1. Secure Out-of-band Remote Management Using Encrypted Virtual Serial Consoles in IaaS Clouds Kenichi Kourai Tatsuya Kajiwara Kyushu Institute of Technology

2. IaaS Clouds Provide users with virtual machines (VMs) Users manage their systems through SSH In-band remote management is usually used A user connects an SSH client to an SSH server running in his VM Not usable when a user failed network configurations user VM cloud SSH client SSH server firewall

3. Virtual Serial Console (VSC) IaaS provides out-of-band remote management An SSH server runs in the management VM Access a user VM via a VSC A VSC consists of a virtual serial device and a serial driver A user can access his VM without relying on VM's network management VM user VM SSH server firewall SSH client VSC virtual serial device serial driver

4. Untrusted Admins in IaaS The management VM is not always trustworthy Honest-but-curious admins take information that they can easily look at Malicious admins act as inside attackers Skill-less admins cause a vulnerable management VM to be penetrated by outside attackers management VM user VM outside attackers untrusted admins

5. Attacks against Remote Management Attackers can eavesdrop on inputs and outputs of out-of-band remote management By modifying an SSH server in the management VM Attack examples Extract passwords from inputs to login prompts Steal displayed secrets management VM user VM SSH server SSH client virtual serial device serial driver

6. SCCrypt Provide an encrypted VSC to prevent information leakage Receive encrypted inputs from the management VM Decrypt and send them to a user VM Receive unencrypted outputs from a user VM Encrypt and send them to the management VM management VM user VM encrypted VSC SSH server SSH client decrypt virtual serial device serial driver encrypted inputs/outputs encrypt

7. Where to Encrypt/Decrypt? Virtual serial device in the management VM? The entire management VM is untrusted Attackers can tamper with the virtual device Serial driver in a user VM? Modifying the existing device driver is not desirable Users cannot use favorite OSes user VM management VM en-/de- crypt? en-/de- crypt? serial driver virtual serial device

8. Leveraging the Trusted VMM SCCrypt encrypts/decrypts data in the virtual machine monitor (VMM) The integrity of the VMM can be guaranteed At boot time: remote attestation with TPM At runtime: HyperGuard [Rutkowska+ '08], HyperCheck [Wang+ '10], and HyperSentry [Azab+ '10] with SMM management VM user VM encrypted VSC serial driver virtual serial device trusted authority SCCrypt VMM

9. How to Identify Inputs/Outputs? The traditional VMM does not recognize a virtual serial device or a serial driver Cannot rely on information from the untrusted device in the management VM Cannot obtain information from the unmodified driver in a user VM user VM management VM untrusted virtual serial device unmodified serial driver ? SCCrypt VMM

10. Tracking Device States The VMM identifies inputs/outputs without the cooperation of the device or the driver Track the state of a virtual serial device From the interactions between the device and the driver Extract only inputs/outputs Based on the knowledge of the standard of serial devices management VM user VM serial driver virtual serial device SCCrypt VMM

11. Implementation We have implemented SCCrypt in Xen 4.1.3 and the OpenSSH 6.0p1 client Support HVM guests Emulate hardware as is Support PV guests (see the paper) Define interfaces suited for virtualization

12. Output Delivery A serial driver writes data using OUT instruction The VMM traps this instruction using Intel VT-x It encrypts the written data using RC4 Only if the specified I/O port address is 3F8 A session key is exchanged for each connection user VM management VM SSH server SSH client OUT serial driver virtual serial device trap encrypt VMM

13. State Tracking The VMM encrypts the written data if The FIFO buffers are enabled Neither in the divisor latch access nor loopback mode Devisor latch access mode: set a baud rate Loopback mode: test a device It watches all the writes to recognize the context divisor latch access mode looback mode FIFO disabled FIFO enabled

14. Input Delivery A serial driver reads data using IN instruction The VMM traps this instruction Receive input data from a virtual serial device It decrypts input data using RC4 If the same conditions as in output delivery are satisfied user VM management VM SSH server SSH client IN serial driver virtual serial device decrypt trap VMM

15. Pending Outputs at Reconnection An SSH client cannot decrypt pending outputs correctly at reconnection Console outputs are stored in a virtual serial device While an SSH client is not connected Pending outputs are sent to the client at reconnection Encrypted with an old session key management VM ? new session key pending data encrypted with an old session key SSH server SSH client virtual serial device

16. Re-encryption of Outputs The VMM re-encrypts pending outputs Restore unencrypted data with an old session key Cannot 'decrypt' it Reverse the encryption process in RC4 Encrypt the data with a new session key decrypt reverse management VM !#$ !#$ SSH client SSH server A#$ !#C pending data virtual serial device !BC AB$ old/new session keys ABC re-encrypt ABC VMM

17. Experiments We confirmed the effectiveness of SCCrypt Response time in an SSH client Throughput of console outputs CPU utilization We compared results between SCCrypt and vanilla Xen management VM vCPU: 8 Mem: 3 GB OS: Linux 3.2.0 SSH: OpenSSH 5.9p1 client server CPU: Intel Xeon E5630 Mem: 6 GB Net: Gigabit Ethernet OS: Linux 3.2.0 SSH: OpenSSH 6.0p1 CPU: Intel Core i7 870 Mem: 4 GB Net: Gigabit Ethernet VMM: Xen 4.1.3 user VM vCPU: 8 Mem: 1 GB OS: Linux 3.2.0

18. Response Time (Input) We measured the response time of inputs An SSH client sent an input to an SSH server It received an output caused by its remote echo Result 2.9% shorter in SCCrypt The reason was unclear vanilla Xen SCCrypt response time (ms) 2.0 1.5 1.0 0.5 0.0

19. Throughput (Output) We measured the throughput of outputs We wrote large text to a VSC in a user VM Result 5.6% higher in SCCrypt The reason was unclear vanilla Xen SCCrypt 50 throughput (cps) 40 30 20 10 0

20. CPU Utilization (Input) We measured the CPU utilization under the keyboard auto-repeat at a client Management VM: 0.8% point lower in SCCrypt User VM: almost the same vanilla Xen SCCrypt vanilla Xen SCCrypt CPU utilization (%) 25 1.5 CPU utilization (%) management VM user VM 20 1.0 15 10 0.5 5 0 0.0

21. Related Work FBCrypt [Egawa et al.'12] Encrypt keyboard/mouse inputs and video outputs in out-of-band remote management using VNC Strongly depend on VNC Xoar [Colp et al.'11] Run a virtual serial device in trusted Console VM Console VM can be compromised via an SSH server VMware vSphere Run virtual devices and a VNC server in the VMM The VMM can be compromised via the VNC server

22. Conclusion SCCrypt for enabling secure out-of-band remote management in untrusted IaaS clouds Provide encrypted VSCs Inputs/outputs are securely decrypted/encrypted in the trusted VMM Future work Apply SCCrypt to other remote management systems using VSCs E.g., web-based Ajaxterm
