1. 3rd Symposium on Positron Emission Tomography and 1st Symposium on Boron Neutron Capture Therapy Time Over Threshold calibration in the framework of J-PET Sushil K. Sharma on behalf of the J-PET collaboration Sushil K. Sharma 11/09/2018

2. Outline Introduction Experimental details Event s selection Results Summary & Outlook 3rd Jagiellonian Symposium on Positron Emission Tomography Sushil K. Sharma 11/09/2018

3. Jagiellonian - Positron Emission Tomograph 2-D front view J-PET .7cm 50 cm 192 plastic Scintillators 57.5 cm 46.75 cm Arranged axially in 3 layers 42.5 cm Key features : Trigger less DAQ TOT as measure of energy deposition 3rd Jagiellonian Symposium on Positron Emission Tomography Sushil K. Sharma 11/09/2018

4. Time-Over-Threshold & Energy deposition PMT A PMT B V V Thresholds Thresholds 1 1 1 1 TOT11 TOT11 2 2 2 2 TOT22 TOT22 3 3 3 3 TOT33 TOT33 4 4 4 4 TOT44 t t Signals from each photomultiplier are probed at four thresholds. TOT = TOTsumA + TOTsumB 3rd Jagiellonian Symposium on Positron Emission Tomography Sushil K. Sharma 11/09/2018

5. Methodology : What we have : Measured TOT values Hit positions of primary and scattered photon gives access to the values What is required : Energy of the incident photon True scattering angle Edep = f(Einc , ) 3rd Jagiellonian Symposium on Positron Emission Tomography Sushil K. Sharma 11/09/2018

6. Experimental details Small chamber in the center XAD4 22Na 3rd Jagiellonian Symposium on Positron Emission Tomography Sushil K. Sharma 11/09/2018

7. Experimental details Small chamber in the center XAD4 22Na Run specifications : Run number : 4 with small chamber Total files analysed : 500 / 3500 Velocity calibration : Applied Time Calibration : Applied 3rd Jagiellonian Symposium on Positron Emission Tomography Sushil K. Sharma 11/09/2018

8. Events selection - Analyzed : 3 Hit Events In order to study scattering of a photon, two hits are sufficient. 3rd Hit allows to use additional constraints to conjecture and tag the photon of different energy/origin Case 2 Case 1 e+ - e- annihilation into two photons (511 keV) high energetic photons 1274.6keV (Prompt) 3rd Jagiellonian Symposium on Positron Emission Tomography Sushil K. Sharma 11/09/2018

9. 3 Hit Events ( Tagging 511 keV) (hits are ordered in time) Two hits are Back-to-Back gamma 3RD Hit from the scattering of gamma either after Hit 1 or Hit2 3rd Jagiellonian Symposium on Positron Emission Tomography Sushil K. Sharma 11/09/2018

10. 3 Hit Events ( Tagging 1274.6 keV) (hits are ordered in time) Case 2: for 1274.6keV (Prompt) Ist Hit is prompt gamma 2nd Hit from the scattering of prompt gamma 3rd hit is assumed as one of the annihillation gamma from oPs decay as the time difference b/w Ist hit and 3rd hit is taken more than 10 ns 3rd Jagiellonian Symposium on Positron Emission Tomography Sushil K. Sharma 11/09/2018

11. 3 Hit Angles 12< 23< 31 Diff. of two small. angles [ deg ] Sum of two small. angles [ deg ] 3rd Jagiellonian Symposium on Positron Emission Tomography Sushil K. Sharma 11/09/2018

12. Tagging the 511 keV photon Applied Cuts: 1 2 Hit 1 and Hi 2 are back to back (511keV) TOT : TOThit1<30 ns TOThit2<30 ns Hit 1 Hit 2 Hit 3 3 Along Z : Z -23<Zhit1<23 -23<Zhit2<23 -23<Zhit3<23 .7cm 4 NO 2 hits in same scintillator 3rd Jagiellonian Symposium on Positron Emission Tomography Sushil K. Sharma 11/09/2018

13. Tagging the 1274.6 keV photon Cut on 3 Hits angles Along Z : for all hits -23 < Z < 23 Hit 1 Hit 2 Hit 3 TOThit1 < 65 ns Time diff: Timehit3 Timehit1 > 10 ns NO 2 hits in same scintillator 3rd Jagiellonian Symposium on Positron Emission Tomography Sushil K. Sharma 11/09/2018

14. Results Scattering angle distribution (511 keV) For the assignment of scattered hit to its origin, scatter test(S) was applied: S= (timescatter timeorigin) Distancescatter-origin / c 511 keV 511 keV Selected scattered angles ( ) 3rd Jagiellonian Symposium on Positron Emission Tomography Sushil K. Sharma 11/09/2018

15. Results Scattering angle distribution (1274.6 keV) Selected scattering angles ( ) 3rd Jagiellonian Symposium on Positron Emission Tomography Sushil K. Sharma 11/09/2018

