Training for the 2013 Construction and Material Specifications Office of Construction Administration Gary Angles, Administrator
Introduction, Overview and Implementation Schedule Focus of this training will be to: Introduce the 2013 C&MS Describe the significant changes with a focus on the changes that may require design consideration
Introduction, Overview and Implementation Schedule o The 2013 C&MS was published 12/31/2012 o Associated documents published 12/31/2012: Proposal Notes Supplemental Specifications Supplements o Associated documents published 1/18/2013: Standard Construction Drawings L&D Manual updates
Introduction, Overview and Implementation Schedule The most significant changes were made in: Items 603, 604 were replaced by Item 611 (To be covered by Becky, and Gary) with QC-1, QC-2, QC-Misc (To be covered by Craig, and Jim) For all Concrete items, replace Class C, S, F
Introduction, Overview and Implementation Schedule Currently all documents, including the Item Master are available on the internet Conversion guidelines: www.dot.state.oh.us/Divisions/Engineering/CaddMapping/cms_conversion/Pages/2013_CMS_Conversion_Page.aspx Item Master: www.dot.state.oh.us/Divisions/ContractAdmin/Contracts/Construction/Forms/ItemMaster.aspx C&MS, PN, SS, S: www.dot.state.oh.us/Divisions/ConstructionMgt/OnlineDocs/Pages/ProposalNotesSupplementalSpecificationsandSupplements.aspx Please note that all projects with an award date of 12/23/2013 (sale date of 12/12/2013) or after must be converted to the 2013 C&MS with no exceptions. The first SS800 for the 2013 C&MS will be dated 4/19/2013 The last SS800 for the 2010 C&MS will be dated 7/19/2013
Introduction, Overview and Implementation Schedule 9:00 am 0.25 hr 2013 C&MS Introduction, Overview, and Implementation Gary Angles, P.E. Todays Agenda: 9:15 am 0.75 hr Clint Bishop, P.E. Administration Issues, CPM Schedules, and Partnering 10:00 am 0.5 hr Stephen Slomski, P.E. Earthwork and MSE changes 10:30 am Break 10:45 am 0.75 hr Craig Landefeld, P.E. Pavements and QC/QA Concrete changes 11:30 am on your own Lunch 12:30 pm 0.5 hr Structures changes Jim Welter, P.E. 1:00 pm 0.25 hr Gary Angles, P.E. Environmental changes 1:15 am 0.5 hr Becky Humphreys, P.E. Hydraulics and the New Item 611 1:45 pm Break 2:00 pm 0.50 hr Dan Groh, P.E. Traffic, Signing, and Pavement Marking changes 2:30pm 0.50 hr Gary Angles, P.E. Review, Summary and Questions 3:00 pm 4.5 hr total End of Training
Questions Gary Angles, Administrator Office of Construction Administration Gary.Angles@dot.state.oh.us www.dot.state.oh.us/Divisions/ConstructionMgt/Pages/default.aspx 614-466-7075
