Adaptive Observing Techniques for Weather Forecasting

This presentation by Dr. Rolf H. Langland explores the concept of adaptive observing in atmospheric applications, focusing on the methodology, field programs, challenges, and objectives of targeted observing. It delves into the optimization problem of determining locations for special atmospheric observations and the integration of these observations into data assimilation methods to improve weather forecasting. The talk emphasizes the importance of objective targeting using models to reduce forecast uncertainty and enhance the accuracy of high-impact weather forecasts.

• Adaptive Observing
• Targeted Observations
• Weather Forecasting
• Data Assimilation
• Atmospheric Applications

qguth Follow

Uploaded on Sep 19, 2024 | 0 Views

Download Presentation

Please find below an Image/Link to download the presentation.

The content on the website is provided AS IS for your information and personal use only. It may not be sold, licensed, or shared on other websites without obtaining consent from the author. Download presentation by click this link. If you encounter any issues during the download, it is possible that the publisher has removed the file from their server.

Presentation Transcript

1. Overview of Adaptive Observing 1 Rolf H. Langland (NRL-Monterey) NRL-Monterey Dr. Rolf H. Langland JCSDA Summer Colloquium on Data Assimilation Santa Fe, N.M., 2 August 2012

2. Outline of Presentation 2 1.What is adaptive ( targeted ) observing? 2. Targeting methodologies 3. Targeting field programs (1997-2012) 4. Challenges for adaptive observing Note: this talk describes adaptive observing for atmospheric applications ocean adaptive observing techniques have also been developed

3. What is Targeted Observing ? 3 If one has the capability to add ~10-10,000 special atmospheric observations that can be assimilated to improve the forecast of a particular weather event, can the locations be determined using objective (e.g., model-based) methods? Optimization problem with two constraints 1. The probability of making an analysis error at a particular location 2. The intrinsic instability of the flow in that location sensitivity Can the data assimilation method accurately incorporate the special observations? [MORE IMPORTANT THAN INITIALLY BELIEVED !!]

4. Targeted Observing Objectives 4 Improve 0 to 7 day forecasts of high-impact weather: Tropical cyclone track Extra-tropical winter storms [wind, precipitation] Forecast systems: Global and regional deterministic models of operational forecast centers Ensemble forecast systems [goal: reduce forecast uncertainty]

5. Targeted Observing Resources 5 Dropsondes from reconnaissance aircraft On-demand upper-air soundings from land- and ship-based radiosondes Land and ship surface observations Airborne lidar Un-manned aerial vehicles On-demand satellite rapid-scan wind observations

6. Objective vs. subjective targeting 6 Objective targeting involves use of an adjoint model or ensemble system to identify observation target areas through estimates of analysis uncertainty and potential forecast error growth Subjective targeting is based on inspection of map features or forecaster intuition Jet streaks PV anomalies Hurricane structure Goal of objective targeting is not to correct the largest analysis error, but the analysis error that leads to the largest forecast error 6

7. Uncertainty in Atmospheric Analyses 7 GFS | ECMWF Jan-Dec 2010 ms-1 Root-Mean Square of Analysis Differences: 300mb u-wind

8. Singular Vectors in 72-hr East Coast Storm Forecast Initial Time Total Energy 12Z 22 Jan 2000 Final Time Sfc Pressure 12Z 25 Jan 2000 8 SV 1 SV 2 SV 3 Forecast error growth is controlled by a few rapidly-growing perturbation structures 8

9. Large error growth in a 5-day forecast 9 NOGAPS Forecast hour Forecast Error Potential Target Region Error starts in mid-Pacific Remnant of tropical storm Kiko Global total energy error norm (J kg-1)

10. U-2 Hurricane Flights (1960-1968) Before the days of objective targeting 10 Click to enlarge Click to enlarge In 1956, the US Weather Bureau, reacting to the devastation of three consecutive hurricane strikes along the east coast of the United States, received Congressional funding to establish the National Hurricane Research Project to conduct research on tropical cyclones that would advance our scientific understanding of these storms and provide the means to improve the accuracy of future hurricane forecasts. During this process, the NHRP began to ponder the horizontal thermal and vertical wind structures in the upper Troposphere / lower Stratosphere region of tropical cyclones. At the time, there were no high-altitude aircraft adequate to probe these upper regions over the tops of tropical cyclones, except the U-2. Beginning in early 1960, the AFCRL made available a U-2 to the Weather Bureau's hurricane research project (NHRP) and its component Project Stormfury (an experimental hurricane modification project) providing high- altitude photographs and gathering meteorological data in the Troposphere region over the hurricanes. Storms flown by the AFCRL U-2 included Hurricanes Donna (60), Carla (61), Esther (61), Flora (63), Beulah (63), Ginny (64), Isbell (64), Betsy (65) and Beulah (67) to name just a few.

