Transformers in Electrical Engineering
TRANSFORMER
GT ECE ACADEMIC LAB
SLIDES BY ZACHARY CHAN
OVERVIEW
•
An AC generator creates current
through a primary coil of wire
wrapped around an iron core and a
secondary coil is wrapped around the
same iron core
•
The alternating current in the first coil
generates a magnetic field with
changing direction and magnitude
which induces an alternating current in
the secondary coil
STEP UP VS STEP DOWN
•
Step up transformers increase the voltage
•
More coil windings on the primary coil (wire from the generator) and less coil windings on
the secondary coil (wire going to the load)
•
Step down transformers decrease the voltage
•
Less coil windings on the primary coil (wire from the generator) and more coil windings on
the secondary coil (wire going to the load)
•
N1/N2 = V1/V2
•
1 denotes the primary coil and 2 denotes the secondary coil
•
N is the number of coil windings and V is the Voltage
EFFICIENCY
•
Some energy is lost in the iron core as the magnetic molecules in the iron heat
up and cause power loss
•
The core is not completely solid
•
It is made up of multiple sheets attached together to improve efficiency
•
Some energy is lost in the copper proportional to I^2R
•
Represent the greatest loss of a transformer
•
Current heats up the copper wire and some energy is lost
APPLICATION
•
Powerstations use transformers to step up the voltage of alternating current to
distribute it because AC is easier to step up and step down voltage than DC
•
After being stepped up for transmission and distribution, the voltage is
stepped down to be safely used in homes
•
Stepping down the voltage decreases the current and therefore makes
transmission more efficient
THREE PHASE POWER
•
Transformers can be combined to
make 3 phase transformers which
reduced costs and size
•
The primary and secondary coils
are connected in various
configuration combinations, each
with their own advantages
•
Common configurations are star-star,
delta-delta, delta-star and star-delta
