1. Zero-Emission Powertrain Certification (ZEP Cert) 3rd Public Workshop El Monte, CA March 20, 2018 Meeting materials available at: https://ww2.arb.ca.gov/our-work/programs/zero-emission-powertrain-certification

2. 8/1/2024 8/1/2024 Agenda California s Climate/Air Quality Challenges, and Policy Objectives ZEP Cert Framework Applicability Powertrain / Vehicle Certification Tiered Approach Battery Module Testing Certification Families System Monitoring and Reporting Requirements Warranty and Repairability Next Steps 1

3. 8/1/2024 8/1/2024 Written Questions and Comments Please send written questions & comments to: matthew.diener@arb.ca.gov 2

4. Californias Climate & Air Quality Challenges and Policy Objectives 8/1/2024 8/1/2024 California needs significant additional NOx and GHG reductions beyond what can be achieved by existing technologies Broad deployment of zero- and near zero-emission technologies needed ZEP Cert is intended to help accelerate the transition to zero-emission technologies Support other CARB regulations Empower fleet decision making Support effective funding program implementation 3

5. 8/1/2024 8/1/2024 Zero-Emission Powertrain Certification Conceptual ZEP Cert Framework Conceptual ZEP Cert Framework 4

6. 8/1/2024 8/1/2024 Applicability On-Road: MY2023+ battery-electric and fuel-cell electric vehicles Not certified under the existing light Not certified under the existing light- -duty ZEV program program Heavy-Duty Vehicles >14,000 lbs GVWR Medium-Duty Vehicles 8,501 lbs 14,000 lbs GVWR Starting January 1, 2023, battery-electric and fuel-cell electric vehicle conversions Optional process for zero-emission off-road powertrains duty ZEV 5

7. Powertrain & Vehicle-Based Certification Updates Since 2nd Workshop Framework now includes both Certification provisions Single set of requirements for all powertrain families Testing at the module level for usable battery capacity Two level certification requirement for vehicles based on sales volume Each vehicle certification would point to powertrain certifications Revisions to monitoring, diagnostics, service/repair, warranty, reporting, and recall proposals. 8/1/2024 8/1/2024 both Powertrain and Vehicle 6

8. 8/1/2024 8/1/2024 Written Questions and Comments Please send written questions & comments to: matthew.diener@arb.ca.gov 7

9. 8/1/2024 8/1/2024 ZE Powertrain Elements Zero-Emission Powertrain Definition: Any system of components capable of providing vehicle tractive effort for a given application without producing emissions. Energy Storage System Fuel-Cell System Power Electronics Electric Drive Components 8

10. ZE Powertrain Certification Applicability On- and Off-Road 8/1/2024 8/1/2024 ZE On-Road (New) Vehicle GHG Certification Powertrain Certification ZE Aftermarket Parts Conversion Approval Powertrain Certification ZE Off-Road (Optional) Powertrain Certification 9

11. 8/1/2024 8/1/2024 Certification Families (Draft Proposal) All powertrains in a test group shall contain same battery characteristics (e.g., chemistry, packaging, cooling strategies, etc.) Battery scaling (e.g., additional modules to increase total pack capacity) would be allowed in same test group 10

12. 8/1/2024 8/1/2024 Certification Testing (Draft Proposal) Battery Capacity Test: SAE J1798 (module-level testing acceptable) Testing within pack design parameters Results from module testing scalable to different pack configurations Usable capacity (max capacity in SAE J1798) and available capacity (manufacturer-limited capacity) 11

13. System Monitoring and Diagnostics (Draft Proposal) 8/1/2024 8/1/2024 Structure similar to Engine Manufacturer Diagnostics (EMD) Must monitor: Energy Storage System Including State of Health (OEM defined) Power Electronics Motor/Generator Regenerative Braking System Charger Must identify fault modes and store faults 12

14. 8/1/2024 8/1/2024 Certification Families (Draft Proposal): Shall be grouped by the vehicle weight classes 4 groups: Class 2b/3, 4/5, 6/7, 8 Certification levels would move from Level 1 to Level 2 once 250 vehicles within the weight class have been sold 13

15. 8/1/2024 8/1/2024 In-Use Testing (Draft Proposal) Level 1 None required Level 2 Report in-use capacity test at year 3 and year 6 Use SAE J1798 or manufacturer devised procedure to determine on-board energy capacity (e.g., using the charger to measure kWh accepted by battery) 14

16. 8/1/2024 8/1/2024 Warranty (Draft Proposal) Level 1 Defects/workmanship for minimum of 3 years/50,000 miles Level 2 Defects/workmanship for minimum of 3 years/50,000 miles Manufacturer shall specify warranted percentage of usable capacity 15

17. Warranty Reporting and Recall (Draft Proposal) 8/1/2024 8/1/2024 Level 1 and 2 Warranty reporting if warranty rate exceeds the greater of 1% of CA sales or 10 valid claims within a weight class group Executive Officer may require recall if warranty rate exceeds the greater of 4% of CA sales or 25 valid claims for the same component failure Manufacturer required to reimburse for towing costs for distances over 50 miles as measured by the distance between the vehicle s base of operation and the nearest authorized repair facility if repair is found to be covered during the warranty period 16

18. 8/1/2024 8/1/2024 System Monitoring and Diagnostics (Draft Proposal) Level 1 and 2 Any modifications to powertrain certification monitoring and diagnostics shall be reported Required Connector: Must meet the requirements in Title 13 CCR 1971.1(h)(2) or provide an adapter designed to communicate with an SAE J1939 network Required Scan Tool Communications: Must meet the controller area network requirements in Title 13 CCR 1971.1(h)(3) 17

19. 8/1/2024 8/1/2024 Service and Repair (Draft Proposal) Level 1 and 2 Must have a service/dealer level technical repair manual for the powertrain Must provide copy to CARB at time of certification Must provide updates and technical service bulletins Must provide dealer level diagnostic software to CARB Make available to third party repair facilities (manufacturer may require technical and/or safety training prerequisites) 18

20. 8/1/2024 8/1/2024 Disclosure Statement (Draft Proposal) Level 1 and 2 Disclosure statement to purchaser about considerations when buying a vehicle with a zero- emission powertrain Example Considerations: Gradeability needs, acceleration requirements, max speed, range on work cycle, impacts on range from HVAC usage, and charging/fueling infrastructure. 19

21. Off-Road Equipment 8/1/2024 8/1/2024 Optional process Supports funding program requirements to have CARB verified/certified system Certification at the powertrain level 20

22. 8/1/2024 8/1/2024 Zero-Emission Powertrain Certification Next Steps Next Steps 21

23. 8/1/2024 8/1/2024 Next Steps Ongoing stakeholder engagement Proposed regulation released for 45-Day public comments May 2018 May 2018 Board consideration July 2018 July 2018 22

24. ZEP Cert Rulemaking Contacts 8/1/2024 8/1/2024 Matthew Diener, Lead Staff Phone: 626-575-6684 Email: matthew.diener@arb.ca.gov David Eiges, Staff Phone: 626-575-6602 Email: david.eiges@arb.ca.gov David Chen, Manager, Advanced Emission Control Strategies Section Phone: 626-350-6579 Email: david.chen@arb.ca.gov https://ww2.arb.ca.gov/our-work/programs/zero-emission- powertrain-certification 23