11. Field Programs for Targeted Observing 11 Programs for winter storm targeting: [Operational*] North Atlantic (FASTEX-1997, ATREC-2003) Eastern North Pacific (NORPEX-1998, WSRP-1999-2012) Entire North Pacific (Winter T-PARC 2009) Programs for hurricane / tropical cyclone targeting: North Atlantic (NOAA-HRD, 2000-2012) Western Pacific (DOTSTAR, 2003-2012) T-PARC (TCS-08) 2008 Antarctica: CONCORDIASI (2010-2011) Participants: Meteo France, ECMWF, UKMO, NRL, NCEP, NCAR, NOAA-AOC, NOAA-HRD, USAF Hurricane Hunters, NASA, CIMSS, MIT, Univ. of Miami, others

12. FASTEX first objective targeted observing program 12 January February 1997 Shannon Goose Bay St. John s St. John s NOAA G-IV flights Learjet flights 8 targeted dropsonde missions tasked by Meteo France & NRL 12 targeted dropsonde missions tasked by NCEP and NCAR Adjoint-based targeting Ensemble-based targeting

13. FASTEX targeting example (IOP-17) 13 Sensitivity to 700mb Temperature J Forecast Verification Region WARMER J = Vorticity (measure of cyclone intensity) 700 COLDER Interpretation: the 42-hr forecast error over UK is most sensitive to the structure of this trough Adjoint-based target guidance to improve 42-hour forecast of intense cyclone over Ireland and Great Britain

14. The observation target region 14 A region in which initial condition error is expected to cause significant forecast error or uncertainty at the forecast verification time Occur in dynamically significant regions (baroclinic zones, strong advection, jet entrance / exit) The key initial error may involve relatively small changes to temperature and wind structure Does not necessarily correspond to most prominent synoptic features (surface low, PV max)

15. FASTEX IOP-17 E-W Cross-section of Singular Vector target 15 15 15

16. Dropsonde Aircraft in FASTEX (1997) 16 Manned Reconnaissance Aircraft GPS Dropsonde Deployed from 24,000 40,000 ft. NOAA GIV Dropsondes, which are radiosondes deployed from aircraft, measure temperature, humidity, pressure, and wind speed/direction, as they fall through the atmosphere Temperature Accuracy +/- 0.2% at 40C 16

17. Target Planning Time-Line 17 Current time Decision time Adaptive sampling (analysis) time Verification time ti td ta tv t Targeting Calculations Observations How do we choose the optimal deployment of observations to improve a forecast between times ta and tv? It has proven feasible to prepare targeting guidance ahead of time, and deploy in-situ observational resources (e.g., dropsondes) into identified target regions

18. Vertical cross-section of sensitivity information from NOGAPS adjoint model 18 Jet Stream Level Dropsonde profiles Surface Level Dropsondes provide vertical profiles of temperature, wind, and humidity in region of maximum dynamic sensitivity (error source region)

19. NORPEX Targeting Mission (1998) 19 Forecast Verification + 2 days SV Target Area 19

20. NORPEX-98 Targeting Example (48-hr impact) 20 300mb wind 300mb wind SV Target Area With targeted dropsondes: 48hr fcst error* reduced by 35% in verification region Sea Lev Pres Sea Lev Pres *Fcst error is E- weighted error of T, u, v, ps from surface to 250mb SV Target Area NOGAPS 20

21. NORPEX-98 Targeting Example (96-hr impact) 21 Impact of 30 dropsondes on a 96-hr NOGAPS Forecast during NORPEX (Feb 1998) Control Forecast Forecast with Targeted Data Target Region for special dropsonde observations Significant Enhancement of Precipitation in Storms over California and Florida

22. Impact of NORPEX targeted dropsondes 16 January 27 February 1998 (NRL-NCEP) 22 In 45 forecast cases, ~ 10% mean error reduction over western North America, using NOGAPS forecast model RMSE 500mb ht of2-day forecasts 10% mean error reduction Approx 700 dropsondes (45 cases) 45 forecast cases IMPROVED FORECASTS (n=35) DEGRADED FORECASTS (n=10) error with targeted dropsondes (m) Langland et al. 1999 (BAMS)

23. Results of Early Targeting Field Programs (1997- 2003) 23 FASTEX, NORPEX, WSRP, ATREC (mid-latitude programs), and tropical cyclone targeted with dropsondes primarily involve small sets of in-situ observations deployed intermittently Average 10% reduction in 1-3 day forecast error over regional verification areas maximum reductions as large as 50% in certain cases Approx. 60-70% of forecast cases improved Target areas incompletely surveyed in vast majority of field program cases Impact per-observation of targeted data is about 3x larger than observations placed randomly, but total impact is generally limited by the relatively small number of targeted data Based on studies at ECMWF, Meteo France, NOAA, NRL and other centers

