1. Using and Adapting ROOT for High-frequency Financial Market Data ROOT Users Workshop 2022-05-09, Philippe Debie, on behalf of Project HighLO Debie, P., Naumann, A., Verhulst, M.E., Pennings, J.M.E., Rembser, J., Demirel, S., & Moneta, L.

2. Project HighLO High Energy Physics Tools in Limit Order Book Analysis Collaboration between 1. Wageningen University & Research (WUR) 2. CERN 3. Commodity Risk Management Expertise Centre (CORMEC) Research goal 1. Describe and detect manipulation of financial markets 2. Help regulators and lawmakers 2

3. Background info Financial data 300TB of messages For each order, for each transaction, etc. Nanosecond timestamp Irregularly spaced in time Commodity futures from the Chicago Mercantile Exchange (CME) 3

4. Why ROOT Finance research Data is noisy, irregular in shape, and large in size Current storage tools are basic (e.g., csv files) The power of ROOT TFile and TTree are perfect for market data Transform timeseries into events Apply HEP statistical methods 4

5. Overview 1. A library using ROOT Actively using for research 2. Extending RDataFrame with time series operations Prototype build 5

6. Data iteration using a TimeFrame TimeFrame A simple single threaded version of RDataFrame for time series analysis Create a TimeFrame object TimeFrame timeFrame; timeFrame.add(chainSoybean); timeFrame.add(chainCorn); 6 https://github.com/HighLO/TimeFrame

7. Data iteration using a TimeFrame Keep track of the internal state timeFrame.setStateInitializer([&](int id) { return LimitOrderBook(metaData.at(id).Name, id); }); timeFrame.setStateUpdater([](int id, TimeNS time, LimitOrderBook& lob, const Message& message) { lob.update(time, message); }); 7 https://github.com/HighLO/TimeFrame

8. Data iteration using a TimeFrame Simple iteration timeFrame.setForEachRow([&](int id, TimeNS time, const Message& message, const LimitOrderBook& lob) { std::cout << lob.getName() << " has " << lob.getTradeVolume() << " transactions so far\n"; }); Making snapshots timeFrame.setForEachSnapshot(T_Second * 10, [](TimeNS time, const map<int, LimitOrderBook>& lobs) { std::cout << lobs.size() << " internal states tracked at " << nsToTimestamp(time) << '\n'; }); 8 https://github.com/HighLO/TimeFrame

9. Data iteration using a TimeFrame Start iteration timeFrame.run(); What happens? 1. Synchronize the 2 chains (soybean and corn data) 2. Build the state for each message 3. Resample the time series 4. Call the lambda functions 9 https://github.com/HighLO/TimeFrame

10. Extending RDataFrame RDataframe operations Define using lead and lag Persistent data objects Resample a time series Trigger-filter-action system (differentiation) (integration and more) Proof of concept: https://github.com/philippe554/root 10

11. Lead and Lag ROOT::RDataFrame rdf(50); auto r = rdf .DefineSlotEntry("foo", [](unsigned int slot, ULong64_t entry){return static_cast<int>(entry);}) .Define("bar", [](int foo){return foo * foo;}, {"foo"}) .MovingCache<int, int>({"foo", "bar"}) .Define("D", [](int bar1, int bar2){return bar2 - bar1;}, {"bar", "bar"}, {-1, 0}) .Display({"foo", "bar", "D"}); r->Print(); +-----+-----+-----+---+ | Row | foo | bar | D | +-----+-----+-----+---+ | 1 | 1 +-----+-----+-----+---+ | 2 | 2 +-----+-----+-----+---+ | 3 | 3 +-----+-----+-----+---+ | 4 | 4 +-----+-----+-----+---+ Note that it skipped the first entry | 1 | 1 | | 4 | 3 | | 9 | 5 | | 16 | 7 | 11 https://github.com/philippe554/root

12. Persistent Define and Resampling ROOT::RDataFrame rdf(50); auto r = rdf .DefineSlotEntry("foo", [](unsigned int slot, ULong64_t entry){return static_cast<int>(entry);}) .Define("D", [](){return gRandom->Exp(1);}) .DefinePersistent("time", []( double& time, double D){time += D;}, {"D"}) .Resample<double, double, int>("time", 1, 5, 15, {"time", "foo"}) .Display({"time", "foo"}, 10); r->Print(); 12 https://github.com/philippe554/root

13. Resample a time series +-----+-----------+-----+ | Row | time +-----+-----------+-----+ | 0 | 5.0000000 | 5 +-----+-----------+-----+ | 1 | 6.0000000 | 6 +-----+-----------+-----+ | 2 | 7.0000000 | 7 +-----+-----------+-----+ | 3 | 8.0000000 | 8 +-----+-----------+-----+ | 4 | 9.0000000 | 8 +-----+-----------+-----+ | 5 | 10.000000 | 9 +-----+-----------+-----+ | 6 | 11.000000 | 9 +-----+-----------+-----+ | 7 | 12.000000 | 9 +-----+-----------+-----+ | 8 | 13.000000 | 10 +-----+-----------+-----+ | 9 | 14.000000 | 11 +-----+-----------+-----+ | foo | | | | | | | | | | | 13 https://github.com/philippe554/root

14. Trigger-filter-action system 14

15. Trigger-filter-action system auto r = rdf .DefinePersistent("market", [](Market& market, Message message){ market.update(message); }, {"message"}) .Collect(-2, 2, [](Message message){return message.isTransaction();}, {"message"}) .Define("price", [](Market& market){ market.getPrice();}, {"market"}) .Histo2D<float, float>({"impactPlot", "Impact plot", 5u, -2.5, 2.5, 32u, -4.0, 4.0}, "timeOffset", "price"); 15

16. Summary Using ROOT in Finance 1. ROOT can store and process complex time series data 2. Introduce HEP tools into Finance RDataFrame extension 1. Implementation possible with minimal changes to existing code 2. Reducing the learning curve of working with high-frequency data 16

17. References Verhulst, Marjolein E., Philippe Debie, Stephan Hageboeck, Joost ME Pennings, Cornelis Gardebroek, Axel Naumann, Paul van Leeuwen, Andres A. Trujillo Barrera, and Lorenzo Moneta. "When two worlds collide: Using particle physics tools to visualize the limit order book." Journal of Futures Markets 41, no. 11 (2021): 1715-1734. Debie, P., Gardebroek, C., Hageboeck, S., van Leeuwen, P., Moneta, L., Naumann, A., ... & Verhulst, M. E. Unravelling the JPMorgan Spoofing Case Using Particle Physics Visualization Methods. European Financial Management. https://github.com/HighLO/TimeFrame https://github.com/philippe554/root 17
