A Detailed Look into X-Ray Machine Components
undefined
Control panel
Extension arm
Tube head
On/off switch
Exposure button
Digital timer indicator
Time set switch
Warning lights and audible signals to indicate
when X-rays are being generated
Connects control panel to tube head
Houses electric wires
Metal housing
External body, tightly sealed and filled with oil.
Internally it contains x-ray tube, transformer,
filter collimator.
Position Indicating Device:
Connected to tube head
Lead, plastic
8” or 16”
Rectangular /round
Shapes the X-ray beam and prevent
overdivergence of beam
Surrounds the X-ray tube and transformer.
Act as
insulator
; prevent overheating of X-ray
machine by absorbing heat generated during
production of X-rays.
Leaded Glass Housing – evacuated to high
vacuum
Cathode – contains filament and focusing cup
Anode – contains tungsten target.
Borosilicate glass along with lead
central area is unleaded – window for the exit
of X-ray beam
Function: prevent radiation leakage
Tungsten filament
Emission of electron by thermionic emission
When filament is heated to incandescence, it
generates electron.
Focusing cup
Molybdenum,
Nickel
Focuses the
electron toward the
anode by
electrostatic forces.
High melting point – 3370
0
C
High atomic number (74)
High thermal conductivity
Less tendency to vaporize
Long life
Prevents the spread out of the electron
Tungsten target embedded in the copper
stem.
Fn – generate X-ray and dissipation of heat
Insulating oil
Copper stem of anode
Rotating anode
Removes low energy X rays.
Penetrate only superficial tissues
Causes unwanted absorption of rays
Inherent
Added
Total
Control size and shape of the X-ray
beam.
Lead
Size – improve image quality by
reducing the scatter radiation
Diaphragm/ round
Tubular
Rectangular
silt