24. Increasing the impact of targeted observing 24 Goal 1: Increase the average beneficial impact of targeted data in deterministic and ensemble forecasts Goal 2: Increase the percentage of forecasts that are improved by targeted data Assimilate larger amounts of satellite, remote-sensed, and in-situ observations in target regions - do not rely on intermittent small sets of observations

25. Targeting and Observation Impact Questions 25 Why does assimilation of good observations make some forecasts worse ? Why doesn t the assimilation of 10-50 dropsondes produce larger impacts on forecast skill? Examine the data assimilation procedure

26. Impact of Observations on Forecast Error 26 OBSERVATIONS ASSIMILATED e e 30 Xb 24 Xa 00UTC +24h = 30 e e e The forecast error difference, assimilation of observations at 00UTC , is due to the 24 30 24 Langland and Baker (Tellus 2004)

27. USING ADJOINT-BASED OBSERVATION IMPACT TO EVALUATE IMPACT OF TARGETED DATA [WSRP DROPSONSDES] 27 1 Jan 28 Feb 2006 00UTC Analysis Beneficial (-0.01 to -0.1 J kg-1) Non-beneficial (0.01 to 0.1 J kg-1) Small impact (-0.01 to 0.01 J kg-1) NOAA-WSRP 191 Profiles Date: Jan-Feb 2006 Result: Average targeted dropsonde profile impact is beneficial placement in sensitive regions provides 2-3x larger impact than average radiosonde profile Observation impact is determined by size of innovation, assumed observation and background errors, distribution of other nearby observations and intrinsic error growth properties of the atmosphere in that location

28. 28

29. 29 FORECAST ERROR INCREASE FORECAST ERROR INCREASE FORECAST ERROR REDUCTION FORECAST ERROR REDUCTION

30. Probability of improving or degrading a forecast 30 Probability of forecast degradation from assimilation of new observations (percent) Forecast degradations occur because the observation and background errors are not precisely known however, our estimates of these errors work well if the number of assimilated observations is very large . 50 Many observations small chance of forecast degradation Few observations significant chance of forecast degradation 0 1,000 1 10 10,000 100 Number of additional data assimilated One observation CAN change a forecast But adding small sets of observations is not a reliable method for targeted observing

31. Advanced Targeting Hypotheses 31 Amount and quality of data added is more important than small inaccuracies in target area guidance [better to cover entire target area than to place a few observations in location of maximum sensitivity] Continuous addition of targeted data for several days leading up to the critical analysis time is essential for larger forecast impact [conditioning of background]

32. Satellite observations = targeting resource Observation selection is a form of targeting 32 Radiances from infrared and microwave sounders on polar orbiters Cloud and water vapor motion vectors from geostationary platforms Surface winds from space-based scatterometers LESS THAN 2% OF ATMOSPHERIC OBSERVATIONS ARE ACTUALLY ASSIMILATED FOR OPERATIONAL FORECASTING Satellite channel-selection Regional variations in satellite observation data-thinning Addition of rapid-scan AMVs

33. Rapid-Scan Satellite winds for Targeted Observing 33 Regular: 30min scan RAPID-SCAN: 3min sampling Improved data quantity and quality AMVs at 08GMT, 7th August 2007, during TCs Wutip and Pabuk Source: JMA, CIMSS

34. 34 34 34 observations,

35. Medium-RangeTargeted Observing Example 35 Target Regions for 72h Forecast of Hurricane Floyd HURRICANE VORTEX at targeting time UPSTREAM MID- LATITUDE SHORT-WAVE at targeting time NOGAPS Adjoint Sensitivity Gradient VERIFICATION AREA Target: 00UTC 13 Sep 1999 Forecast Verifies: 00UTC 16 Sep 1999

36. Rapid scan targeting for Hurricane Katrina 36 Average 12% reduction in track forecast errors [24hr-120hr] Upstream trough affects medium-range forecasts Katrina position at 00UTC 30 Aug 2005 Katrina position at 00UTC 27 Aug 2005 Region around cyclone vortex is sampled by dropsondes RS-wind vectors: assimilated every 6-hr from 00UTC 20 Aug to 120UTC 29 Aug 2005 Source: NOAA, CIMSS

37. Rapid-Scan and Dropsonde targeted observing in super-typhoon Sinlaku 10-18 Sep 2008 [TCS-08] Rapid-Scan Winds 37 Rapid-scan winds produce significant reduction in 24hr forecast error energy norm new data in areas that cannot be sampled with dropsondes -1.95 J kg-1 Forecast Error Reduction Forecast Error Increase Dropsondes and Driftsondes Dropsondes in this case do not reduce 24hr forecast error energy norm + 0.10 J kg-1 Forecast Error Reduction Forecast Error Increase

