UPDATE A PRODUCT
INSTANCE
Jeff Zemsky
12/21/2015
START WITH EXISTING PRODUCT INSTANCE
We will revise the
Gearbox and switch
the Primary Gear from
serial PG02 to PG03
FIRST – REVISE THE INSTANCE
DEALLOCATE THE PRIMARY GEAR
ALLOCATE A NEW OR EXISTING SERIAL NUMBER FOR PRIMARY GEAR
In this case
we will select
PG03 serial
number
INSTANCE 001 REVISION B IS UPDATED, REVISION A IS UNCHANGE
REVIEW SIDE BY SITE WITH COMPARE
This process involves updating a product instance by revising the gearbox and switching the primary gear from serial PG02 to PG03. Steps include revising the instance, deallocating the primary gear, allocating a new or existing serial number for the primary gear, updating Instance 001 Revision B, and reviewing the changes alongside the original product instance for comparison.
