship model
4
Entity
An abstract class of conceptual objects, representing the key objects of
interest in the model
… that is, “the key objects of interest to users of library information systems.”
(LRM 4.1.1.)
•
Entities
are treated as classes in LRM; the term
entity
tends to be used mostly
for the LRM entities, while
class
is used for non-RDA entities and descriptions of
LRM entities. Other Modules will define and explain specific LRM
entities
.
•
The primary benefit of treating
entities
as classes is that it also introduces the
relational concepts of
superclass
and
subclass
5
Class relationships--Superclass
•
An entity may group several entities/classes together in a superordinate class, a
more general class under which a set of more specific classes is incorporated.
This is known in LRM as a
superclass.
Example:
The entity
Agent
is the superclass of the
entities
Person
and
Collective Agent
6
Class relationships--Subclass
Multiple entities may be grouped into a superordinate entity, if all their instances
are instances of that larger entity. This is known as a
subclass.
The LRM definition
is:
“An entity, all of whose instances are also instances of a larger, superordinate
entity.”
The relationship is described as an “isA” relationship
Example:
The entities
Person
(an individual) and
Collective
Agent
(a group) are subclasses of the entity
Agent
.
Person
“isA”
Agent
Collective Agent
“isA”
Agent
7
Entity Hierarchy: Superclass, Class,
Subclass
(IFLA Library Reference Model, August 2017, as amended and corrected through December 2017 (IFLA LRM (2017-12))
8
Disjoint Entities
Entirely non-overlapping sets. Disjoint entities can have no instance
that is simultaneously an instance of more than one of these entities
“IFLA LRM declares that, other than those entities related by the
“isA” hierarchies, the entities in the model are disjoint.” (IFLA LRM
(2017-12) 5.2)
9
Disjointness is easy!
Some examples of disjointness are easily understandable.
For example, something cannot be both an instance of the
person
entity and an instance of the
collective agent
entity.
These entities have an “isA” relationship to the entity
agent
, but they
are disjoint to each other.
(cannot be a)
10
Maybe not always easy.
Disjointness is less obvious but equally important when something is considered in
different aspects.
For example:
Hamlet
as
work
,
expression
,
manifestation
, and
item
: all may share
the same
nomen string
(can be referred to by the same name) but are nonetheless
different and
disjoint
entities
11
Property, Attribute,
Relationship
Property:
An attribute or relationship of an entity
Attribute:
A type of data which characterizes specific instances of an entity
Relationship:
A connection between instances of entities
Attributes
and
Relationships
are discussed more fully in subsequent modules.
12
Inheritance
Definition:
Modeling in which an entity or class automatically acquires all the attributes
and relationships from its superclass.
Example:
The
Agent
entity has the following attributes:
■
Contact information [LRM-E6-A1]
■
Field of activity [LRM-E6-A2]
■
Language [LRM-E6-A3]
The
Person
entity “inherits” these attributes and adds the following attribute:
■
Profession/Occupation [LRM-E7-A1]
13
Properties--Inheritance
•
Any property (
relationship
or
attribute
) that applies to a
superclass
also applies to all entities of its
subclasses
•
Example:
Any relationship or attribute that applies to the entity
Agent
also
applies to the entity
Person
(a subclass of
Agent
), and therefore does not
need to be specifically declared for
Person
•
The entity
Agent
has the
attribute
Language, defined as “A language used by the
agent
when
creating an
expression
.” The entity
Person
is a subclass of the entity
Agent
and therefore also
has the attribute Language
•
The
relationship
“is member of” is defined for the entity
Agent
. It also applies to the entity
Person
, which is a subclass of the entity
Agent
14
Relationships--Domain & Range
Domain:
The source entity, or departure point, for a relationship
Range:
The target entity, or arrival point, for a relationship
To use a grammatical analogy,
Domain
and
Range
can be thought of as
the subject and object, respectively, of a relationship.
15
Domain & Range
For example:
In the relationship “
Work
‘is realized through’
Expression
,” Work is the
domain
and
Expression is the
range
.
In the inverse relationship “
Expression
‘realizes’
Work
,” Expression is the
domain
and Work is the
range
.
Domain
and
Range
are revisited in later modules
16
Reification
•
Process through which a relationship is modelled as an entity, so
that it can in turn have its own attributes and relationships
In non-technical English, to reify is “To regard or treat (an abstraction) as if it
had concrete or material existence. [Latin
rēs
,
rē-
, thing … + fy.] (
American
Heritage Dictionary
, third edition.)
Reification in LRM is just a specialized instance of this. Relationships are not
entities in LRM, but treating them as if they were allows them to be more fully
described and discussed (as in Table 4.7 and the detailed definition in 4.3.3).
•
Reification is further discussed in later modules
17
