Wastewater Treatment Process Through Images
Swage treatment plant
Screen and Racks
•
Screening device are used to remove coarse
solids from wastewater. Coarse solids consist
of sticks, rags, boards and other large objects
that often find their way into sewer system.
Grit chamber
•
Suspended solids such as sand, metal
fragment, …….etc. should be removed because
of their bad effect on biological treatment and
mechanical equipment.
Aerated grit chamber
•
It controls the separation of organic and
inorganic solids by producing a spiral flow.
•
The velocity of the bulk solution is kept above
the settling velocity of the organic particles
but below that of the inorganics.
Screening devices and grit chambers play crucial roles in sewage treatment plants to remove coarse solids and suspended solids like sand and metal fragments. The aerated grit chamber helps separate organic and inorganic solids efficiently, ensuring the effectiveness of biological treatment and mechanical equipment.
Download Presentation
Please find below an Image/Link to download the presentation.
The content on the website is provided AS IS for your information and personal use only. It may not be sold, licensed, or shared on other websites without obtaining consent from the author. Download presentation by click this link. If you encounter any issues during the download, it is possible that the publisher has removed the file from their server.
E N D
Presentation Transcript
Screening device are used to remove coarse solids from wastewater. Coarse solids consist of sticks, rags, boards and other large objects that often find their way into sewer system.
Grit chamber Suspended solids such as sand, metal fragment, .etc. should be removed because of their bad effect on biological treatment and mechanical equipment.
Aerated grit chamber It controls the separation of organic and inorganic solids by producing a spiral flow. The velocity of the bulk solution is kept above the settling velocity of the organic particles but below that of the inorganics.
