1. Chapter 24: Section 3 Notes The Outer Planets

2. Outer Planets Jupiter, Saturn, Uranus, Neptune Pluto is no longer considered a planet. 4 planets are gaseous giants (Jovian Planets) Voyager 1 & 2 probed the 4 gaseous giants Jupiter, Saturn, Uranus, Neptune

3. Jupiter jupiter.jpg

4. Jupiter Largest Planet in our Solar System Fifth planet in order Has 4 sets of rings = 2 outer rings =gossamer rings Revolution = 11.9 years to orbit Rotation = 10 hrs (fastest of all planets)

5. Jupiters Composition Made of Hydrogen, Helium, Ammonia, Methane, & water vapor Gaseous Atmosphere, Liquid Mantle, & Solid Core Clouds form color bands (strong jet streams) Winds up to 400 km/hr. Has Great Red Spot: Continuous Atmospheric Storm Lightning has been observed in the atmosphere Radiates 2x as much heat as it receives Believed to be a star that just didn t make it

6. Jupiters Moons Jupiter has at least 79 moons Four Largest = Galilean Moons (Discovered in 1610) Named: Io, Europa, Ganymede, Callisto Io: Closest of the Large moons to Jupiter Most volcanic objects in out Solar System Sulfuric Lava produces Reddish/Orange color Holds a thin sulfur dioxide atmosphere Europa: Composed of solid rock covered with ice Tectonic activity frozen crust layer Thin oxygen atmosphere

7. Jupiters Moons continued Ganymede: Largest moon in the Solar System has own magnetic field Larger than Mercury, Surface covered in Ice Slushy Mantle, Solid rock core Callisto: Composed of heavily cratered Rock/Ice Crust Water/Ice mantle with a rocky core

8. Galilean Moons Europa Io with eruption Callisto Ganymede

9. Saturn images.jpeg

10. Saturn Sixth planet from the sun revolution: 30 year orbit rotation: 11 hr is the Ringed Planet Second Largest planet Very low density (would float in water) Atmospheric composition: Mostly hydrogen & helium; also ammonia, methane Liquid Hydrogen/helium mantle & small rocky core

11. Saturn Continued 7 Rings composed of 1000 s of ringlets Ringlets are made up of ice & rock particles Many/Several moons orbit Saturn (82 total) Largest moon = Titan (2nd largest in Solar System) Real atmosphere of nitrogen, argon, & methane Thick, smog clouds cover Titan Surface temp. = -180 0C (-292 oF)

12. saturn_false.jpg (62611 bytes) saturn_rings_false.jpg (129826 bytes)

13. Uranus default-uranus.jpg

14. Uranus Smallest of the gas planets Only one named after a Greek God Discovered in 1781 7th planet from the sun revolution: 84 year orbit rotation: 17 hour rotation Average Temp. = -3280F -350oF

15. Uranus continued Has 27 moons 5 largest are almost identical Main Moon is Titania Dark color, lack atmosphere, crater riddled Has several dark rings Detected a magnetic field tilted 600 from axis Atmosphere: Hydrogen, Helium & Methane Methane gives planet a blue/green tint Liquid mantle of water, methane, & ammonia Rocky core ** Rotational axis lays on its side (Spins like a tire)

16. Neptune Unknown.jpeg

17. Neptune Last of the gas planets; discovered in 1846 Orbit overlaps Pluto s at 2 points Change position 8 9 & 9 8 1 orbit = 165 years; 1 rotation = 16 hrs Atmosphere: Hydrogen, Helium, Methane dark, cold, and super sonic winds Methane gives Neptune bluish tint (has unknown components) Winds = 2200 km/hr; Temperature = -417 0F Has a dark spot = storm in it s atmosphere Liquid mantle: water, methane, & ammonia Core: solid rock

18. Neptune continued Now has 14 moons (14this an unofficial moon) Largest moon = Triton Has a thin nitrogen atmosphere cold and orbits the opposite way of the other moons Constantly erupting methane geysers also detected The Great Dark Spot oval-shaped dark storm Neptune also has 6 rings (thin & thicken at different places)
