COLLABORATIVE
TCP SEQUENCE NUMBER
INFERENCE ATTACK
BY
ZHIYUN QIAN, Z.MORLEY,
MAOYINGLIAN XIE
PRESENTED BY:
YUGENDHAR REDDY SARABUDLA
TODAY’S AGENDA
Introduction
Background description
TCP Sequence Number Inference Attack
Design and Implementation of TCP Attack
Impact Analysis of an Attack from case studies
Conclusion
TCP INTRODUCTION
•
TCP
- M
ost commonly used protocol over the
internet
•
Built on top of Internet Protocol. Hence TCP/IP.
•
T
ransmits bits of data in terms of IP packets
•
C
onnection-oriented.
•
H
ighly reliable for transmission of data.
•
Receiver sends acknowledgement for the packets
received, based on that re-transmission is done
for failed packets
UNDERSTANDING TCP FIELDS
THE THREE-WAY HANDSHAKE
•
TCP utilizes many 1-bit boolean flags to maintain the state of the connection.
•
The three fields that we are interested in are
1.
SYN : initiates a connection
2.
ACK : used to acknowledge received data
3.
FIN : terminates a connection
SEQUENCE AND ACKNOWLEDGEMENT
NUMBERS
•
Sequence and Acknowledgement are two more fields of TCP header,
used to track a connection’s packet
•
These are different from “SYN flag” and “ACK flag”
•
Both client and server of a TCP session maintains a 32-bit sequence
number
•
Sequence number is included in every packet that is sent and it is used
to track the amount of data that has been sent
•
When the opposite host receives a packet it send the sequence number
as acknowledgement number to the sender, conforming that it received
the packet.
THE THREE-WAY HANDSHAKE
So TCP 3 way handshake is all about
SYN—>SYN-ACK—>ACK.
This 3 way handshake is one of the
reason which makes TCP a reliable
protocol.
SEQUENCE AND ACKNOWLEDGEMENT
NUMBERS OBESERVANCE
BACKGROUND DESCRIPTION
•
TCP-
Not o
riginally designed for security, for years it has been patched
to address various security holes
•
Randomization of TCP’s initial sequence number (ISN), introduced in
RFC 1948 was an important one.
•
P
roposed to guard against off-path spoofing attacks attempting to
inject packets with forged source addresses
•
P
revents easy prediction of ISN, by which arbitrarily inserted messages
are likely to be discarded at the receiver due to invalid sequence
numbers
BACKGROUND DESCRIPTION
•
A function has been defined to obtain a unique random number using a 4 micro
second timer M, which decreases the probability of guessing sequence number
•
Below is the equation to generate ISN
ISN = M + F(localhost, localport, remotehost, remoteport)
F is the hash function
TCP SEQUENCE NUMBER INFERENCE
ATTACK
•
Threat Model
•
Packet Counter Side Channels
•
TCP Incoming Packet Validation
•
Sequence Number Dependent Counter in Linux
•
Sequence Number Dependent Counter in Windows
•
Sequence Number Dependent Counter in Mac/BSD
THREAT MODEL
In Threat model, there are four main entities
1.
The victim smartphone and a target application
2.
The legitimate server which communicates with victim smartphone
using an unencrypted application layer (HTTP)
3.
The on-device malware, which doesn’t have privileges and cannot
tamper other apps directly
4.
The off-path attacker, capable of spoofing the legitimate server IP
address
THREAT MODEL- WORK FLOW
A
ttacker sends a probing packet to target and the malware
residing in the target checks whether attacker has sent the
correct sequence number or not and replies with a feedback
THREAT MODEL
•
The off-path attacker needs the two piece of information
1.
Four tuples of target connection i.e., source/destination IP address and
source/destination port numbers
2.
Correct sequence number
•
The on-device malware will be able to identify the current active tcp
connection but not the sequence number that is in use
PACKET COUNTER SIDE CHANNELS
P
rovides indirect feedback on sequence number.
Some of the processes could be used to attain this.
1.
‘netstat –s’
=> E
xtracts information
2.
The IPID side channel
=>
A special form of packet counter to record outgoing
packets.
TCP INCOMING PACKET VALIDATION
Five checks from referred source code in Linux
1.
Error check : MD5, Timestamp, Packet Length, Checksum
2.
Sequen
ce Number check : seq_end >= X, seq <= X +rcv_win
3.
