1. 3-D Scene Analysis via Sequenced Predictions over Points and Regions Xuehan Xiong Daniel Munoz Drew Bagnell Martial Hebert 1

2. Problem: 3D Scene Understanding 2

3. Solution: Contextual Classification Building Wire Pole Veg Trunk Car Ground 3

4. Classical Approach: Graphical Models Graphical models Intractable inference Belief propagation Mean field MCMC Difficult to train Kulesza NIPS 2007 Wainwright JMLR 2006 Finley & Joachims ICML 2008 Limited success Anguelov, et al. CVPR 2005 Triebel, et. al. IJCAI 2007 Munoz, et al. CVPR 2009 4 Fig. from Anguelov, et al. CVPR 2005

5. Classical Approach: Graphical Models Graphical models Intractable inference Belief propagation Mean field MCMC Difficult to train Kulesza NIPS 2007 Wainwright JMLR 2006 Finley & Joachims ICML 2008 Limited success Anguelov, et al. CVPR 2005 Triebel, et. al. IJCAI 2007 Munoz, et al. CVPR 2009 5 Fig. from Anguelov, et al. CVPR 2005

6. Classical Approach: Graphical Models Graphical models Intractable inference Belief propagation Mean field MCMC Difficult to train Kulesza Wainwright Finley & Joachims ICML 2008 Limited success Anguelov, et al. CVPR 2005 Triebel, et. al. IJCAI 2007 Munoz, et al. CVPR 2009 6 Fig. from Anguelov, et al. CVPR 2005

7. 7

8. 8

9. 9

10. 10

11. Our Approach: Inference Machines Train an inference procedure, not a model. To encode spatial layout and long range relations Daume III 2006, Tu 2008, Bagnell 2010, Munoz 2010 11

12. Our Approach: Inference Machines Train an inference procedure, not a model. To encode spatial layout and long range relations Daume III 2006, Tu 2008, Bagnell 2010, Munoz 2010 Inference via sequential prediction T T C0 C1 C2 F F F Reject E.g. Viola-Jones 2001 12

13. Our Approach: Inference Machines Train an inference procedure, not a model. To encode spatial layout and long range relations Daume III 2006, Tu 2008, Bagnell 2010, Munoz 2010 Inference via sequential prediction context context C0 C1 C2 Ours 13

14. Example features (0): xi point features = ) 0 ( ) 0 ( ) 0 ( LogReg ( ) Y X 14

15. (0): xi point features argmax( Y(0)) 15

16. top mid bottom (0): (1): xi xi point features Contextual features 16

17. top mid bottom (1): xi point features = ) 1 ( ) 1 ( ) 1 ( LogReg ( ) Y X 17

18. top mid bottom (1): xi point features = ) 1 ( ) 1 ( ) 1 ( LogReg ( ) Y X argmax( Y(1)) 18

19. top mid bottom (1): xi point features = ) 1 ( ) 1 ( ) 1 ( LogReg ( ) Y X 19

20. top mid bottom (2): xi point features = ) 2 ( ) 2 ( ) 2 ( LogReg ( ) Y X 20

21. Local features only Wire Building Veg Pole Car Ground 21

22. Round 1 22

23. Round 2 23

24. Round 3 Veg Car 24

25. Create regions Level 2 Level 1 25

26. 26

27. (2): (0): (1): xj xj xj region features Pt level Region level 27

28. Level 2 Level 1 28

29. (2): (3): xi xi point features Region level Point level 29

30. With Regions 30

31. Learned Relationships top mid bottom xi: point features Neighbor contextual feature Learned weights 31

32. Learned Relationships top mid bottom xi: point features Neighbor contextual feature Learned weights 32

33. Experiments 3 large-scale datasets CMU (26M), Moscow State (10M), Univ. Wash (10M) Multiple classes (4 to 8) car, building, veg, wire, fence, people, trunk, pole, ground, street sign Different sensors SICK (ground), ALTM 2050 (aerial), Velodyne (ground) Comparisons Graphical models, exemplar based 33

34. Quantitative Results 0.9 0.8 Average F1 Score 0.7 0.6 0.5 0.4 0.3 CMU [1] Moscow A [2] Moscow B [2] UWash [3] Ours Related Work [2] Shapovalov PCV 2010 LogReg [1] Munoz CVPR 2009 [3] Lai RSS 2010 * 34 * Use additional semi-supervised data not leveraged by other methods.

35. [1] Munoz, et. al. CVPR 2009 CMU Dataset Ours Max Margin CRF [1] 35

36. [1] Munoz, et. al. CVPR 2009 CMU Dataset Ours Max Margin CRF [1] 36

37. [1] Munoz, et. al. CVPR 2009 CMU Dataset Ours Max Margin CRF [1] 37

38. Moscow State Dataset Ours Logistic regression 38

39. Conclusion Simple and fast approach for scene labeling No graphical model Labeling via 5x logistic regression predictions context context C0 C1 C2 Support flexible contextual features Learning rich relationships 39

40. Thank you! And Questions? Acknowledgements US Army Research Laboratory, Collaborative Technology Alliance QinetiQ North America Robotics Fellowship 40
