Streamlining Dynamics Integration in the Cloud: A User-Centric Approach
Integrating With
Dynamics by
Leveraging Azure
John, Software Engineer, Root16
•
Our client required an integration between
CRM and on-prem services
•
Previously, dynamics instance hosted on-
prem sever
•
Plugins could make direct access to on-prem
SQL server
•
With Dataverse, no longer direct access
•
Objective: hoist communication into the cloud
to act as ‘middle-man’
Intro
•
Discuss the problem we were brought in to
solve
•
What other architectures were considered
•
Top-down architecture
•
Cloud architecture component deep dive
•
Issues we encountered and solved
The Problem to
Solve
The Problem
•
As they migrated their Dynamics instance from on-
prem to the cloud, some integrations had to be
reconfigured
•
They had plugins which would reach out to on-
prem SQL servers to perform data
validation/integration
•
On-prem services inaccessible from Dynamics
cloud instance
•
Develop a system to act as a ‘middle-man’ to pass
messages from Dynamics to on-prem
•
Needed to be fast and scalable for high-throughput
•
Easily repeatable to build
•
Needed to reuse a lot of preexisting code
Possible Solutions
Possible Solutions
•
Azure Functions
•
Using the Azure Service Bus integration with Dynamics to send messages
•
Have an Azure function as the listener
•
Scrapping the integration
•
Lots of pushback on this one :)
Issues With Azure Function
•
Asynchronous by design
•
Needed a way to then get the data back to D365
•
Key insight: one of these integrations needed to be real time
•
Http web request is a more appropriate choice
Advantages to AKS
•
Client already had Kubernetes infrastructure
•
Scalable horizontally during times of peak load
•
Easy ASP .NET REST API project creation
•
Realtime communication via HTTP
High Level
Architecture
High Level Architecture
•
Dynamics makes a synchronous web request via plugin
•
Hits
Azure Application Gateway
•
Forwards the connection to
Azure Kubernetes Service
(AKS)
•
AKS Custer has two components:
•
Load balancer for pods (virtual machines)
•
Pods do the business logic and connect to on-prem services
•
Business logic copied right out of the plugin
•
AKS’s subnet has connection to on-prem network via a Microsoft
Azure virtual network
•
Pods connect to on-prem services
•
Forward the request back up the chain
High Level Architecture
Components Deep
Dive
AKS Cluster
•
Managed Kubernetes Cluster
•
Client already had an AKS service in their
Azure subscription
•
D365 team assigned our own AKS
namespace in each environment
•
Pods run on shared virtual machines
AKS Logs
•
Set your app to log output to
‘Console’ logs are streamed
straight to AKS
•
Querable in Azure dashboard
•
Kusto Query Language (KQL)
•
Read-only syntax focused on
transformations of rows
•
Readable and writeable syntax
Azure Dev Ops Pipeline Deploys
•
ADO pipelines help automate and control our
deploys
•
Can choose which environment to deploy to
•
QA and PROD require admin approval
.NET 7 API
•
Standard REST application, containerized via a Docker file
•
Visual Studio has a containerized application template
•
Can run via docker on dev machine
•
Make deployment to Kubernetes painless
.NET 7 API
App Configuration
•
Configuration parameters and secret values are
stored in
Azure Key Vault
•
In order to access secrets in KV, the Integration API
makes use of
App Configuration
in Azure,
•
When run locally, the .NET runtime consumes the
auth information store in
`appsettings.Development.json` to access the Dev
Key Vault
•
When deployed on Kubernetes, the cluster handles
all authentication to Azure KV
App Configuration
•
From the perspective of the
.NET program, nothing has
changed
•
Access the `Configuration`
object like normal
Lens
•
Lens: ‘The Kubernetes IDE‘
is a program that
facilitates Kubernetes deployments and
services
•
View deployments, view logs, kill/restart pods
App Insights
•
Service that your applications can write logs and
other metrics to
•
Remarkably easy to setup
•
Only required step is to add nuget package
reference:
Microsoft.ApplicationInsights.AspNetCore
•
Then include instrumentation key:
•
Instrumentation key is already in the
‘Configuration’ object
Issues and Solutions
Open Ports
•
Port 1433 between AKS subnet and on-prem subnet needed to be open
•
Required coordinating with network team
•
To confirm ports open, could remote into pods via lens
•
Run ‘nslookup’ and ‘nmap’ to validate and debug
503 Gateway
•
Endpoints returning ‘503 Service Unavailable server error response’
•
Checking app insights, no non-200 response ever returned to client
•
Turned out the
Web Application Firewall
was returning 503 to the App Gateway
•
WAF wasn’t able to keep up with load, as payload sizes too large