Ack Number check
: Valid ACK -> [Y, Y+remaining_bytes]
4.
0-payload check : If payload = 0, drop
5.
Retransmission check
: If seq_end <= X, drop
TCP INCOMING PACKET VALIDATION
SEQUENCE NUMBER DEPENDENT COUNTER
IN LINUX
Problems with Previous attack (Phrack attack)
Too Large :
Required number of packets is too large
Too Noisy :
The counter that records the total number of outgoing packets is too noisy
SEQUENCE NUMBER DEPENDENT COUNTER
IN LINUX
Both the problems mentioned can be addressed by using
“sequence-number-dependent packet counters”
SEQUENCE NUMBER DEPENDENT COUNTER
IN LINUX
DelayedACKLost (Binary Search)
DelayedACKLost (Four-way Search)
SEQUENCE NUMBER DEPENDENT
COUNTER IN MAC/BSD
•
Fi
ndings of sequence dependent counters in BSD/Mac OS, they are.
1.
rcvduppack and rcvdupbyte
2.
rcvpackafterwin and rcvbyteafterwin
3.
rcvoopack and acvoobyte
4.
rcvdupack and rcvacktoomuch
•
The first three pairs can be used to infer server-side sequence numbers.
•
The last pair is used to determine the client-side sequence numbers.
SEQUENCE NUMBER DEPENDENT
COUNTER IN WINDOWS
•
Windows OS doesn’t expose such sequence number dependent
counters and are not vulnerable to the attack.
•
Windows 7-
TCP related packet counters
includes (netstat -s”)
a. I
ncoming packets
b. O
utgoing packets
c.
Number of packets
•
These Packet counters do not leak sequence numbers directly.
INFERENCE PERFORMANCE
OVERHEAD
•
A sequence number inference is
implemented on android and Mac OS.
•
Top Figure - Tradeoff is that the fewer
iterations an attacker wants, the more bytes
he needs to send in total.
•
Bottom Graph - Inference time increases as
the RTT between attacker and client
increases.
NOISNESS OF SEQUENCE-NUMBER
DEPENDENT COUNTERS
Claim : Clean side channels that rarely increment, naturally even with
background traffic.
•
Running web pages playing You tube video in background.
Probability that the counter increments due to noise and
interference with one round of probing is roughly 0.059%.
•
Windows 7
- TCP related packet counters includes (netstat -s”)
a. Incoming packets
b. Outgoing packets
c. Number of packets
DESIGN AND IMPLEMENTATION OF
TCP ATTACKS
•
Attack Requirements
•
Client-Side TCP Injection
•
Passive TCP Hijacking
•
Server-Side TCP Injection
•
Active TCP Hijacking
ATTACK REQUIREMENTS
•
Internet access to malware.
•
Malware that can run in the background and read packet
counters
•
Ability of Malware to read the list of active TCP
connections and their four tuples
•
A predictable external port number if NAT is deployed
CLIENT-SIDE TCP INJECTION
•
Inject malicious data into a connection established by other
apps.
•
Challenge – May compete with the data sent from
legitimate server.
PASSIVE TCP HIJACKING
SERVER-SIDE TCP INJECTION
•
Attackers injects malicious payload into connection
destined for server
•
Straight forward : Combines Sequence number inference
and attack
ACTIVE TCP HIJACKING
ATTACK IMPACT ANALYSIS FROM
CASE STUDIES
•
Facebook Javascript Injection
•
Phishing Facebook Login Page
•
Command Injection on Windows Live Messenger
•
Restricted Facebook Login Page Hijack
SUCCESS RATE AND ANALYSIS OF THE
ATTACKS
•
Success rate for Facebook javascript injection when RTT=100ms is
87.5%
•
Success rate for phishing Facebook Login Page :
–
<50%
–
With two nodes for latency values of 70ms and 100ms it increases to
62.5% and 82.5%.
•
Windows Live Messenger - Command line injection was carried out using server-
side TCP injection wherein adding friend or removing existing friend, changing
status messages, sending messages to friends has been carried out with an
inference time of around 2-3 seconds.
•
Restricted Facebook Login page Hijack :
–
The app indeed has a relationship with the target website so that the user will enter his
password into the browser.
CONCLUSION
The paper provides few defense strategies to avoid the attack.
•
Always using SSL/TLS
•
Removing unnecessary global data or only allow privileged programs to access
such state.
•
providing better isolation among resources
QUESTIONS ?
THANK YOU