38. RAPID-SCAN WINDS IMPROVE SUPER-TYPHOON SINLAKU FORECASTS 38

39. DOTSTAR Targeting Mission 00UTC 10Sep 2008 On average, small improvements in track forecasts from added dropsondes 39 Target Areas Super-Typhoon Sinlaku [much larger than area sampled with dropsondes (at left)] 8th 12th 10th Targeting guidance prepared Targeted observations deployed Forecast verification

40. Winter T-PARC Field Program Feb 2009 40 TARGETED SPECIAL RAOB PROFILES TARGETED SPECIAL AMDAR DATA Added about 18% to total 24hr global forecast error reduction from radiosonde profiles at 06UTC and 18UTC 29, 898 observations Added about 2% to total 24hr global forecast error reduction from global aircraft observations 24,423 observations

41. CONCORDIASI Field Program Sep-Dec 2009 41

42. CONCORDIASI Field Program Sep-Dec 2009 42 Largest sensitivity to targeted observations on the periphery of Antarctica Targeted dropsondes Ob Impact results for Concordiasi October 2010 (124 analyses and forecasts) equivalent to addition of three full-time raob stations NOGAPS-NAVDAS_AR (4d-Var) operational forecast system Observation Impact on 24hr forecast error norm (total moist energy) For observations in geographic domain south of 60 S Observation Type Radiosondes Dropsondes GeoSat Wind MODIS Wind AVHRR Wind LEO GEO Wind AIREP AMDAR LAND SFC SHIP SFC SSMI SFC WIND SCAT SFC WIND ASCAT SFC WIND WINDSAT SFC WIND SSMI TPW WINDSAT TPW GPS-RO AMSU-A IASI SSMIS AQUA Total Compiled by Rolf H. Langland NRL-Monterey Summed Impact J kg-1 -2.8260 -1.0658 -0.0474 -10.4172 -2.6195 - -0.0001 -0.0793 -2.0729 -0.2345 +0.0327 +0.0082 -0.1490 -0.0403 -0.0112 -0.0012 -2.1002 -8.3132 -3.8546 -3.4714 -0.5572 -37.8201 Impact per-ob x10-5 J kg-1 -3.2050 -2.8050 -0.7895 -1.3243 -0.6724 - -0.0342 -11.1690 -1.9161 -4.6704 +0.1189 +0.6193 -1.5351 -1.0172 Profiles Profiles -0.1394 -0.2088 -0.0650 -0.0909 -0.4474 -0.2329 Number Obs 88,175 37,996 6,004 786,618 389,562 - 292 710 108,185 5,021 27,493 1,324 9,706 3,962 11,902 633 1,507,041 3,981,468 5,932,979 3,820,906 124,553 16,844,530

43. Successes of Targeted Observing 43 The theory of targeted observing to improve short- and medium-range forecasts has been validated Targeted observing has the potential for significant improvement to deterministic and ensemble forecasts of high- impact weather Several targeting programs are in routine operations: [NOAA: WSRP, N.Atlantic Hurricanes, Taiwan:DOTSTAR] The targeted use of rapid-scan AMVs is now a routine part of operations at JMA and NESDIS (for land-falling tropical cyclones)

44. Limitations and Challenges for Targeting 44 Dropsonde targeting provides only partial surveys of target areas, relatively small amounts of data, and is thus not able to achieve the full potential of targeted observing Addition of rapid-scan winds provides more-complete surveys of target areas, and larger forecast error reductions, but cannot be used in all situations because of logistical limitations In-situ data (radiosondes, dropsondes, aircraft) appears necessary to supplement current satellite data, especially in cloudy areas, where targeted data are most needed

45. Research Questions for Targeted Observing 45 How much benefit can we obtain by tuning the network of existing regular satellite and in-situ observations in a targeted sense? - Targeted satellite data thinning - Targeted satellite channel selection - On-request feature-track wind data for anticipated high-impact weather events - Increase observations from commercial aircraft in certain regions - Request radiosondes at non-standard times

46. WMO Targeting Recommendations 46 Focus on critical deficiencies that exist in the current global observing network note that large-scale differences in analysis uncertainty has not been eliminated by huge amounts of radiance data Aircraft data should be maintained or expanded in regions where current in-situ observations are sparse [e.g., oceans, South America, Africa] Current radiosonde stations should be maintained with increases in off-time [06Z, 18Z] soundings in remote locations and regions with sparse aircraft data Where possible, rapid-scan and other satellite resources should be used in targeted mode to improve forecasts of high-impact weather events in regions with large analysis uncertainty

47. For additional information: Dr. Rolf H. Langland Data Assimilation Section Naval Research Laboratory Monterey, CA 93940 Rolf.langland@nrlmry.navy.mil 47