16. Results : Summed over 511 keV and 1274.6 keV TOT spectra Scattered angless ( ) 3rd Jagiellonian Symposium on Positron Emission Tomography Sushil K. Sharma 11/09/2018

17. Results : TOT vs Edep Only for 511 keV Only for 1274.6 keV Relationship between TOT and Edep individual for 511 keV and 1274.6 keV photons 3rd Jagiellonian Symposium on Positron Emission Tomography Sushil K. Sharma 11/09/2018

18. Results : TOT vs Edep There is an enhancement in the value of TOT with the increase in the energy deposi- tion. However, There contribution visible during the selection of prompt gamma ??? is an additional Relationship between TOT and Edep for 511 keV and 1274.6 keV photons together 3rd Jagiellonian Symposium on Positron Emission Tomography Sushil K. Sharma 11/09/2018

19. Results : TOT vs Edep Energy bins [ 500, 550 ] 3rd Jagiellonian Symposium on Positron Emission Tomography Sushil K. Sharma 11/09/2018

20. Results : TOT vs Edep Fitting of the TOT projections for most populated energy depositions : 3rd Jagiellonian Symposium on Positron Emission Tomography Sushil K. Sharma 11/09/2018

21. Results : TOT vs Edep 3rd Jagiellonian Symposium on Positron Emission Tomography Sushil K. Sharma 11/09/2018

22. Results : TOT vs Edep Additional contribution visible during the selection of prompt gamma ??? Investigation procedure : For the calculated scattering angles ( ) for 1275 photon a). Estimate the Edep: Edep1 = f( 511 keV , ) Edep2 = f( 1275 keV, ) b) cal. TOT value for Edep1 using TOT = A + B *ln(Edep1) c). Fill the hist(Edep2, TOT) 3rd Jagiellonian Symposium on Positron Emission Tomography Sushil K. Sharma 11/09/2018

23. Results : TOT vs Edep Black line shows the histogram filled with the discussed algorithem. Assuming the contribution might be from 511 keV photon, FIT THE UNKNOWN REGION. 3rd Jagiellonian Symposium on Positron Emission Tomography Sushil K. Sharma 11/09/2018

24. TOT vs Edep ( for different hit Z position) Z (50 cm) - 2 3 - 1 0 . 5 - 1 7 . 5 - 3 . 5 3 . 5 1 0 . 5 1 7 . 5 2 3 .7cm 3rd Jagiellonian Symposium on Positron Emission Tomography Sushil K. Sharma 11/09/2018

25. TOT vs Edep ( for different hit Z position) 50000 40000 30000 TOT [ ps ] -23 to -17.5 cm -17.5 to -10.5 cm -10.5 to -3.5 cm -3.5 to 3.5 cm 3.5 to 10.5 cm 10.5 to 17.5 cm 17.5 to 23 cm 20000 10000 0 200 400 Energy Deposition [ keV ] 600 800 1000 3rd Jagiellonian Symposium on Positron Emission Tomography Sushil K. Sharma 11/09/2018

26. Summary & Outlook An algorithm is developed to tag the photons of different energy and their scattering distributions are studied. Preliminary relationship between energy deposition by interacting photon and the corresponding TOT values is established. TOT vs Edep relationship has Z dependence which is currently being investigated. 3rd Jagiellonian Symposium on Positron Emission Tomography Sushil K. Sharma 11/09/2018

27. 3rd Jagiellonian Symposium on Positron Emission Tomography Sushil K. Sharma 11/09/2018

28. Back-up slides 3rd Jagiellonian Symposium on Positron Emission Tomography Sushil K. Sharma 11/09/2018

29. Results TOT spectra 3 Hits Hit 1 Hit 2 Hit 3 3rd Jagiellonian Symposium on Positron Emission Tomography Sushil K. Sharma 11/09/2018

30. Summary & Outlook 200 keV 230 keV 270 keV 310 keV 380 keV 520 keV 640 keV 730 keV 790 keV 870 keV 950 keV 40000 Time Over Thresholds [ ps ] 30000 For different z-intervals , the center was chosen. 20000 10000 0 -20 -10 0 10 20 Z [ cm ] 3rd Jagiellonian Symposium on Positron Emission Tomography Sushil K. Sharma 11/09/2018

31. Summary & Outlook 3rd Jagiellonian Symposium on Positron Emission Tomography Sushil K. Sharma 11/09/2018

32. Summary & Outlook Threshold 1 Threshold 2 Threshold 3 Threshold 4 3rd Jagiellonian Symposium on Positron Emission Tomography Sushil K. Sharma 11/09/2018

33. Summary & Outlook TOT vs Edep (single thresholds) 3rd Jagiellonian Symposium on Positron Emission Tomography Sushil K. Sharma 11/09/2018

34. Summary & Outlook Relative Efficiency 3rd Jagiellonian Symposium on Positron Emission Tomography Sushil K. Sharma 11/09/2018

35. Summary & Outlook Relative Efficiency 3rd Jagiellonian Symposium on Positron Emission Tomography Sushil K. Sharma 11/09/2018
