Argon Shrouding for Metallurgy Applications
Argon Shroud Efficiency
Kelly E. Stewart
Ingot Metallurgy Forum
March 28, 2017
1 of 15
•
What is argon shrouding?
•
Why use it?
•
Test equipment
•
Experiment design
•
Trials
•
Results and Discussion
OUTLINE
2 of 15
WHAT IS ARGON SHROUDING?
Fiber shroud
Kaowool gasket
•
Use of an inert gas to provide a
protective neutral environment
surrounding the teeming stream
•
Effectiveness depends on:
–
Shroud design
–
Argon flow rate
WHY IS IT NECESSARY?
•
Turbulence while teeming increases environmental
interaction
•
An average teeming stream has enough surface area to
encourage oxygen absorption
•
Reintroduced oxygen can be consumed immediately by Al
and/or Si in the steel
–
Silica
–
Alumina
3 of 15
WHY IS IT NECESSARY?
•
Prevent re-oxidation of steel stream
•
Reduce oxygen, nitrogen, and hydrogen in final product
•
Prevent “steelcicles”—steel build up on trumpet
4 of 15
5 of 15
SHROUDING AT EQS
6 of 15
HOW TO GAUGE EFFECTIVENESS OF SHROUDING
•
Oxygen content under the
shroud while teeming
•
Oxygen sensor
–
Alpha Omega 2000 series
–
Input gas line attached
and secured under the
shroud, near the steel
stream
www.aoi-corp.com/oxygen-analyzers/percent/series-2000
7 of 15
OXYGEN CONTENT UNDER THE SHROUD
•
Oxygen under shroud was used as an
approximation
•
Less oxygen under shroud
less atmosphere
interaction
less O, N, and H exposure to steel,
implied
•
No direct correlation to hydrogen pick up in steel
–
Other factors in the bottom pour process inherently
affect hydrogen content and cannot be nullified
•
Refractory brick, teeming flux, etc
8 of 15
EXPERIMENTAL DESIGN
9 of 15
PARAMETERS
•
Oxygen sensor lance placed under shroud manually
•
Three flow rates were compared
–
Minimum 5 trial heats per flow rate
•
Oxygen content measured until a plateau was maintained
for over two minutes
•
Steady oxygen content reported
10 of 15
ARGON FLOW RATE AS COMPARED WITH
OXYGEN CONTENT UNDER THE SHROUD
11 of 15
ARGON FLOW RATE AS COMPARED WITH
OXYGEN CONTENT UNDER THE SHROUD
12 of 15
OXYGEN CONTENT RESULTS, SUMMARIZED
•
Any result below 0.50% O
2
was deemed adequate
•
A flow rate of 90 cfh or 120cfh yields similar
oxygen content
13 of 15
MISCELLANEOUS TRIAL HEATS
•
One heat was teemed with the maximum possible argon
flow rate: 190 cfh
–
oxygen content under the shroud = 0.43%
•
Purposefully inducing a poor seal between the shroud and
the trumpet kaowool blanket did not adversely affect
oxygen content
–
30 cfh, 0.34% oxygen
–
90 cfh, 0.39% oxygen
14 of 15
DISCUSSION
•
As argon flowrate ↑, oxygen content under the shroud ↓
•
This holds true until flow rate exceeds
90 cfh
•
Eventually, a positive pressure keeps the shroud purged,
relatively oxygen free.
–
At this pivot point, excess argon was unnecessary + at extra cost
