Neutron Stars: Discoveries and Characteristics
Neutron Stars
Adam Flanders
Discovery of Neutron Stars
•
Walter Baade and Fritz Zwicky first proposed the existence
of neutron stars, in December 1933, at a meeting with
physicists
•
1965, Antony Hewish and Samuel Okoye found a strange
source of radio brightness in space
•
In 1967, Franco Pacini suggested the search for neutron stars
should focus on discovering the electromagnetic waves
caused by the rapid spinning of the star. Antony and Jocelyn
Bell discovered the radio emissions of a pulsar from a
neutron star
•
In 1974, Joseph Taylor and Russell Hulse discovered the first
two orbiting neutron stars
Mass versus radius relation
•
Neutron-star
mass versus
radius in three
different
approximations
Neutron Stars
•
Degenerate stars heavier than 1.4 solar
masses collapse to become neutron stars
•
Formed in supernova explosions
•
Electrons are not separate
–
Combine with nuclei to form neutrons
•
Neutron stars are degenerate gas of neutrons
Neutron energy levels
•
Only two neutrons (one up,
one down) can go into each
energy level.
•
In a degenerate gas, all low
energy levels are filled.
•
Neutrons have energy, and
therefore are in motion and exert
pressure even if temperature is
zero.
•
Neutron star are supported by
neutron degeneracy.
Neutron Stars
•
Very compact – about 10 km radius
•
Very dense – one teaspoon of neutron star
material weighs as much as all the buildings in
Manhattan
•
Spin rapidly – as fast as 600 times per second
•
High magnetic fields – compressed from
magnetic field of progenitor star
Composition
•
A neutron star is predominantly composed
of neutrons, with a few electrons and
protons within some of the layers of the star
•
A range of particles such as pion
condensates, delta isobars, and quark-gluon
plasmas can be found within the inner
layers of the star where temperatures are
high enough.
Composition
•
A neutron star emits
neutrinos and other
particles through pulsars,
which can be detected
from earth
•
A neutron star can also
have material orbiting it
in the form of stellar
wind
Pulsars
Discovered by Jocelyn
Bell in 1967.
Her advisor, Anthony
Hewish, won the Nobel
Prize in Physics for the
discovery in 1974.
Pulsars
Energy source
is spin down of
neutron star.
Must lie along
pulsar beam to
see pulsed
signals.
What Makes the Pulsar Beam?
•
They undergo the
process called
accretion
•
It grabs onto electron
from other atomic
fields and flings them
into space in high
speed emitting
radiation
Crab Pulsar
Magnetars
Magnetic fields so strong
that they produce
starquakes on the neutron
star surface.
These quakes produce
huge flashes of X-rays
and Gamma-rays.
Energy source is a
magnetic field.
Magnetar Formation
•
When in a supernova, a star collapses to a neutron star, and
its magnetic field increases dramatically in strength
•
Duncan and Thompson calculated that when the spin,
temperature and magnetic field of a newly formed neutron
star falls into the right ranges, a
dynamo mechanism
could
act, converting heat and rotational energy into magnetic
energy and increasing the magnetic field, normally an
already enormous 10
8
teslas, to more than 10
11
teslas
•
It is estimated that about one in ten supernova explosions
results in a magnetar rather than a more standard neutron
star or pulsar
Dynamo Mechanism
•
The dynamo theory proposes a mechanism by which a
celestial body such as Earth or a star generates a magnetic
field
•
The dynamo theory describes the process through which a
rotating, convecting, and electrically conducting fluid can
maintain a magnetic field over astronomical time scales
•
A dynamo is thought to be the source of the Earth's
magnetic field and the magnetic fields of Mercury and the
Jovian planets
X-Ray Pulsars
Neutron star in binary system with a normal star
X-Ray Pulsars
High magnetic field neutron stars make regular
pulsations. Energy source is gravitational energy of
infalling matter.
X-ray Bursters
•
X-ray bursts are some of the most energetic events
observed in the cosmos
•
X-ray bursts are the thermonuclear explosions occurring
near the surface of accreting neutron stars
•
The material accreted from the companion star is funneled
to the surface of the neutron stars
•
The extreme density found near the surface of the neutron
star provides the environment for explosive Hydrogen and
Helium burning
X-ray Bursters
X-ray vs Radio Pulsars
•
Radio pulsars have periods on the order of milliseconds to
seconds, and all radio pulsars are losing angular
momentum and slowing down. In contrast, the X-ray
pulsars exhibit a variety of spin behaviors
•
Some X-ray pulsars are observed to be continuously
spinning faster and faster or slower and slower (with
occasional reversals in these trends) while others show
either little change in pulse period or display erratic spin-
down and spin-up behavior
X-ray pulsar
Radio pulsar
X-Ray vs Radio
Pulsars
X-ray vs Radio Pulsars
•
Over 99% of radio pulsars are single objects that radiate
away their rotational energy in the form of relativistic
particles and magnetic dipole radiation, lighting up any
nearby nebulae that surround them
•
In contrast, X-ray pulsars are members of binary star
systems and accrete matter from either stellar winds or
accretion disks
•
The accreted matter transfers angular momentum to the
neutron star causing the spin rate to increase or decrease at
rates that are often hundreds of times faster than the typical
spin down rate in radio pulsars
Sources
•
https://www.researchgate.net/publication/247152796_Properties_of_dense_asymmetric_nuclear_matt
er_in_Dirac-Brueckner-Hartree-Fock_approach#pf11
•
http://www.physics.drexel.edu/~bob/Term_Reports/John_Timlin.pdf
•
http://archive.jinaweb.org/docs/nuggets_09/Spo_nugget.pdf
•
https://arxiv.org/abs/1506.07881
•
https://aasnova.org/2019/09/10/radio-pulsars-how-slow-do-they-go/
•
https://www.nasa.gov/missions/deepspace/f_magnetars.html
•
https://www.ncbi.nlm.nih.gov/pmc/articles/PMC33576/
•
https://chandra.harvard.edu/xray_sources/neutron_stars.html
•
https://www.esa.int/Science_Exploration/Space_Science/Missing_link_found_between_X-
ray_and_radio_pulsars
